RAC+ASM: Stories to Share

RAC+ASM 3 years in production Stories to share
Presented by: Christo Kutrovsky

Who Am I
2
Oracle ACE
10 years in Oracle field
Joined Pythian 2003
Part of Pythian Consulting Team
Special projects
Performance tuning
Critical services
“oracle pinup”

Pythian Facts
Founded in 1997
90 employees
120 customers worldwide
20 customers more than $1 billion in revenue
5 offices in 5 countries
10 years profitable private company

What Pythian does
Pythian provides database and application infrastructure services.

Agenda
5
2 nodes RAC
ASMLIB with multipathing
Migrating to new servers with ASM
Thin provisioning
ASM + restores = danger
Device naming conventions
spfile location
JBOD configuration

6
2 Node RAC for High Availability

2 Node RACs for HA
7
Two node RAC nodes
13 databases
Dev databases
Shutdown databases (and ASM) on node1
Perform maintenance
Unplug the interconnect cable
What happens?

2 nodes RAC
8
VIP
VIP
Node 1
Node 2
SID_A1
SID_A2
SID_B1
SID_B2
Interconnect
ASM
DG
Fibre Channel
OCR/V

2 nodes RAC
9
VIP
VIP
Node 1
Node 2
SID_A1
SID_A2
SID_B1
SID_B2
Interconnect
ASM
DG
Fibre Channel
OCR/V

10
I can’t
See Node 1
I can’t
See Node 2
VIP
VIP
Node 1
Node 2
SID_A1
SID_A2
SID_B1
SID_B2
Interconnect
ASM
DG
Fibre Channel
OCR/V

One is not Quorum
11
50% chance your working node gets restarted
Depends on clusterware version
Who will shoot the other guy first

One is not Quorum
12
Conclusion?
Turn off clusterware when you have only 2 nodes and performing maintenance
Upgrade to a more predicable clusterware
Lowest ‘leader’ always survives
Add a 3th tie-breaker node
doesn’t have to run a database, just clusterware (observer)

One is not Quorum
13
Production cases, what happens if
All Network dies on one node?
All disk dies on one node?

14
ASMLIBwith Multi Pathing

Building ASMLIB devices when multipathing is present
15
Devices used for creating asmlib
/dev/emcpowerc1
/dev/mapper/raid10_data_disk
Devices used to create asmdiskgroup
ASMLIB
The reboot changes everything
ASMLIB re-discovers the devices without multipath
Difficult to diagnose

Visual
16
/dev/mapper/data1
/dev/mapper/data2
/dev/sdb
/dev/sdc
/dev/sdd
/dev/sde
HBA1
HBA2
LUN_1
LUN_2

Building ASMLIB devices when multipathing is present
17
Do not use ASMLIB
If you have to (why?)
Must setup “ORACLEASM_SCANORDER”
asm_diskstring parameter
Permissions
Udev files
Boot/startup script

Removing ASMLIB
18
Why
Extra layer
Requires new driver for every new kernel
Can cause downtime if not careful
ASMLIB header is the same as ASM DISK header
Just has extra field for ASMLIB name
Disks can be accessed directly, without ASMLIB without having to drop/recreate them

Removing ASMLIB
19
Unmount all affected diskgroups
Change or set asm_diskstring
Remount diskgroups via new paths
Can be done in rolling fashion in RAC

20
SAN Migration

Migrating from EMC to 3PAR
21
New SAN
New concept
Thin provisioning
A big project
Or not

Add/drop/go home
22
No brainer
Thin provisioning rocks
SA adds disks
Add disk to diskgroup
Drop all old disks
Wait
Never be paged on space

23
Server Migration

Server migration
24
Current setup
2 nodes RAC with ASM
New servers
Better, Faster, Stronger
Fastest (effort wise) way to migrate, with minimal downtime
Possible with zero downtime

Server migration options
25
Create standby on new server
Requires extra copy of data
Add the new nodes, drop existing ones
Possible clusterware issues
Move the LUNs
Easy
New servers tested

Lun Migration
26
Install clusterware and create RAC database with same name
Test hardware / wiring / configuration
Migrate
Stop production
Re-assigning LUNs
Start production

27
ASM Restore creates database black hole

ASM + Same host restore = DANGER
28
Production database
Diskgroup +PROD
Snapshot database
Diskgroup +SNAP
Rebuild monthly via duplicate database
Except this one time…

The concept
29
“SNAP” backups not taken
If a given “SNAP” backup is to be restored, simply re-create the given “PROD” backup
Independent from Production

Restore with ASM
30
Restore FRA files into separate directory
Startup SNAP instance
Catalog backup files
Restore into SNAP diskgroup
The missing piece?“restore” writes into original backup file location
Must use “set new name for datafile” in run block

Restore with ASM – the result
31
Unrecoverable corruption on production database
Lost about 3-4 hours of changes
If this was filesystem and not ASM, no corruption would have occured

Corruption – what happened
32
SGA
5
rows
5
rows
2
rows
BLK1 add Row 6
BLK3 add Row 3
5
rows
5
rows
2
rows
2
rows
Disk
Partially overwritten datafile
5
rows
5
rows
5 rows
5 rows
REDO
Disk
Original datafile

