  • 1. Scalarium and CouchDBJonathan Weiss@jweiss@scalariumPeritor GmbH
  • 2. Scalarium.comEC2 Cluster Management   Automatic & dynamic configuration over lifetime of a cluster via Chef runs   Self healing clusters   Auto scaling clusters   One click deployment   One click cluster cloning   Monitoring & alerting   Logs & accounting   Firewalls & backups   Access & rights management 2
  • 3. Use case wooga.com One of wooga’s Facebook games   1.5 million DAU (Daily Active Users)   ~ 130 servers   ~ 150.000 requests per minute on average   Complex stack with different databases and replication   Multiple deployments of the game on multiple clusters 3
  • 4. Scalarium.comhttp://www.flickr.com/photos/av8pix/3391322123/ 4
  • 5. DataRather static but important Dynamic and non-critical   Cluster configuration   Accounting & events   Server descriptions   Monitoring and metering and current state   Lifecycle events: setup, deploy, configure, shutdown   Applications and deployment definitions   EC2 assets like EBS, elastic IPs, SSH keys 5
  • 6. DataRather static but important Dynamic and non-critical 6
  • 7. Why CouchDB? High Availability Easy Replication Clustering Robustness Short Recovery Time Jan Lehnardt 7
  • 8. Architecture 8
  • 9. Architecture 9
  • 10. Interaction 10
  • 11. SimplyStoredRuby library with ActiveRecord inspired capabilities   Models   Associations  Generates map & reduce   Validations   Callbacks   Dynamic finders   S3 attachments   Paranoid deletehttp://github.com/peritor/simply_stored 11
  • 12. SimplyStored 12
  • 13. SimplyStored 13
  • 14. Conflict & Resolution 14
  • 15. Conflict & ResolutionRe-load and retry: Automatically done by SimplyStoredDiscard and report: Internal report 15
  • 16. RockingChairIn-memory CouchDB as a Ruby library   Just a big Hash   Understands views generated by SimplyStored   Speeds up your tests   Tests can run in parallel   Nice for debugginghttp://github.com/jweiss/rocking_chair 16
  • 17. Operations 17
  • 18. BackupSlaves in different EC2 availability zones and regionsOffsite copy of data and index files 18
  • 19. Hot Standby 19
  • 20. Cold Standbyhttp://www.flickr.com/photos/dnkemontoh/2680822579 20
  • 21. Keeping views fresh Cronjobs for crawling all design docs and calling all views On master & standby! Rollout new views without using them first And while we are there, compact views&dbs 21
  • 22. Performance 22
  • 23. I/OCouchDB heavily depends on file system I/O   EBS RAIDs for better performance   Different volumes for data and indices   Be generous with RAM & CPUhttp://www.flickr.com/photos/walkn/5471945439 23
  • 24. include_docs Nice feature to load related data in one go…but slow  random I/O on read Emit the data you need to the view index 24
  • 25. Design Documents Maintained in a framework/model-layer Using md5 of content to decide if update needed Whenever one view definition changed, all views got recomputed 25
  • 26. Design DocumentsSeparate design document per viewFine granular control   Update   Delete   Compact 26
  • 27. One DB to rule them all 27
  • 28. Separate DBs 28
  • 29. Wishlist Build-in caching include_docs to load from index Improved performance of building views Build-in solution for automatic sharding Automatic compaction Metrics & monitoring 29
  • 30. Couchbase 2.0 30
  • 31. Q&ATalk to us if you want to use Scalarium 3 month for free @scalarium 31
