Managing Resource Networkswith a Generic Open-source     Software Platform    Julien Harou    University College London   ...
CollaboratorsBTG funding Lazaros Papageorgiou, Andy Chow, Mark Barrett, Eric FragaUCL Research Challenge funding Muki Hakl...
Outline• Sustainability and resource systems• Systems modeling software• HydroPlatform• Example applications• Project orga...
Sustainable City …   Sustainable Resource NetworkWater resources, energy, food, transport, trade, logistics, social networ...
Systems modeling in the 21st Century •   Large problems •   Multidisciplinary •   Many spatial and temporal scales •   Com...
Traditional stand-alone software / DSS            Interface   Database                                   Examples         ...
Model Platform                                                  Manages &                                                d...
HydroPlatform  an example platform for network models• Free, open source (GPL license & Python)• GIS interface (Thubian) D...
The old way…               [Jacobs et al. 1995]   9
… in HydroPlatform             Yuba      Bear                    American                               10
Define required data for each network                object                                        11
Example Applications     1.     London water supply and Thames water                      resource system2.        Water S...
English water management context•    Water supply & waste water utilities privatised    since 1989•    Companies must subm...
London and Thames water resource system                                          14
London and Thames water resource system                         IRAS-2010 model uses a weeklyGoal:                    time...
Gauged flow at TeddingtonIRAS-2010 and AQUATOR show same flows and  follow trend for gauged flow                          ...
Capacity Expansion and Water Trading                             Schematic  Goal:  - Identify minimum cost  portfolio of s...
Annual rainfall   Water companies
Zambezi Basin Hydropower dam operation          Goal:          Find allocation policies          that maximize agricultura...
Linear-Quadratic traffic signal controlGoal:Model optimises real-timecontrol of traffic lightduration                     ...
Linear-Quadratic traffic signal control• Input   – Traffic inflow                                         120   – Nominal ...
Finding community structures in complex  networks using mixed integer optimisation Goal: reveal the relationships between ...
Project organization• www.hydroplatform.org• Wiki, code, and bug reports• Pre-release available• Future app store   open-s...
Conclusions• Model platform = user interface + data manager• Helps focus on model development rather than software• Effici...
