CERAMICS Carasco, Allan Gabriel Doliente, Lorenzo Miguel Jacinto, Stephanie Villanueva, Von Kirby
Ceramics <ul><li>One of the largest groups of materials with the properties of nonmetals and all are made by firing or bur...
Ceramic materials are attractive for several reasons : <ul><li>Cheap in terms of its starting materials. </li></ul><ul><li...
History <ul><li>The art of making pottery by forming and burning clay has been practiced from the earliest civilizations. ...
Ceramics Industry <ul><li>An important characteristic of the ceramics industry is that it is basic to the successful opera...
Uses of Ceramics <ul><li>The ceramics industry is divided in the manufacture of the ff. products: </li></ul><ul><ul><li>St...
Classifications of the  Ceramics <ul><li>Traditional Ceramics </li></ul><ul><li>New Ceramics </li></ul>
Ceramic Tile Processes Raw Material Weighing Ball Milling Vibrating Screen and HomoTank Spray Dryer Powder Storage (SILO) ...
Raw Materials <ul><li>The traditional ceramics industry is largely based on various combinations of clay minerals, feldspa...
Raw Materials <ul><li>Oxygen, silicon, and aluminum together account for 90% of the elements in the earth’s crust , These,...
Raw Materials <ul><li>Clay Minerals </li></ul><ul><li>Talc and Related Minerals </li></ul><ul><li>Silica and Silicate Mine...
Common Types of Clay <ul><li>Kaolin or China Clay  </li></ul><ul><li>Ball Clays </li></ul><ul><li>Fire Clays </li></ul><ul...
Important Characteristics of Clays in Ceramic Bodies <ul><li>Clays have the ability to form clay-water composition and to ...
Talc and Related Minerals <ul><li>Talc is a hydrous magnesium silicate which has a layer structure similar to that of the ...
Talc and Related Minerals <ul><li>Pyrophyllite  </li></ul><ul><li>Block talc  </li></ul><ul><li>Asbestos  </li></ul>
Silica and Silicate Minerals <ul><li>Silica is a major ingredient in glass, glazes, enamels, refractories, abrasives, and ...
Silica and Silicate Minerals <ul><li>The major source of silica for the ceramic industry is sandstone, consisting of light...
Feldspars and Related Minerals   <ul><li>Feldspar are anhydrous aluminosilicates containing K+, Na+, and Ca2.; they are pr...
Feldspars and Related Minerals <ul><li>Nepheline syenite </li></ul><ul><li>Wollastonite </li></ul><ul><li>Sillimanite  </l...
Refractory Raw Materials   <ul><li>Alumina </li></ul><ul><li>Magnesia </li></ul><ul><li>Dolomite </li></ul><ul><li>Chrome ...
Other Raw Materials <ul><li>Soda ash </li></ul><ul><li>Borate minerals </li></ul><ul><li>Fluorspar </li></ul><ul><li>Phosp...
Ball Milling <ul><li>Spheres mixed with the stock to be comminuted are rotated inside a large cylindrical container. </li>...
Ball Milling Stock Balls Drive rolls Container
Spray Dryer <ul><li>Characterized by atominization of a solution or suspension into droplets, followed by drying. </li></ul>
Spray Dryer Schematic Diagram of Spray Dryer Particle Trajectory
Dry Pressing <ul><li>Forming of the “greenware” tile body. </li></ul><ul><li>Non-clumping granulates are compressed in ste...
Glazing <ul><li>The application of glassy coatings on ceramic wares to give them decorative finishes and to make them impe...
Roller Hearth Kiln <ul><li>A roller tunnel kiln for firing a drying refractory material advanced along the refractory rota...
Roller Hearth Kiln Firing zone  Gear system Entrance
Traditional Ceramic  Processes <ul><li>Preparation of Raw Materials </li></ul><ul><ul><li>Crushing </li></ul></ul><ul><ul>...
Crushing Jaw Crusher Gyratory Crusher Roll Crusher Hammer Mill
Traditional Ceramic  Processes <ul><ul><li>Grinding </li></ul></ul><ul><ul><li>Types of Equipments Used </li></ul></ul><ul...
Grinding Ball Mill Roller Mill Impact Grinding
Traditional Ceramic  Processes <ul><li>B. Shaping Processes </li></ul><ul><ul><ul><li>Slip Casting </li></ul></ul></ul><ul...
Drain Casting
Traditional Ceramic  Processes <ul><ul><ul><ul><ul><li>Mechanized </li></ul></ul></ul></ul></ul><ul><ul><ul><ul><ul><li>Ji...
Semidry Pressing
Traditional Ceramic  Processes <ul><li>Drying </li></ul><ul><li>Firing </li></ul><ul><li>Glazing </li></ul>
New Ceramic  Processes <ul><li>Preparation of Raw Materials </li></ul><ul><ul><ul><li>Freeze Drying </li></ul></ul></ul><u...
New Ceramic  Processes <ul><li>Sintering </li></ul><ul><ul><ul><li>To bond individual grains into a solid mass </li></ul><...
New Ceramic  Processes Doctor blade Process
Factors Affecting Ceramic Process <ul><li>Oxidation </li></ul><ul><li>Decomposition Reactions </li></ul><ul><li>Phase Tran...
Common Errors in Ceramic Process <ul><li>Firing Shrinkage </li></ul><ul><li>Warping </li></ul>
