Getting Started with the Talis Platform <ul><ul><li>Leigh Dodds  </li></ul></ul><ul><ul><li>Platform Programme Manager </l...
Agenda <ul><li>Platform Overview </li></ul><ul><li>Core Concepts </li></ul><ul><li>Review of the RDF Model </li></ul><ul><...
Platform Overview
Software as a Service Multi-Tenant Data Storage Service
Unstructured Data Storage e.g. binary files, including images, documents, etc
Structured Data Storage RDF metadata
Access Control All data is open (to read) by default Configurable access options
Full-Text Searching  and Querying
Standards Compliance RDF, SPARQL, HTTP
Platform Architecture Web API Metabox Contentbox
REST, RDF Authentication & Authorization Content Negotiation Core Concepts aka “The Science Bit”
REST Re presentational  S tate  T ransfer Correct Use of HTTP
Resource-Centric API Everything has a unique URI
Interact with resources using HTTP GET  = read PUT = write POST = update/modify DELETE = delete
Use HTTP Response Codes 200 = OK 201 = Created (new resource) 202 = Accepted (for processing) 400 = Bad Request 500 = Serv...
Mime Types Used to identifiy content & meaning of request and response body
Content  Negotiation Majority of services support multiple output options, list varies by resource Accept  header output  ...
Our Service Checklist <ul><ul><li>Consistent URI structure </li></ul></ul><ul><ul><li>Every service has human interface </...
Authentication HTTP Digest Authentication
Authentication Example
Authorization By default stores are world-readable, Store owner writable Customisable roles and privileges per-Store
Review of the RDF Model
Apollo 11 was launched from Cape Canaveral
Apollo 11 was launched from Cape Canaveral Subject Predicate Object
<http://purl.org/net/schemas/space/spacecraft/apollo-11>   <http://purl.org/net/schemas/space/launchsite>  <http://purl.or...
space: spacecraft/apollo-11   space: launchsite  space: launchsite/capecanaveral.
space:spacecraft/apollo-11  space:launchsite space:launchsite/capecanaveral. space:spacecraft/apollo-11  rdfs:label   “Apo...


Benefits of RDF?
Good for Semi-structured Data “Schema-Free” Very Flexible
Extensible New properties New resources New types of resource New statements
Encourages Convergence Reuse of vocabularies (i.e. properties) Reuse of identifiers (i.e. talk about the same things)
Simplifies Data Integration and Aggregation Shared identifiers Common data model Common query language Common data formats
Several Different Ways to Serialize RDF Optimized for different purposes
Turtle Simple to read and hand-author Used in SPARQL query language
@prefix rdf: <http://www.w3.org/1999/02/22-rdf-syntax-ns#> @prefix space: <http://purl.org/net/schemas/space/>  @ @prefix ...
RDF/XML Best for data interchange Harder to read
<rdf:RDF xmlns:j.0=&quot;http://xmlns.com/foaf/0.1/“ xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  xm...
The Content Box Managing unstructured, binary data
Store any stream of binary data Images, documents, Javascript, etc
Full HTTP Caching Support ETags Efficient retrieval Conditional updates
Server or Client Assignment of Identifiers Provides full control over how URIs assigned
ContentBox URLs <ul><li>/storename/items </li></ul><ul><ul><li>The Contentbox container </li></ul></ul><ul><li>/storename/...
Adding Content
Deleting Content
Metadata for Contentbox Resources Minimum is URI and ETag Extract height & width of images … more metadata extraction in f...
The Meta Box Managing structured metadata
Full RDF Data Storage Create, read, update, delete RDF resources Query RDF data
Configurable Full Text Indexing of RDF Indexes updated whenever new metadata added
Versioned and Un-Versioned Updates By submitting data to separate resources Maintain audit trail
Can be Divided into Sub-Graphs Separate access control options
Metabox URLs <ul><li>/storename/meta </li></ul><ul><ul><li>The metabox </li></ul></ul><ul><li>/storename/meta/changesets <...
Storing RDF POST  application/rdf+xml Changes saved immediately Search indexing asynchronous
Triples are  Merged  into Store Can catch out the unwary Updates happen through separate mechanism
Retrieving Metadata /meta?about=…URI… Can select RDF serialization
Updating Resources POST  application/vnd.talis.changeset+xml
ChangeSets Vocabulary that specifies removals/additions to an RDF graph
<ul><li><rdf:RDF xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  </li></ul><ul><li>xmlns:cs=&quot;http:...
