Cooking with ChefServer management made easy
Me?Ken RobertsonSenior Software Engineer at InvolverInvolver builds a social media marketing platformSpecialize in our pla...
Our Chef Usage10 separate environments120+ serversAll managed with ChefOne Operations Engineer, Two Developers
What is Chef?Server management and configuration in RubyDeveloped by OpsCodeAdopted by Engine Yard, 37signals, and moreApa...
Chef isn’t aloneCFEngine: http://cfengine.com/Puppet: http://www.puppetlabs.com/http://en.wikipedia.org/wiki/Comparison_of...
Why use Chef?Repeatable system provisioningManual tweaks are not repeatableEase scalingAvoid vendor lock-in
Chef is RepeatableContinuous configuration managementEnsure system complianceRecovery from failures
Chef Flavorschef-solo    Single instancechef-server    Cluster, centrally managed
Chef’s ToolkitCookbooks  RecipesAttributes
Recipes areeverywhere!Open source - Engine Yard, 37signals, OpsCodeOne offs for specific configurationsApproach with caution
Recipe ingredients:Sub-recipesResourcesAttributesDefinitionsStatic resourcesTemplates
Resources
Resources - Examplesexecute "some-descriptive-text" do  command "uptime"end
Resources - Exampleslink "/usr/local/bin/foo" do  to "/usr/src/foo-#{version}/bin/foo"end
Resources - Examplesdirectory "/home/foo/apps/bar" do  owner "foobar"  group "foobar"  recursive trueend
Resources - Examplespackage "mongodb"  version "1.2.3"  action :installend
Resources - Examplespackage "mongodb"  action :install, :upgradeend
Resources - Examplesservice "nginx" do  supports :status => false, :start => true,           :restart => true, :reload => ...
Resources - Examplescookbook_file "/etc/profile" do  owner "root"  group "root"  mode 644  source "profile"end
Resources - Examplescookbook_file "/etc/profile" do  owner "root"  group "root"  mode 644  source "http://safesite.com/fil...
Resources - Examplestemplate "/etc/hosts" do  owner "root"  group "root"  mode 644  source "hosts.erb"  variables(:one => ...
Resources - Examplescron "clear_tmp_files_older_than_a_day" do  hour    0  minute 0  user    "root"  command "do_something...
Resources - Conditionsexecute "install-rubygems-for-jruby" do  command %Q{    curl http://production.cf.rubygems.org/rubyg...
Results/Expectationsexecute install passenger and nginx do  command %Q{       wget -N http://site/file.tar.gz &&       tar...
Triggerstemplate "/etc/nginx/apps/#{params[:name]}.conf" do  source "#{params[:name]}.nginx.erb"  owner node[:user]  group...
Triggersexecute "mysql-create-database" do  ...  action :nothingendtemplate "/tmp/mysql-#{params[:name]}.sql" do  source "...
AttributesRuntime configuration valuesDefine defaultsPass in at runtime (as JSON)Available through through the ‘node’ vari...
Default Attributescookbooks/myrecipe/attributes/*.rb:nginx_user "www-data"nginx_port "80"  => node[:nginx_user]  => node[:...
Merging Attributesdefault.mysql[:bindir] = /usr/local/mysql,default.mysql[:root] = /data/mysql,default.mysql[:uid] = mysql...
Runtime Attributes{    "nginx_user": "www-data",    "nginx_port": 80,    "nginx": {      "user": "www-data",      "port": ...
Runtime Attributes{    "mysql": {      "version": "5.1.47",      "config": {        "log_slave_updates": true,        "aut...
DefinitionsMini-recipesRepeatable blocks or sub-functionsDefinitions sub-directory of recipecookbooks/myrecipe/definitions
Definitionslink "/usr/local/bin/foo" do  to "/usr/src/foo-#{version}/bin/foo"end
Definitionsfor db in node[:mysql][:databases] do  mysql_database db[:name] do    root_user node[:mysql][:root_user] || roo...
Definitionsdefine :mysql_database do  execute "mysql-create-database" do    ...    action :nothing  end  template "/tmp/my...
Definitionsdefine :nginx_site do  include_recipe "nginx"  template "/etc/nginx/apps/#{params[:name]}.conf" do    source "#...
Recipe GotchasIdempotency
Idempotencyexecute "install-jruby" do  command %Q{    curl http://urlto/#{version}/jruby-src-#{version}.tar.gz -O &&    ta...
Idempotency - Fixedexecute "install-jruby" do  command %Q{    curl http://urlto/#{version}/jruby-src-#{version}.tar.gz -O ...
Recipe GotchasIdempotencyPackage sources
Recipe GotchasIdempotencyPackage sourcesInstall vs upgrade
Install vs Upgradepackage “git-core” do  action :installendpackage “git-core” do  action :install, :upgradeend
Recipe GotchasIdempotencyPackage sourcesInstall vs upgradeAttribute abuse
Recipe GotchasIdempotencyPackage sourcesInstall vs upgradeAttribute abuseCowboys and Homers
Homerpackages.each do |pkg|  package pkgendexecute "Nuke existing installs" do  command "rm -rf /etc/tinydns /etc/dnscache...
CowboysOne offsLack of testingManual, undocumented changes
DEMO
Much more!Chef-serverSearchingTaggingLibraries
ResourcesOpsCode: http://www.opscode.com/Chef Wiki: http://wiki.opscode.com/37signals recipes:http://github.com/37signals/...
Me!Twitter: @krobertsonBlog: http://invalidlogic.com/Email: ken@invalidlogic.com
Questions?
