MongoDB on EC2 and EBS Presentation Transcript

  • 1. MongoDB on Amazon Web Services
    Webinar 3-14-2011
  • 2. Agenda
    MongoDB deployment components
    Amazon EC2 infrastructure
    Deployment scenarios
  • 3. Mongodb components
  • 4. MongoDB Components
    • Actual data
    • 5. Needs RAM + Disk IO
    • 6. Can run as Arbiter
    • 7. No data
    • 8. Just votes to elect primary
    • 9. Stateless router
    • 10. Typically run on App Servers
    • 11. Stores sharding configuration
    • 12. Stores small amounts of data
    • 13. Infrequently queried/updated by MongoS
  • Replica Sets
    Primary
    Primary
    Primary
    Secondary
    Secondary
    Secondary
    Secondary
    Arbiter
    Secondary
    Secondary
    Secondary
  • 14. Sharding
    MongoD
    MongoD
    MongoD
    MongoD
    MongoS
    MongoS
    MongoS
    ConfigD
    MongoD
    MongoD
    MongoD
    MongoD
    ConfigD
    ConfigD
    MongoD
    MongoD
    MongoD
    MongoD
  • 15. Amazon EC2
  • 16. Amazon EC2 Instance Types
    32-bit = Don’t Use
    Typical MongoD
    ConfigD/ Arbiter
    Big MongoD
    32-bit = Don’t Use
    High CPU not necessary
  • 17. OS
    Turn off atime
    Raise file descriptor limits
    cat >> /etc/security/limits.conf << EOF
    * hard nofile 65536
    * soft nofile 65536
    EOF
    DO NOT use large VM pages
    Use ext4, xfs
    Use RAID
    RAID10 on MongoD
    RAID1 on ConfigbDB
    Warning! Known problems with Ubuntu 10.04 & EBS
    https://bugs.launchpad.net/ubuntu/+source/linux-ec2/+bug/614853
    https://bugzilla.kernel.org/show_bug.cgi?id=16991
  • 18. Mongodb components on ec2
  • 19. MongoD on EC2
    MongoD
    64-Bit EC2 Instance
    LVM or
    MDADM
    RAID 10
    EBS Volumes
  • 20. MongoS on EC2
    Language Specific Driver
    Your App
    32- or 64-Bit EC2 Instance
    (Typically your app server)
    MongoS
  • 21. Arbiter on EC2
    64-Bit EC2 Instance
    (Micro Instance is Fine)
    Arbiter
    Local Instance Storage
  • 22. ConfigDB on EC2
    64-Bit EC2 Instance
    (Micro Instance is Fine)
    ConfigDB
    LVM or MDADM
    RAID 1
    EBS Volumes
  • 23. Deployment Scenarios
  • 24. 3-Node Replica Set
    Your App
    Large
    Large
    Large
    MongoD
    (Primary)
    MongoD
    (Secondary)
    MongoD
    (Secondary)
    RAID 10
    RAID 10
    RAID 10
  • 25. 2-Nodes + Arbiter
    Your App
    Large
    Large
    Micro
    MongoD
    (Primary)
    MongoD
    (Secondary)
    Arbiter
    RAID 10
    RAID 10
  • 26. 3-Node Replica Set
    Your App
    US West
    US East
    Large
    Large
    Large
    MongoD
    (Primary)
    MongoD
    (Secondary)
    MongoD
    (Secondary)
    Priority = 0
    RAID 10
    RAID 10
    RAID 10
  • 27. Config DB
    Sharding
    Amazon ELB
    App Tier
    Shard 2
    Shard 1
    Shard 3
  • 28. Running in ec2
  • 29. Operational Considerations
    Automating Deployment
    Puppet
    Chef
    Amazon CloudFormation
  • 30. Backup / Restore
    EBS Snapshots
    Also for rapid replica provisioning
    LVM Snapshots
    Use secondaries for zero downtime backups
    http://www.mongodb.org/pages/viewpage.action?pageId=19562846
  • 31. Security Groups
    • All nodes listen on all interfaces unless –bind_ip is specified
    • 32. Specify alternate port with –port
    • 33. Don’t mix names & IP’s. Names preferred
    • 34. Use security groups as access control lists
    • 35. (e.g. allow 27017 from app servers, but not everybody)
  • Final thoughts
    EC2 is a great platform for Mongo
    Lots of production use
    Try it out! Test a big cluster for cheap!
    We’re here to help!
  • 36. Questions?
    I am
    Jared Rosoff (jsr@10gen.com) @forjared
    Try it out!
    http://www.mongodb.org/downloads
    http://www.mongodb.org/display/DOCS/Amazon+EC2
