OSGi
Building LinkedIn's Next Generation
       Architecture with OSGI


                                           Yan Pu...
Background
■ LinkedIn created in 03/2003
  • close to 30M members
  • profitable with 5 revenue lines
  • HQ in Mountain Vi...
Challenges
 ■ Growing engineering team on a monolithic
   code base (still modular)


 ■ Growing product team wanting more...
Challenges (SOA in dev)
       Front-End                               Back-End

                           X
         1  ...
Container Challenge

■ 1 war with N services
  • does not scale for dev (conflicts, monolithic...)


■ N wars with 1 servic...
Challenges (SOA in prod)
 ■ Upgrading back-end service to new version
   requires downtime
   • Hardware LB does not accou...
Solution: OSGi

■ Belief that OSGi is one of the tools that will help us
  address those challenges




       Why OSGi?
OSGi intro

 ■ OSGi means “Open Services Gateway
   initiative”
 ■ OSGi is a spec with several implementations
   • Equino...
OSGi intro (cont.)
 ■ OSGi has some very good properties
   • Smart class loading => multiple versions
     jars ok
   • H...
OSGi bundle

Specification-Title: Colorado Software Summit 2008 Hello Wolrd Client
Bundle-Activator:
 com.linkedin.colorad...
BundleActivator
 ■ In a war: ServletContextListener
 public interface ServletContextListener extends EventListener {
   vo...
BundleContext

 ■ The bundle context is the entry point:
   • registerService / getServiceReference =>
     to register / ...
Demo




■ Equinox demo... stay tuned...
Web Container

                           JARs         WAR


■ Services exported       Services
  with Spring/RPC
■ Servic...
Web Container

                   JARs              JARs


                  Services          Services
■ Cannot share
  j...
OSGi container
                            Bundles


■ Bundles (jars) shared         Service Registry

■ Services shared
■...
Distributed OSGi

 ■ OSGi is currently container centric


 ■ Next version (4.2) will introduce distributed
   OSGi


   •...
LinkedIn distributed OSGi

                      Bundles

                              Service
                      Serv...
LinkedIn distributed OSGi
                                     Bundles


                          Service
               ...
LinkedIn distributed OSGi
                                         Bundles


                                  Service
   ...
LinkedIn distributed OSGi

                                         Bundles


                                  Service
  ...
LinkedIn distributed OSGi
                                         Bundles


                                  Service
   ...
LinkedIn distributed OSGi
 ■ no more N-1 / 1-N problem
   • libraries and services can be shared in 1
     container (mem....
LB and version
                                         Bundles

  Bundles
                                  Service
     ...
Everything is perfect...



■ ...Not really
  • OSGi has some problems
OSGi problems

■ OSGi is great, but tooling is not quite there
  yet
■ Not every lib is a bundle
■ OSGi was designed for e...
OSGi problems
■ OSGi is quite low level => but there is some
  work to ‘hide’ the complexity
  • spring DM (spring dynamic...
OSGi problems (cont.)


 ■ version management can be nightmarish
   • Import-Package:
     com.linkedin.util;version=1.0.0...
Runtime version problem




 ■ client1 and client2 uses Service 3.0.0
 ■ Dependencies are ‘loose’: [3.0.0, 4.0.0)
Runtime version problem




■ We upgrade client1 and service
■ client2 starts using green bundles
■ => Most likely untested
Runtime version solutions ?
 ■ A solution is to lock version:
   •   [1.0.0,1.0.0] => no slack
   •   [1.0.0,1.0.1) => tin...
Runtime version problem




■ With maximal lock-down, client2 cannot use
  the new service
Runtime version solutions ?




 ■ Services cannot talk to each other directly
   => need serialization for backward
   co...
Despite problems...




■ ...OSGi and community moving in the right direction
Where are we ?
■ Bundle repository (big amount of work... in progress)
■ Use ivy/bnd for generating bundles
■ Evaluating c...
Conclusion



 ■ Using OSGi... definitely!
 ■ But we do not want application developers
   to have to deal with it.
More information



 ■ Check my posts on the LinkedIn blog (OSGi
   series). More to come...
Upcoming SlideShare
Loading in …5
×