Corruption – what should’ve hap.
33
SGA
5
rows
5
rows
5
rows
BLK1 add Row 6
BLK3 add Row 3
5
rows
5
rows
2
rows
2
rows
BLK3 add Row 6
Disk
Partially overwritten datafile
5
rows
5
rows
5 rows
5 rows
REDO
Disk
Original datafile

Corruption – what happened
34

Corruption
35
Why this wouldn’t have happened with filesystem?
File names are just pointers to data stream
If a file is re-created, a new data streams is associated with it
Processes that have the file currently open still use the old data stream
This is why “undelete” is possible
My blog about undeleting files

Corruption
Open “file 1”
36
Process 1
File 1
Stream X1

Corruption – recreate File 1
Open “file 1”
37
Process 1
File 1
Stream X1
Stream X2

38
Device names convention causes user error

39
Using /dev/mapper/<name>
Asm uses <name>p1 – first partition
Permissions set script uses: “*p1”
Then came /dev/mapper/backup1
First partition is: /dev/mapper/backup1p1

40
V$ASM_DISK
PATH HEADER_STATUS
--------------------------- -------------
/dev/mapper/backup1 CANDIDATE
/dev/mapper/redop1 MEMBER
/dev/mapper/backup1p1 MEMBER
/dev/mapper/data2p1 MEMBER
/dev/mapper/data1p1 MEMBER

Naming conventions
41
ADDED
DISK
Partition 1
IN USE

New convention
42
Now we use generic names, as we do re-assign disks
We also use prefix and suffix with a clear dilimiter
/dev/mapper/asm-raid5-dev01-part1

43
spfile location in RAC

spfile location
44
Intended configuration
init.oraspfile=‘+ASM_DSKGRP/dbname.spfile’
no spfile

Changing parameters in masses
45
create pfile=‘your_initials.ora’ from spfile;
edit
create spfile=‘+ASM_DSK/spfile’ from pfile=‘ck.ora’

What not to do
46
create pfile from spfile
edit
create spfile from pfile;

Result
47
One node uses local spfile
Other(s) uses global spfile
Parameter changes to “BAD” node are sent to other nodes
not persistent on GOOD nodes
persistent on BAD nodes
Paramer changes on GOOD nodes have reversed behaviour

48
Adding ASM disks crashes databases

Adding disks
49
Must be visible on all servers
Otherwise your diskgroup gets dismounted on the nodes that don’t see the disk
All databases using this diskgroup crash

ASM add disk process
50
Is the disk visible locally?
Initialize disk header, add it to diskgroup
Notify all nodes to rescan disks and add the new disk
If one or more nodes cannot see the disk, raise error
Dismount diskgroup on all nodes not seeing the new disk

51
ASM with JBODwelcomes simplicity

JBOD Configuration
52
Linux Datawarehouse
10 TB space
28 disks of 430/285 GB
All redundancy/striping provided by ASM

JBOD Configuration
53
Simplicity
No ASMLIB
Straight devices
Naming convention – use only 1 partition, and use partition 4
/dev/sd*4
is ASM partition
is permissions wildcard
is asm_diskstring

Testing your speed
54
Verify read speed of each device
Verifies each device is performing as expected
Verify read speed from all devices
Verify your total bandwith
Verify read speed from all devices, towards the end of the device
Disk read speed is not linear

Read Speed of a single disk
55
* Courtesy google image search

Testing your speed
56
One device at a time
for dsk in /dev/sd[c-q]; do echo $dsk; dd if=$dsk of=/dev/null iflag=direct bs=2M count=100; done
All devices (total bandwith)
for dsk in /dev/sd[c-q]; do echo $dsk; dd if=$dsk of=/dev/null iflag=direct bs=2M count=100 &; done
Test end speed
Add SKIP=x

Sample output
57
/dev/sdc100+0 records in100+0 records out209715200 bytes (210 MB) copied, 1.60325 seconds, 131 MB/s/dev/sdd100+0 records in100+0 records out209715200 bytes (210 MB) copied, 1.60188 seconds, 131 MB/s/dev/sde100+0 records in100+0 records out209715200 bytes (210 MB) copied, 1.60067 seconds, 131 MB/s/dev/sdf100+0 records in100+0 records out209715200 bytes (210 MB) copied, 1.59928 seconds, 131 MB/s/dev/sdg100+0 records in100+0 records out

JBOD configuration
58
Disk adding/removal is very easy
Add disks in bulk:alter diskgroup XXX add disk ‘/dev/sd[c-q]4’;
Performance rocks
controller speed
Diagnostic is easy
Iostat –x 5 /dev/sd*4
Manageability is easy
1 diskgroup – no filenames, no mountpoints

Final Thoughts
59
RAC for HA requires 3 nodes
ASM
Keep it simple
Reduce layers
Runs fast
Still need to be carefull

60
The End
Thank You
Questions?
I blog at
http://www.pythian.com/news/author/kutrovsky/
