ruote - open source ruby workflow and bpm engine Developed by John Mettraux jmettraux.wordpress.com Presented by Kenneth Kalmer in 20 minutes opensourcery.co.za

Workflows? BPM? “Improved state machine” Long running processes, long-lived process interpreter Diverse participants Complex rules & decisions Implement clearly defined business processes

“Improved state machine”

Long running processes, long-lived process interpreter

Diverse participants

Complex rules & decisions

Implement clearly defined business processes

Joe's Mortgages Applies on your behalf at seven different institutions Selects the best deal for you Handles application for you You sign You buy You pay

Applies on your behalf at seven different institutions

Selects the best deal for you

Handles application for you

You sign

You buy

You pay

State Machine :requested :evaluation :acquired :accepted :applied :approved Where? When? Rate? Comparison? Who?

:requested

:evaluation

:acquired

:accepted

:applied

:approved

Where?

When?

Rate?

Comparison?

Who?

Rule: Notify Client when 4 quotes are received aasm_state :pending_four_left aasm_state :pending_three_left aasm_state :pending_two_left aasm_state :pending_one_left aasm_state :pending_but_notified_client ... aasm_state :is_this_ridiculous_or_what?

Rule: Wait up to 7 days for quotes aasm_state :pending_four_remaining_timeout aasm_state :pending_three_remaining_timout aasm_state :pending_two_remaining_timout aasm_state :pending_one_remaining_timout … aasm_state :call_recruiter_for_new_dev!

Recap State machines are only valuable when they have a few, well defined states Tempted to setup hundreds of states, with complex transitions State machines help manage the results of real life processes, not the processes

State machines are only valuable when they have a few, well defined states

Tempted to setup hundreds of states, with complex transitions

State machines help manage the results of real life processes, not the processes

Modified State Machine class Mortgage aasm_initial_state :pending aasm_state :pending aasm_state :quoted aasm_state :applied aasm_state :approved aasm_state :rejected end

Enter ruote Clearly defined DSL for workflow Clearly defined processes Expressions Participants Concurrent tasks Timeouts Easy decision making

Clearly defined DSL for workflow

Clearly defined processes

Expressions

Participants

Concurrent tasks

Timeouts

Easy decision making

Expressions Utility statements that give structure to your processes Conditional statements that facilitate branching and merging patterns

Utility statements that give structure to your processes

Conditional statements that facilitate branching and merging patterns

Participants A point in the process where work gets done Can be automated code Can be human interaction Ruote provides plenty of participants out the box Breeze to write new ones

A point in the process where work gets done

Can be automated code

Can be human interaction

Ruote provides plenty of participants out the box

Breeze to write new ones

First round: Participants class MortgageApplication < OpenWFE::ProcessDefinition sequence do institution_1 :activity => 'Mortgage Quote' institution_2 :activity => 'Mortgage Quote' institution_3 :activity => 'Mortgage Quote' institution_4 :activity => 'Mortgage Quote' institution_5 :activity => 'Mortgage Quote' institution_6 :activity => 'Mortgage Quote' institution_7 :activity => 'Mortgage Quote' end end

Problems so far Will request quotations in serial 14 days to complete if each institution takes 2 days on average

Will request quotations in serial

14 days to complete if each institution takes 2 days on average

Concurrency! Not the Erlang kind, the business kind Send all requests in one go, and continue the process once we've received at least 4 quotes Also, quote process may not take longer than 7 days to complete

Not the Erlang kind, the business kind

Send all requests in one go, and continue the process once we've received at least 4 quotes

Also, quote process may not take longer than 7 days to complete

Second round: Concurrency and Timeout class MortgageApplication < OpenWFE::ProcessDefinition sequence do timeout :after => '7d' do concurrence :count => 4 do institution_1 :activity => 'Mortgage Quote' institution_2 :activity => 'Mortgage Quote' institution_3 :activity => 'Mortgage Quote' institution_4 :activity => 'Mortgage Quote' institution_5 :activity => 'Mortgage Quote' institution_6 :activity => 'Mortgage Quote' institution_7 :activity => 'Mortgage Quote' e nd end end end

Achievements so far Quotations requested simultaneously Process will take 7 days at most to complete First 4 institutions stand the chance of earning new business Mortgage is still “pending”

Quotations requested simultaneously

Process will take 7 days at most to complete

First 4 institutions stand the chance of earning new business

Mortgage is still “pending”

Rule: Joe can re-request quotes Joe drives a hard bargain Can request quotes any number of times But, wants to let the client know he's doing his best!

Joe drives a hard bargain

Can request quotes any number of times

But, wants to let the client know he's doing his best!