Building LinkedIn's Next Generation Architecture with OSGi

18,388 views
18,136 views

Published on

Published in: Technology, Education
2 Comments
42 Likes
Statistics
Notes
  • Thanks for the presentation. I was not at all familiar with OSGi architecture, now I am incredibly curious. Will be doing quite a bit of research because of this. Excellent presentation.
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
  • Nice presentation, Yan!
    Regarding slide 27. Distributed OSGi doesn't explicitly state how load balancing should be done, but the idea is that implementors of DOSGi could provide mechanisms that would achieve this behind the scenes. This could be exposed via an intent that expresses that a service is 'load balanced' or 'highly available' where the actual details of how this is exactly done is left up to the implementation of DOSGi used.
       Reply
    Are you sure you want to  Yes  No
    Your message goes here
No Downloads
Views
Total views
18,388
On SlideShare
0
From Embeds
0
Number of Embeds
6,850
Actions
Shares
0
Downloads
610
Comments
2
Likes
42
Embeds 0
No embeds

No notes for slide

Building LinkedIn's Next Generation Architecture with OSGi

  1. 1. OSGi Building LinkedIn's Next Generation Architecture with OSGI Yan Pujante Distinguished Software Engineer Member of the Founding Team @ LinkedIn ypujante@linkedin.com http://www.linkedin.com/in/yan
  2. 2. Background ■ LinkedIn created in 03/2003 • close to 30M members • profitable with 5 revenue lines • HQ in Mountain View (400 employees) ■ Technologies • 2 datacenters (~ 600 machines) • SOA, java, tomcat, spring framework, http, Oracle, MySQL, servlets, jsp, graph, OSGi... • dev on MacOS X, prod on Solaris
  3. 3. Challenges ■ Growing engineering team on a monolithic code base (still modular) ■ Growing product team wanting more and more feature, faster ■ Growing operations team deploying more and more servers
  4. 4. Challenges (SOA in dev) Front-End Back-End X 1 3 webapp Z 2 Y webapp 4 M N webapp jetty (1) webapp P N R webapp webapp webapp tomcat jetty (2) ■ Front-end: many BL services in one webapp (in tomcat) ■ Back-end: many wars in 5 containers (jetty) with 1 service per war ■ Note that prod and dev are different
  5. 5. Container Challenge ■ 1 war with N services • does not scale for dev (conflicts, monolithic...) ■ N wars with 1 service • does not scale from a container point of view (no shared jars) ■ Can add containers but only 12Gb of RAM :(
  6. 6. Challenges (SOA in prod) ■ Upgrading back-end service to new version requires downtime • Hardware LB does not account for version ■ Upgrading front-end service to new version requires redeploy • N services in 1 war ■ Adding new back-end service painful • lots of manual configuration (LB, front- end...)
  7. 7. Solution: OSGi ■ Belief that OSGi is one of the tools that will help us address those challenges Why OSGi?
  8. 8. OSGi intro ■ OSGi means “Open Services Gateway initiative” ■ OSGi is a spec with several implementations • Equinox (eclipse!) • Knoplerfish • Felix (Apache)
  9. 9. OSGi intro (cont.) ■ OSGi has some very good properties • Smart class loading => multiple versions jars ok • Highly dynamic => deploy / undeploy built in • Services registry • Highly extensible / configurable ■ OSGi bundle = Jar File with OSGi manifests
  10. 10. OSGi bundle Specification-Title: Colorado Software Summit 2008 Hello Wolrd Client Bundle-Activator: com.linkedin.colorado.helloworld.client.HelloWorldClientActivator Import-Package: com.linkedin.colorado.helloworld.api;version=quot;[1.0.0,1.0.1)quot;, com.linkedin.colorado.helloworld.client;version=quot;[1.0.0,1.0.1)quot;, org.osgi.framework;version=quot;[1.4.0,1.4.1)quot; Export-Package: com.linkedin.colorado.helloworld.client;version=quot;1.0.0quot; Bundle-Version: 1.0.0 Bundle-Name: colorado-helloworld-client Bundle-ManifestVersion: 2 Bundle-SymbolicName: colorado-helloworld-client Bnd-LastModified: 1224557973403 Generated-On: 20081020 Tool: Bnd-<unknown version> Implementation-Version: DevBuild
  11. 11. BundleActivator ■ In a war: ServletContextListener public interface ServletContextListener extends EventListener { void contextInitialized(ServletContextEvent event); void contextDestroyed(ServletContextEvent event); } web.xml <listener> <listener-class>com.colorado.MyListener</listener-class> </listener> ■ In a Bundle: BundleActivator public interface BundleActivator { void start(BundleContext bundleContext) throws Exception; void stop(BundleContext bundleContext) throws Exception; } MANIFEST.MF Bundle-Activator: com.colorado.MyActivator