<ul><li><rdf:RDF xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  </li></ul><ul><li>xmlns:cs=&quot;http:...
<ul><li><rdf:RDF xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  </li></ul><ul><li>xmlns:cs=&quot;http:...
Versioned Updates POST to  /meta/changesets Apply update and stores changeset for later retrieval
Batch Updates Combine several changesets into single POST Linked together to define ordering
<rdf:RDF xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  xmlns:cs=&quot;http://purl.org/vocab/changeset...
Data Extraction & Exploration with SPARQL
SPARQL RDF query language; HTTP protocol; Results format 4 different forms of query
ASK Test whether the graph contains some data of interest
#Was there a launch on 16 th  July 1969? PREFIX space: <http://purl.org/net/schemas/space/> PREFIX xsd: <http://www.w3.org...
<?xml version=&quot;1.0&quot;?> <sparql  xmlns=&quot;http://www.w3.org/2005/sparql-results#&quot;> <head> </head> <boolean...
DESCRIBE Generate an RDF description of a resource(s)
#Describe launch(es) that occurred on 16 th  July 1969 PREFIX space: <http://purl.org/net/schemas/space/> PREFIX xsd: <htt...
#Describe spacecraft launched on 16 th  July 1969 PREFIX space: <http://purl.org/net/schemas/space/> PREFIX xsd: <http://w...
CONSTRUCT Create a custom RDF graph based on query criteria
PREFIX space: <http://purl.org/net/schemas/space/> PREFIX xsd: <http://www.w3.org/2001/XMLSchema#> PREFIX foaf: <http://xm...
SELECT SQL style result set retrieval
PREFIX space: <http://purl.org/net/schemas/space/> PREFIX xsd: <http://www.w3.org/2001/XMLSchema#> PREFIX foaf: <http://xm...
…as XML <?xml version=&quot;1.0&quot;?> <sparql  xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot; xmlns=&...
…as JSON {  &quot;head&quot;: {  &quot;vars&quot;: [ &quot;name&quot; , &quot;agency&quot; , &quot;mass&quot; ]  } ,  &quo...
Tour of Extra Features Searching, browsing, augmentation
Searching Full text index over RDF literals Configurable indexing options
/items?query=[query] &max=[10] &offset=[0] &sort=[comma-separated fieldnames] &xsl=[XSLT stylesheet] &content-type=[mimety...
Query Syntax <ul><li>lunar </li></ul><ul><li>luna* </li></ul><ul><li>“ apollo 11” </li></ul><ul><li>lunar OR apollo </li><...
Query Results RSS 1.0 feed OpenSearch extensions (paging, relevance) Full description of each resource
<rdf:RDF xmlns=&quot;http://purl.org/rss/1.0/&quot;  xmlns:foaf=&quot;http://xmlns.com/foaf/0.1/&quot;  xmlns:relevance=&q...
Facetted Search Similar to Amazon product search, etc Group search results by specific fields
/services/facet?query=[query] &fields=[comma-separated fieldnames]   &top=[10] &format=[xml|html]
<facet-results xmlns=&quot;http://schemas.talis.com/2007/facet-results#&quot;> <head> <query>name:luna*</query> <fields>ag...
Augmentation Annotate an RSS 1.0 feed against a store Automatically add a description of each referenced resource
Store Administration Job Control, Store Configuration
Field Predicate Map Associate a short name to a RDF property Properties in field predicate map are indexed for searching S...
<rdf:RDF  xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot;  xmlns:rdfs=&quot;http://www.w3.org/2000/01/rd...
Query Profile Assign weightings to fields for searching
<rdf:RDF  xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot; xmlns:rdfs=&quot;http://www.w3.org/2000/01/rdf...
Job Control Reindex, Reset, Snapshot, Restore POST Job Request to  /jobs
<rdf:RDF xmlns:rdf=&quot;http://www.w3.org/1999/02/22-rdf-syntax-ns#&quot; xmlns:rdfs=&quot;http://www.w3.org/2000/01/rdf-...
Jobs Each job is a resource, with a URI GET to monitor status, DELETE to remove
Summing Up Summary, Additional Resources
The Talis Platform… <ul><li>Provides a standards compliant storage infrastructure for structured and unstructured metadata...
Additional Resources <ul><li>API Reference </li></ul><ul><ul><li>http://n2.talis.com/wiki/Platform_API </li></ul></ul><ul>...
Client Libraries (in various states of development) <ul><li>Moriarty </li></ul><ul><ul><li>http://code.google.com/p/moriar...
