Virtual Data Centers with OpenStack Quantum Virtual Data Centers with OpenStack Quantum Presentation Transcript

  • Building Multi-Tenant Virtual Data Centers with Quantum Lew Tucker VP/CTO Cloud Computing Cisco Systems, Inc. Twitter: @lewtuckerOpenStack Design Summit and Conference – San Francisco 2012 1
  • Healthcare Government HYBRIDIndividuals PUBLIC PRIVATE Business Media Others 2
  • VM VM Public IP Address Private IP AddressVM VM VM VM VM VM This is VM Great!Cloud Provider Internet My Startup 3
  • VM VMVM VM VM VM VM Uh, which is VM VM MY cloud?Cloud Provider Internet My Startup 4
  • AcmePepsi Coke Shazam! Cloud Provider Internet My Startup 5
  • 6
  • Provider Provider Carrier A B Shazam! Shazam! (west) (east) My Startup 7
  • Provider Provider Carrier A B Shazam! Shazam! (west) (east) Shazam! My Data Center 8
  • 9
  • • Physical Plant• Power• Cooling• Isolation• Lot’s of Servers• Lot’s of Storage• Lot’s of Cables, Networks• Lot’s of complexity 10
  • Technologies Used in the Data CenterApplication Virtual Storage IP NGN VSwitch Compute Access Aggregation Core Peering Software Machine and SAN Backbone App App OS App OS OS Virtual Device Contexts Fabric-Hosted Internet App App Storage Firewall Virtual Device App OS OS Virtualization Services Contexts OS Storage Media Secure App App Encryption Domain App OS OS Routing OS IP NGN Service Profiles Port Profiles Virtual and VN-Link Machine Global Site Line-Rate Optimization Selection NetFlow Fibre Channel Forwarding Partners Port Profiles Intrusion and VN-Link Detection Fabric App Extension App App OS OS Application OS Control (SLB+) 10G Ethernet 10G FCoE Service 4G FC Control 1G Ethernet App VM to vSwitch App OS Virtual App OS Contexts for vSwitch to HW OS FW and SLB App to HW / VM Applications VMWare Nexus 1000v MDS 9000 + UCS, MCS 7800 Nexus 5000 Nexus 7000 Nexus 7000 CRS-1 CRS-1 Xen Consolidated (or Generic w/ Nexus 2000 (w/ Cat 6500 7600 ASR 9000 Hyper-V Storage Arrays Rack or Fabric Extender as Services 6500 ASR 1000 KVM (EMC, etc.) Blade Servers) Chassis) 7600 11
  • • What do we really want in a Virtual Data Center• Can we achieve the benefits without the complexity?• What are the important abstractions?• What is exposed to application developers, what is hidden? • Specialized processor capabilities, e.g. GPUs? • Networks, subnets, routing? • VM Placement, Geographic location, region? • Access to physical network services (load balancers, firewalls, etc.)?• How can we plan for future innovation in infrastructure? 12
  • 13
  • 14
  • Objective: create what the application developer wants Application “B” Application “A” App App Web Svr Web Svr Web Svr OS OS OS OS OS VM VM 10.0.1.0/24 VM VM VM DataBase OS App Svr App Svr MemCach MemCach VM 10.0.1.0/24 OS OS OS OS VM VM VM VM Application “C” DataBase DataBase App DataBase OS OS OS OS VM VM VM VM 10.0.0.0/24 Internet Access, Management NetworkInternet and Multi-tenant Services VPNGatewa Service Provider Network Service y 15
  • A lot may actually need to be done when you are ready to deployApplication Virtual Virtual Storage Aggregation IP NGN Compute Access Peering Software Machine Access and SAN and Core Backbone App 1 AppSubscriber “A” App OS App OSApplication 1 OS Internet AppSubscriber “B” App OS App OSApplication 1 OS App App 1 App OSSubscriber “A” App OS OSApplication 2 App 2 IP NGNSubscriber “B”Application 2 Partners App 2 App App App OS Services OS OS Core 10G Ethernet ACE 10G FCoE 4G FC FW 1G Ethernet App App VM to vSwitch App App OS SSL vSwitch to HW OS OS App to HW / VM App Cisco and VMWare Nexus 1000V 3rd Party SAN + Generic Nexus 5000 Nexus 7000 7600 CRS-1 Third-Party Xen Consolidated Rack or w/ Nexus 2000 (w/ Cat 6500 ASR 9000 Applications Hyper-V Storage Arrays Blade Servers Fabric Extender as Services ASR 1000 KVM Chassis) 7600 16