  12. 12. BundleContext ■ The bundle context is the entry point: • registerService / getServiceReference => to register / get services from registry • addBundleListener / addServiceListener => to listens / extends the framework • even installBundle ! • ... and more
  13. 13. Demo ■ Equinox demo... stay tuned...
  14. 14. Web Container JARs WAR ■ Services exported Services with Spring/RPC ■ Services in same war can see each other SpringRPC ■ Share the jars WEB Container VM HTTP
  15. 15. Web Container JARs JARs Services Services ■ Cannot share jars SpringRPC SpringRPC ■ Cannot talk directly WEB Container VM HTTP
  16. 16. OSGi container Bundles ■ Bundles (jars) shared Service Registry ■ Services shared ■ Dynamic replacement of bundles OSGi Container VM • OSGi solves the container challenge
  17. 17. Distributed OSGi ■ OSGi is currently container centric ■ Next version (4.2) will introduce distributed OSGi • What do we do in the meantime ?
  18. 18. LinkedIn distributed OSGi Bundles Service Service Registry Registry C1 VM ■ Service ‘red’ talks to service ‘green’ (local) • What happens if we move ‘green’ to a different container ?
  19. 19. LinkedIn distributed OSGi Bundles Service Registry Bundles C2 Service Registry VM Bundles C1 VM Service Registry C3 VM
  20. 20. LinkedIn distributed OSGi Bundles Service Registry Bundles 2 C2 Service Registry VM 2 Bundles C1 VM Service Registry C3 VM
  21. 21. LinkedIn distributed OSGi Bundles Service Registry Bundles 2 C2 Service Registry VM 2 3 Bundles C1 VM Service Registry 3 C3 VM
  22. 22. LinkedIn distributed OSGi Bundles Service Registry Bundles 2 C2 Service Registry VM 2 3 Bundles C1 VM Service Registry 3 C3 VM
  23. 23. LinkedIn distributed OSGi ■ no more N-1 / 1-N problem • libraries and services can be shared in 1 container (mem. footprint smaller) • services shared across containers ■ transparent location to clients • no more configurations to change when adding/removing/moving services ■ software load balancer • much more flexible (handle version)
  24. 24. LB and version Bundles Bundles Service Registry Service Registry 2 2 C2 VM 3 Bundles C1 VM Service Registry 3 C3 VM
  25. 25. Everything is perfect... ■ ...Not really • OSGi has some problems
  26. 26. OSGi problems ■ OSGi is great, but tooling is not quite there yet ■ Not every lib is a bundle ■ OSGi was designed for embedded devices => using it for server side is recent (but very active)
  27. 27. OSGi problems ■ OSGi is quite low level => but there is some work to ‘hide’ the complexity • spring DM (spring dynamic module) • multiple vendors containers ■ Spring DM Server, Glassfish, Infiniflow ■ OSGi is container centric, but next version will add distributed OSGi (although no support for LB)
  28. 28. OSGi problems (cont.) ■ version management can be nightmarish • Import-Package: com.linkedin.util;version=1.0.0 ■ version=1.0.0 means [1.0.0, ∞) ■ should use at least: version=[1.0.0,2.0.0) ■ runtime is dynamic and can result in untested code being executed!
  29. 29. Runtime version problem ■ client1 and client2 uses Service 3.0.0 ■ Dependencies are ‘loose’: [3.0.0, 4.0.0)
  30. 30. Runtime version problem ■ We upgrade client1 and service ■ client2 starts using green bundles ■ => Most likely untested
  31. 31. Runtime version solutions ? ■ A solution is to lock version: • [1.0.0,1.0.0] => no slack • [1.0.0,1.0.1) => tiny bit of slack for emergency mode ■ Does it really work ? spring 2.5.5 imports hibernate version [3.1,∞) ■ Can OSGi even resolve with everything locked down ?
  32. 32. Runtime version problem ■ With maximal lock-down, client2 cannot use the new service
  33. 33. Runtime version solutions ? ■ Services cannot talk to each other directly => need serialization for backward compatible services (dynamic proxy)
  34. 34. Despite problems... ■ ...OSGi and community moving in the right direction
  35. 35. Where are we ? ■ Bundle repository (big amount of work... in progress) ■ Use ivy/bnd for generating bundles ■ Evaluating container • Infiniflow (from Paremus) most likely the one • LinkedIn spring / SCA to deploy composites ■ Work on the load balancer/distribution (in progress) ■ Work on tooling / build integration (Sigil from Paremus) ■ Much much more to do...
  36. 36. Conclusion ■ Using OSGi... definitely! ■ But we do not want application developers to have to deal with it.
  37. 37. More information ■ Check my posts on the LinkedIn blog (OSGi series). More to come...

×
