Layar code examplesfor developersCreating augmented reality experiences for the world’s leading platformAugust 2011
Note!   •   Please note that the code examples in this presentation are       based on Layar GetPOIs API version 6.0   •  ...
Introduction   •   After you have gone through the steps as outlined in the       presentation Layar introduction for deve...
Content   •   Layar Platform Architecture   •   Layar Features Overview   •   Developer API - getPOI API   •   Feature hig...
Layar architecture                                                                                              ns      La...
Layar features Overview•   Support for both Geo-location POIs and Vision enabled POIs•   Support for icon/images/3D models...
Creating layers •       Layers are built using simple web technology •       You can use programming languages like PHP, M...
getPOI API   •   Hosted by layer developer   •   Simple API:       •   HTTP request with the following parameters         ...
Two types of POIs   •       Geo-location POI       •    POIs that are attached to a physical location with latitude, longi...
Requesthttp://devAPI.example.com/getPOIs/?countryCode=IN&lon=4.887339&timestamp=1249226148713&userId=ed48067cda8e1b985dbb8...
•   Response for Vision enabled layers {  "hotspots": [{    "id": "test_1",    "anchor": { "referenceImage": “my_Reference...
3D© Layar 2011                    Layer developed by Hoppala
Response{ "hotspots": [{   "id": "test_1",   "anchor": { "geolocation": { "lat": 52.3729, "lon": 4.93 } }, // For Geo-loca...
3D notes   •   Base format is OBJ (WaveFront format)   •   Good interchange format, most 3D programs can convert to OBJ   ...
More info on 3D POI   •   Requirements and best practices on creating 3D model.       •   Presentation: 3D Content Creatio...
User Filter SettingsRequesthttp://examplelayer/FourthTutorial_FilterSettings.php?lang=en&countryCode=NL&lon=4.94745254517&...
More Info on Filter Settings   •   Filter configuration on the Publishing site   •   Filter definition in getPOI request   •...
POI & Layer Actions                                           There’s audio...© Layar 2011                              ht...
POI & Layer Actions                                                      There’s audio...                  “uri”: “http://...
Response for Geo-location POI"actions": [{" "    "label": "Contact Layar",                    "uri": "http://layar.com/com...
Response for Vision POI"actions": [{" "    "label": "Contact Layar",                    "uri": "http://layar.com/company/c...
More Info on Actions   •   Actions API specification   •   Tutorial: Layer with Actions© Layar 2011
Layar intents© Layar 2011
Layar intents               layar://princeofpersia/?SEARCHBOX=start© Layar 2011
Layar Intents   •       Three types of intents:       •    Layar://<layername>/?action=<value>&<custom_param>=<value>&<filt...
Animations© Layar 2011
Animations    Texture animations© Layar 2011
Animations    Texture animations     Rotate© Layar 2011
Animations    Texture animations                                  Oscillate     Rotate© Layar 2011
Animation API     •    A collection of pre-defined animations on POIs.     •    Simple appearance animation (drop, grow, sp...
Response"animations": { // "animations" on a POI level. This overwrites the "animations" parameter defined on the layer lev...
Refresh rate               moving POIs                                                 © 2010, Layar B.V.               ht...
Response{"hotspots": [], "layer": "snowy4", "errorString": "ok", "morePages": false, "errorCode": 0, "nextPageKey": null, ...
Auto-triggers© Layar 2011
Auto-triggers               “actions”: [{ “label”: “ Watch”,                                “uri”: “http://splintercell.co...
User authenticationCookies!                       http://www.flickr.com/photos/mache/166940673
User authentication   •   Layar AR view behaves like a browser view   •   Cookies belonging to the getPOI URL domain are s...
Interactive layers           •   Create Relative POIs           •   User generated POIs           •   User provided feedba...
Create Relative POIs   •   POIs that are always       relative to user’s current       location   •   Useful when POI cont...
User Generated POIs   •   Dynamic layer where users can       create a POI in it.   •   Normally POI’s location is       r...
User provided Feedback   •   Dynamic layer which enables       users to provide feedback to       POIs.   •   For instance...
Sharing screenshots to developer   •   User taken screenshots can be uploaded to developer’s server.   •   URL to post scr...
Point-to-point layer   •    Dynamic layer content based on the        previous interaction   •    Async call action and us...
Play layers in any iPhone app   •   Binary code to be included in your Xcode       project   •   Simple API that opens any...
Sample code© Layar 2011
Third Party Tools   •       Instead of creating your own layer service, you can use one of the third party tools developed...
Developer support   •   The following support resources provide a wealth of information       for developers:       •   La...
Thank you