Third round: Bargain hard class MortgageApplication < OpenWFE::ProcessDefinition sequence do loop do concurrence :timeout => '7d', :count => 4 do institution_1 :activity => 'Mortgage Quote' # ... e nd joe :activity => 'Review quotes' _break :if => “${f:joe_happy}” email :activity => “Getting new quotes”, :to => “${f:client.email}” end end end

Achievements so far Loop used to keep the quote request process running until Joe is happy, or cancels the process Client notified everytime the quote request process starts all over again First glimpse of workitems Mortgage is still “pending”

Loop used to keep the quote request process running until Joe is happy, or cancels the process

Client notified everytime the quote request process starts all over again

First glimpse of workitems

Mortgage is still “pending”

Workitems? The internal “message” passed from participant to participant They're JSON friendly Ruby hashes Participants can modify workitems Processes can be launched with an initial payload, client details in this case, which is accessed through the workitems Workitem attributes accessed in process definitions through the “dollar notation”

The internal “message” passed from participant to participant

They're JSON friendly Ruby hashes

Participants can modify workitems

Processes can be launched with an initial payload, client details in this case, which is accessed through the workitems

Workitem attributes accessed in process definitions through the “dollar notation”

Quote found, action the client class MortgageApplication < OpenWFE::ProcessDefinition sequence do loop do # ... end secretary :activity => “Send client application forms” end end

Application received, apply at institution class MortgageApplication < OpenWFE::ProcessDefinition sequence do # ... secretary :activity => “Send client application forms” participant :ref => “${f:selected_institution}”, :activity => “Apply for mortgage” end end

Achievements so far Dynamic participant specification from workitem attributes Another human participant Mortgage now in “applied” state

Dynamic participant specification from workitem attributes

Another human participant

Mortgage now in “applied” state

Let Joe Know Joe reviews the results of the application, and notifies the client Might attempt to restart the entire process

Joe reviews the results of the application, and notifies the client

Might attempt to restart the entire process

Joe has last say class MortgageApplication < OpenWFE::ProcessDefinition sequence do # ... participant :ref => “${f:selected_institution}”, :activity => “Apply for mortgage” joe :activity => “Review application results” end end

What happens here? Joe will inform the client of the institutions response Mortgage will stay in “applied” state, or move to “approved”/”rejected” states Process ends

Joe will inform the client of the institutions response

Mortgage will stay in “applied” state, or move to “approved”/”rejected” states

Process ends

Possibilities from here Automated decision making Decision tables Better conditional tests Automated response processing, streamlines the feedback loop and decision making Harass institutions that don't respond within 2 days of process timeout Joe improves his handicap

Automated decision making

Decision tables

Better conditional tests

Automated response processing, streamlines the feedback loop and decision making

Harass institutions that don't respond within 2 days of process timeout

Joe improves his handicap

Ruote & AASM Great combination Ruote handles business logic, AASM the state AASM becomes skinny, ruote stays declarative

Great combination

Ruote handles business logic, AASM the state

AASM becomes skinny, ruote stays declarative

More ruote: Listeners Start process, or wait for Messages from SQS Jabber messages Atom feed entries

Start process, or wait for

Messages from SQS

Jabber messages

Atom feed entries

More ruote: Cancel, cursors, replay & redo When processes are cancelled, run sub-processes for “cleanup” tasks Replay failed steps Redo steps based on conditions Jump to any point in the workflow using cursors

When processes are cancelled, run sub-processes for “cleanup” tasks

Replay failed steps

Redo steps based on conditions

Jump to any point in the workflow using cursors

More ruote: ruote-fluo Graphical representation of process definitions Edit process definitions on the fly

Graphical representation of process definitions

Edit process definitions on the fly

More ruote: Active*Participants ActiveRecordParticipant Save workitem information in database ActiveResourceParticipant Interact with any Rails resource as DHH intended you to do

ActiveRecordParticipant

Save workitem information in database

ActiveResourceParticipant

Interact with any Rails resource as DHH intended you to do

Shameless Self Promotion Developed the JabberParticipant and JabberListener now bundled with ruote Added support for daemonizing ruote-rest In talks on refactoring ruote-rest to become preferred “Rails-friendly” implementation of ruote

Developed the JabberParticipant and JabberListener now bundled with ruote

Added support for daemonizing ruote-rest

In talks on refactoring ruote-rest to become preferred “Rails-friendly” implementation of ruote

Summary Process definitions built up from expressions Expressions are “steps in the workflow” Participants perform explicit function during workflow Workitems used as “internal messaging” mechanism between expressions/participants The best complement to any state machine implementation Simplifies complex business process implementations You have full control over the entire process

Process definitions built up from expressions

Expressions are “steps in the workflow”

Participants perform explicit function during workflow

Workitems used as “internal messaging” mechanism between expressions/participants

The best complement to any state machine implementation

Simplifies complex business process implementations

You have full control over the entire process

Thank You opensourcery.co.za @kennethkalmer openwferu.rubyforge.org #ruote on Freenode groups.google.com/group/openwferu-users @jmettraux
