A Hitchhiker's Guide to the Inter-Cloud

Agenda A Quick Elevator Pitch On Inter-Cloud Thanks to David Bernstein, Glenn Dasmalchi, Doug Gourlay, James Urquhart, … 2 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Data Center Evolution Path Virtualization Cloud Computing Utility Consolidation Abstraction Automation Market Inter-Cloud Private Clouds Unified Computing Unified Fabric Data Center Networking 3 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Cisco Cloud Strategy Build Right Products Technology Unified Fabric Enhanced IP core with tight coupling to Software Unified Compute Virtualization Aware Multi-Phased Services/ Standalone Clouds to Reference SW Enterprise-Class Services-led Cloud blueprints to Reference software stacks Inter-Cloud Open Standards Accelerate Cloud deployment and federation through Cloud standards 4 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Essential Cloud Monikers a.k.a. defining clouds without defining them  Elasticity  Multi-tenancy SaaS SaaS Abstraction  Abstraction Inter-Cloud  Federation  Trust Boundary Private IaaS Cloud  Ownership Boundary Federation 5 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Cloud Adoption Phases Enterprise- Standalone Inter-Cloud Class Clouds Clouds External, Off-Premise Internal, On-Premise Key challenges: Key challenges:  Security  Federation  SLAs  Portability  Control  Market 6 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Vision—The Inter-Cloud Flexible Infrastructure and a New Application Platform Apps Integrate Services Dynamic from Multiple Clouds Workload Migration A Federation of Clouds Based on Open Standards:  Naming/Discovery  Trust  Exchange/Peering 7 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Virtual Private Inter-Cloud / CloudBursting 1. Established Trust Internal External Cloud Relationship Cloud 2. Compatible Infrastructure Multi-Tenant SP Cloud Trust Boundary (same) Vs. Internal Ownership Cloud Boundary (may be different) Seamless Extension of the Enterprise DC (IaaS) 8 8 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Systems, Inc. All rights reserved. © 2009 Cisco Confidential Cisco Confidential

Virtual Private Inter-Cloud / CloudBursting  When enterprise applications can seamlessly move between their internal & external clouds leveraging the elasticity & multi-tenancy that a cloud infrastructure offers  Extend secure data center to the cloud computing era  In order to get a portion of the SP cloud as a „seamless extension‟ of the enterprise data center, one also needs • To migrate network context like VPN/VRF, VLAN, Load Balancing, firewall/NAT, QoS and may be some port profiles (for IKV/1K/5K) and configuration (for others).  This will require a convergence of • Current ideas, as well as • A slice of new technologies (like LISP) at appropriate levels to tackle this challenge. 9 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Inter-Cloud: Key Questions  What is the “network model” ? - network-based isolation for the multitenant SP cloud - network abstractions for the enterprise tenants (seamless)  What are the “network features” that differentiate? - isolation (per above), QoS, monitoring, CPE linkages  How are the network features exposed/integrated? - control APIs (and underlying abstractions) - cloud OS linkages  To what extent will we support workload mobility? - live migration requirement? - moving workload context -Dude, where is my VM ? 10 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Inter-Cloud In A Nutshell Virtualized Enterprise- Inter-Cloud Data Centers Class Clouds Application APIs Application APIs Integration Services Compute Services  Orchestration  Select Workload   Cross Cloud: App Deployment Mobility  Load Balancing  Billing/Charge-back  Data   Fault Tolerance SLA Monitoring Access/Mobility  Workload Exchange   Identity/Presence Traffic Isolation  Address Mobility   Discovery Security  Monitoring/   Network Search Event Processing QoS  Intelligent Caching   CloudBursting Virtual Switching  Policy-Based   simpler case Cluster Selection Communications 11 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Inter-Cloud Example Dynamic Workload Migration – Simple VM Mobility Cloud 1 / Cloud 2 transport → XMPP Cloud 1 finds Cloud 2 → Naming, Presence Cloud 1 trusts Cloud 2 → Certificates, Trustsec Cloud 1/2 negotiate → Policy, Entitlement, Security, Metering Cloud 1 sets up Cloud 2 → Placement, Deployment, Format, Motion Cloud 1 sends to Cloud 2 → Transfer, Management VM Runs in Cloud 2 → Addressing, VLAN, WWN, Filesystem 12 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Inter-Cloud Example Dynamic Workload Federation – Generalized Service Access Cloud 1 / Cloud 2 transport → XMPP Cloud 1 finds Cloud 2 → Naming, Presence Cloud 1 trusts Cloud 2 → Certificates, Trustsec Cloud 1 queries Cloud 2 for Services → RDF/SPARQL, OWL Cloud 1 selects; receives protocols, interface → Web Services; REST API Cloud 1 calls services in Cloud 2 → Metering, SLAs 13 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Specific Inter-Cloud Projects  Addressing – IETF LISP  UCI – W3C,  Conversations – Google Code XMPP.org  Distributed Storage Acceleration -  Virtual Machines opencloudconsortium.org, DMTF OVF udt.sourceforge.net  Media Enablement 14 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential

Inter-Cloud Deployment Presence Placement Standards & Identity Events Naming/DNS Instrumentation Geospatial Logs Discovery Metering Protocols Trust/Certificates SLA Roadmap Management Endpoints Security Lots of Work to Policy Remote Desktop Entitlement Spice, RDP HTTP, XMPP, P2P, UDT Transport Transactions do Audit REST, XML Invocation Synchronization XML Schema, SOAP Description Orchestration Communication Cisco Strategy: use technology Users Directory Identity Search Server profiles to enable VM Management enhanced, Blob Storage Streaming Audio Block Storage Streaming Video interoperable VM Format Map/Table Model VM Mobility Query Model network based Drives Load Balancer VM Management Content Addressable Filesystem Distributed Memory services Grid / MPI Physical Platform Content (URL, Cache) Industry Message (Queue, Email) Metaphor Metaphor Associations, partnerships MAC Addresses inevitable IP Addressing Time Synchronization WWN VLAN Power Management FC Multicast iSCSI Intel VT, AMD-V VSAN VNtag Actual Physical 15 Presentation_ID © 2008 Cisco Systems, Inc. All rights reserved. Cisco Confidential
