Using Q4M
a message queue storage engine for MySQL


           Cybozu Labs, Inc.
             Kazuho Oku
Background




                            2
Apr 22 2009     Using Q4M
Who am I?

   Name: Kazuho Oku (奥一穂)
   Original Developer of Palmscape / Xiino
        The oldest web browser for Palm...
About Cybozu, Inc.

   Japan’s largest groupware vendor
        Mostly provides as software products, not as
         se...
About Pathtraq

   Started in Aug. 2007
   Web ranking service
        One of Japan’s largest
        like Alexa, but ...
Design Goals of Q4M

   Robust
        Do not lose data on OS crash or power failure
   Fast
        Transfer thousand...
What is a Message Queue?




                                         7
Apr 22 2009            Using Q4M
What is a Message Queue?

   Middleware for persistent asynchronous
    communication
        communicate between fixed ...
Minimal Configuration of a MQ

   Senders and receivers access a single
    queue




               Sender              ...
MQ and Relays

   Separate queue for sender and receiver
   Messages relayed between queues



                         ...
Merits of Message Relays

   Destination can be changed easily
        Relays may transfer messages to different
       ...
Message Brokers

   Publish / subscribe model
        Separation between components and their
         integration
     ...
What about Q4M?

   Q4M itself is a message queue
   Can connect Q4M instances to create a
    message relay
   Provide...
Performance of Q4M

   over 7,000 mess/sec.
        message size: avg. 512 bytes
        syncing to disk
   Outperform...
Applications of Q4M




                                    15
Apr 22 2009          Using Q4M
Asynchronous Updates

   Mixi (Japan's one of the largest SNS)
    uses Q4M to buffer writes to DB, to
    offload peak d...
Connecting Distant Servers

   Pathtraq uses Q4M to create a relay
    between its database and content
    analysis proc...
To Prefetch Data

   livedoor Reader (web-based feed
    aggregator) uses Q4M to prefetch data
    from database to memca...
Scheduling Web Crawlers

   Web crawlers with retry-on-error
   Sample code included in Q4M dist.
                      ...
Delayed Content Generation

   Hatetter(RSS feed-to-twitter-API
    gateway) uses Q4M to delay content
    generation
   ...
User Notifications

   For sending notifications from web
    services


                              DB


             ...
Installing Q4M




                               22
Apr 22 2009       Using Q4M
Installing Q4M

   Compatible with MySQL 5.1
   Download from q4m.31tools.com
        Binary releases available for som...
Configuration Options of Q4M

   --with-sync=no|fsync|fdatasync|fcntl
        Controls synchronization to disk
        ...
Q4M Basics




                            25
Apr 22 2009     Using Q4M
The Model

        Various publishers write to queue
        Set of subscribers consume the entries in queue



        ...
Creating a Q4M Table

    ENGINE=QUEUE creates
                                mysql> CREATE TABLE qt (
                 ...
Modifying Data on a Q4M Table

    No restrictions for
                                mysql> INSERT INTO qt (id,message)...
SELECT from a Q4M Table

   Works the same as
                                  mysql> SELECT * FROM qt;
                ...
Calling queue_wait()

    After calling, only one
                                       mysql> SELECT * FROM qt;
       ...
OWNER Mode and NON-OWNER Mode

   In OWNER mode, only the OWNED row
    is visible
              OWNED row becomes invis...
Returning to NON-OWNER mode

    By calling
                                     mysql> SELECT QUEUE_ABORT();
           ...
Consuming a Row

    By calling
                                mysql> SELECT queue_wait('qt');
                         ...
Writing a Subscriber

    Call two functions: queue_wait, queue_end
    Multiple subscribers can be run concurrently
   ...
Writing a Subscriber (cont'd)

   Or call queue_wait as a condition
        Warning: conflicts with trigger-based insert...
The Model – with code

                    INSERT INTO queue ...



                            Publisher
                ...
Three Functions in Detail




                                          37
Apr 22 2009            Using Q4M
queue_wait(table)

   Enters OWNER mode
   0〜1 row becomes OWNED
        Enters OWNER mode even if no rows were
       ...
Revisiting Subscriber Code

   Calls to queue_end just before
    queue_wait can be omitted


   while (true) {
     rows...
Conditional queue_wait()

   Consume rows of certain condition
        Rows that do not match will be left untouched
   ...
queue_wait(tbl_cond,[tbl_cond…,timeout])

   Accepts multiple tables and timeout
   Data searched from leftmost table to...
Functions for Exiting OWNER Mode

   queue_end
        Deletes the owned row and exits OWNER mode
   queue_abort
      ...
Relaying and Routing Messages




                                              43
Apr 22 2009               Using Q4M
The Problem

   Relay (or router) consists of more than 3
    processes, 2 conns
   No losses, no duplicates on crash or...
Internal Row ID

   Every row have a internal row ID
        invisible from Q4M table definition
        monotonically ...
queue_rowid()

   Returns row ID of the OWNED row (if
    any)
        Returns NULL if no row is OWNED
   Call when ret...
queue_set_srcid(src_tbl_id, mode, src_row_id)

   Call before inserting a row to destination
    table
        Checks if...
Pseudo Code

   Relays data from src_tbl to dest_tbl
   while (true) {
    # wait for data
    SELECT queue_wait(src_tbl)...
q4m-forward

   Simple forwarder script
        installed into mysql-dir/bin

   usage: q4m-forward [options] src_addrde...
Limitations and the Future of Q4M




                                                  50
Apr 22 2009                 Usi...
Things that Need to be Fixed

   Table compactions is a blocking
    operation
        runs when live data becomes <25% ...
Future of Q4M

   2-phase commit with other storage
    engines (maybe)
        queue consumption and InnoDB updates can...
Thank you

              http://q4m.31tools.com/




                                        53
Apr 22 2009          Using...