  • • Compute service (EC2): virtual machines App Svr • Specify vCPU, Memory, Disk OS • Launch instance (image, mem_size, disk) VM • Suspend, clone, migrate• Storage service (S3, EBS): virtual disks • Specify storage amount, access rights • Store object • Create/attach block• What to do about networks? 17
  • 2011 Design Summit- community-driven merger of proposals … more NetworkService NaaS Core Design NetworkServicePOC NetworkContainers Citrix/Rackspace/Ni Intel NTT/Midokura Cisco cira Quantum 18
  • • Compute service (EC2): virtual machines • Launch instance (image, mem_size, disk) App Svr • Suspend, clone, migrate OS VM• Storage service (S3, EBS): virtual disks • Store object • Create/attach block• Network service (Quantum): virtual networks App Svr App Svr OS OS • Create/delete private network VM VM • Attach VM to network resource • Maintain compatibility with Nova networking model • Work with different networking environments • Address in next release (Folsom) • Routing • IP address management • Service attachment 19
  • Quantum Service API API Extensions• API for creating and managing virtual networks and services• Called by “tenants” and other OpenStack services Quantum Plug-in Framework Vendor/User Plug-In• Maps abstraction to implementation on physical network• Makes all decisions about *how* a network is implemented 20
  • User Application User API User API Network Compute Service Service Sys API Sys API System (Quantum) (Nova) Admin Plug-In Compute Data Center Network Node(s) Network Services (vSwitch)Data Center Mgmt 21
  • Portal (Horizon) Applications Other Services Cloud Platform - Developer APICompute Storage Network Identity (Keystone) (Nova) (Swift) (Quantum)Servers Disks Networks Images (Glance) Folsom Release 22
  • “Innovation above and below the line” IaaS PaaS XaaS Auto-scaling apps Innovation in the design of cloud-based applicationsCloud Platform – API Interface – Resource Abstractions Compute, Storage and Networking Infrastructure 23
  • Massive Scale Applications Cloud Platform – API Interface – Resource Abstractions Unified computing, virtual switches, overlay networks, and software defined networkingKVM, Xen, ESXi, N1Kv, Open vSwitch, LISP, VXLAN, STT, OpenFlow 24
  • Application, “I would like certain resources (of type …) certain virtual topologies, specific services” OpenStack Quantum Service Lower levels provision physical or virtual resources, setup configuration, and provide information backNetwork Service is very new – still lots to be done – and keep it simple • Span multiple data centers? • Best placement of VMs? • Network security, policies? • Quality of service? • Notion of a network container? • SLA guarantees? 25
  • • Advantages of cloud computing • On-demand virtualized resources, self- service, lower cost • Resources managed by others• Ability to create your own isolated private networks• Extensible• Challenge!! Quantum • Easy-to-use Network Service • Minus the complexity of the traditional data center • Work work with different networking infrastructure 26
  • • Incubation during this past period (Essex)• Voted to go into core with Folsom release• Publicly available implementations (plugins): • Open vSwitch, Linux Bridge, Cisco UCS/Nexus, Nicira NVP, Ryu OpenFlow• Still quite basic – but evolving quickly • L3 IP address management, subnets, routing, services• Extensions mechanism for exposing new capabilities• Stay for the following talks on Quantum • OpenStack Quantum for Cloud Operators • Panel on OpenStack Networking• http://wiki.openstack.org/Quantum 27
  • Thank You
