New Application Development features in IDS 11.10. Keshava Murthy, Architect, Informix Development [email_address]
SQL Features in IDS v11 <ul><li>Language features </li></ul><ul><ul><li>Full support for subqueries in FROM clause </li></...
Language Features <ul><li>Full support for subqueries in FROM Clause </li></ul><ul><li>Enhancements to distributed queries...
Support For Subqueries in FROM Clause <ul><li>SELECT * FROM </li></ul><ul><li>(SELECT tab1.a, tab2.x, tab2.y FROM tab1, ta...
Enhancements to Distributed Queries Application IDS Server:  lenexa Database: geardb Table: winter_gear  with Boolean, lva...
Trigger Enhancements employee_tab Insert trigger Delete trigger employee_tab Pre 11.10 server 11.10 server Single insert a...
Optimizer Features <ul><li>Index Self-join Access method </li></ul><ul><li>Optimizer directives for ANSI joins </li></ul><...
Index Self-Join Access Method SELECT * FROM tab WHERE c1 >= 1 AND c1 <= 3 AND c2 >= 10 AND c2 <= 11 AND c3 >= 100 AND c3 <...
Prior Releases Lower Filter c1 >= 1  Upper Filter c1 <= 3 Index Scan Region Eliminated range on c1
With This Feature Lead Keys: c1, c2 Lower Filter c1 = c1 and c2 = c2 and c3 >= 100 Upper Filter c3 <= 102 Index Scan Regio...
Optimizer Directives for ANSI Joins <ul><li>Previously ANSI join queries allowed EXPLAIN, AVOID_EXECUTE and FIRST_ROWS/ALL...
Improvements to IDS Statistics Collection <ul><li>Automatic creation of distribution on leading key of the index </li></ul...
Explain Enhancements <ul><li>Explain enhancements </li></ul><ul><ul><li>Query Optimization Time </li></ul></ul><ul><ul><li...
Utility Features <ul><li>New Isolation level: Committed Read  Last Committed </li></ul><ul><li>Websphere MQ Messaging supp...
Committed Read Last Committed -- do more -- do more --will return 850.00 -- do more -- do more -- Status: lock wait Commit...
Committed Read Last Committed S3:reconstruct 1234  1250 customerid  balance S1: start a transaction 1234  850 S1:Withdraw ...
Websphere MQ Messaging Support MQI Connection Queue1 Websphere MQ Informix Dynamic Server Order Entry Application Queue2 S...
Automatic Re-Preparation of SQL <ul><li>The dreaded -710 error </li></ul><ul><li>Make -710 disappear </li></ul>fetch open ...
Named Parameters Support for JDBC <ul><li>This is an example of implicit positional binding: </li></ul><ul><li>CallableSta...
Named Parameters Support for JDBC Here is the same code rewritten using named parameter notation: // Set parameters (named...
New Functions and Expressions ASCII(character_expression) The ASCII function returns the decimal representation of the  fi...
New Functions and Expressions CEIL (numerical_expession) returns the DECIMAL(32) representation of the  smallest integer  ...
New Functions and Expressions LAST_DAY(date or datetime expression) Returns last day of the month in the argument. SELECT ...
New Functions and Expressions MONTHS_BETWEEN(date/datetime expr, date/datetime expr) Returns the difference between two da...
New Functions and Expressions TO_NUMBER(character or numeric expression) converts a number or a character expression repre...
Enhancements to Functions Works same as POW() function. POWER Returns the same value as CURRENT DATETIME year to fraction(...
Disabling Logging for Temporary Tables <ul><li>Logging on all temporary tables can be disabled by either of the following ...
SYSDBOPEN() and SYSDBCLOSE()  <ul><li>CREATE PROCEDURE  public.sysdbopen (); </li></ul><ul><li>SET pdqpriority 1; </li></u...
New Types and Indices <ul><li>Node Data Type </li></ul><ul><li>Binary Data Type </li></ul><ul><li>Basic Text Search Index ...
Node Data Type -- create employees table CREATE TABLE Employees(Employee_Id NODE, desc VARCHAR(60)); -- insert the hierarc...
Node Functions <ul><li>Equals </li></ul><ul><li>NotEqual </li></ul><ul><li>LessThan </li></ul><ul><li>LessThanOrEqual </li...
Binary Data Type <ul><li>BINARY18 and BINARYVAR </li></ul><ul><ul><li>CREATE TABLE bin18_test (int_col INTEGER, </li></ul>...
Basic Text Search Index Invocation of LUCENE for text index operations IDS Client IDS Client BTS: Basic Text Search Index ...
Basic Text Search Index mkdir /work/myapp/bts_expspace_directory -- Create an external space to hold the index onspaces -c...
Basic Text Search Index CREATE INDEX title_index ON article_tab(title  bts_lvarchar_ops ) USING bts IN bts_extspace; SELEC...
Stored Procedure Enhancements <ul><li>GO TO Statement </li></ul><ul><li>LOOP Statement </li></ul><ul><li>Stored procedure ...
GO TO Statement <ul><li>CREATE PROCEDURE simple_goto(a int) </li></ul><ul><li>RETURNS int; </li></ul><ul><li>IF a < 50 THE...
LOOP Statement <ul><li>CREATE PROCEDURE plusnum(a int) </li></ul><ul><li>RETURNS int; </li></ul><ul><li>DEFINE x int; </li...
LOOP Statement <ul><li>CREATE PROCEDURE sumto_a(a int) </li></ul><ul><li>RETURNS int; </li></ul><ul><li>DEFINE x int; </li...
LOOP Statement <ul><li>CREATE PROCEDURE facto(a int) </li></ul><ul><li>RETURNS int AS x, int AS factx; </li></ul><ul><li>D...
Stored Procedure Recompilation  <ul><li>This is in 10.00.xC7 and 11.10.xC2  </li></ul><ul><ul><li>Wells Fargo situation </...
XML Support <ul><li>XML Publishing functions </li></ul><ul><ul><li>Genxml </li></ul></ul><ul><ul><li>Genxmlelem </li></ul>...
XML Publishing UDR invoking the XSLT4C and XML4C libraries within IDS IDS Client IDS Client Extract functions extract() ex...
XML Publishing functions <ul><li>SELECT  </li></ul><ul><li>genxml( ROW(customer_num, fname, lname, address1, city, state, ...
XML Publishing functions <ul><li>EXECUTE FUNCTION  genxmlqueryhdr('manufact_set', </li></ul><ul><li>'SELECT * FROM manufac...
XPath Support <ul><li>SELECT  extract(booklist, '/bookstore/book[1]') </li></ul><ul><li>FROM books WHERE bookstore_id =123...
Q & A
Resources <ul><li>Infocentre </li></ul><ul><ul><li>http://publib.boulder.ibm.com/infocenter/idshelp/v111/index.jsp </li></...
