NoSQL Databases Jon Meredith [email_address]
What isn't NoSQL? <ul><li>NOT  a standard.
NOT  a product.
NOT  a single technology. </li></ul>
Well, what  is  it? <ul>It's a  buzzword . <li>A banner for non-relational databases to organize under.
Mostly created in response to scaling and reliability problems.
Huge differences between 'NoSQL' systems – but have elements in common. </li></ul>
Where did it come from? <ul><li>They've been around for a while </li><ul><li>Local key/value stores
Object databases
Graph databases
XML databases </li></ul><li>New problems are emerging </li><ul><li>Internet search
e-commerce
Social networking </li></ul></ul>
Where did it come from? <ul><li>Some efforts came from scaling the web...
Several papers published  </li><ul><li>2006 – Google BigTable
2007 – Dynamo Paper </li></ul><li>In 2008 - explosion of data storage projects
All shambling under the NoSQL banner. </li></ul>
Really, why not use RDBMs? <ul><li>I need to perform arbitrary queries
My application needs transactions
Data needs to be nicely normalized
I have replication for scalabilty/reliability </li></ul>
Data Mapping Woes <ul><li>Relational databases divide data into columns made up of tables.
Programmers use complex nested data structures </li><ul><li>Hashes
Sets
Arrays
Things of things </li></ul><li>Have to map between the two </li></ul>
Data Mapping Woes (2) <ul><li>Data in systems evolve over time … which means changes to the schema.
Upgrade/rollback scripts have to operate on the whole database – could be millions of rows.
Doing phased rollouts is hard … the application needs to do work </li></ul>
Alternative! <ul><li>Let the application do it
Use convenient language features </li><ul><li>PHP serialize/unserialize </li></ul><li>… or use standards for mixed platfor...
Google's protocol buffers
… even XML </li></ul><li>Design for forward compatibility </li><ul><li>Preserve unknown fields
Version objects </li></ul></ul>
Scalability and Availability <ul><li>Scalability </li><ul><li>How many requests you can process </li></ul><li>Availability...
Scaling RDBMs - Replication <ul><li>Master-Slave replication is easiest
Every change on the master happens on the slave.
Slaves are read-only. Does not scale INSERT, UPDATE, DELETE queries.
Application responsible for distributing queries to correct server. </li></ul>
Scaling RDBMs - Replication <ul><li>Multi-master ring replication </li><ul><li>Can update any master
Updates travel around the ring
What happens when it fails? </li><ul><li>Reconfigure the ring </li></ul><li>What happens on return </li><ul><li>Synchroniz...
Add back in to the ring </li></ul></ul></ul>
Replication <ul><li>Replication is usually asynchronous for performance – you don't want to wait for the slowest slave on ...
Replication takes time – there is time lag between the first and last server to see an update.
You may not read your writes – not getting aCid properties any more. </li></ul>
Scaling RDBMS – Sharding <ul><li>Do application level splitting of data </li><ul><li>Split large table into N smaller tables
Use Id modulo N to find the right table </li></ul><li>Tables could be spread across multiple database servers </li><ul><li...
Availability <ul><li>If you want availability you need multiple servers – maybe even multiple sites.
In the real world you get network partitions </li><ul><li>Just because you can't see your other data center doesn't mean u...
Upcoming SlideShare
Loading in...5
×

Front Range PHP NoSQL Databases

5,564

Published on

The presentation I did for the FrontRange PHP User Group on 3/10/2010.

Published in: Technology
0 Comments
3 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
5,564
On Slideshare
0
From Embeds
0
Number of Embeds
16
Actions
Shares
0
Downloads
102
Comments
0
Likes
3
Embeds 0
No embeds

No notes for slide
  • Introduce Disclose work for Basho Working on Dynamo clone for the last couple of years
  • Front Range PHP NoSQL Databases

    1. 1. NoSQL Databases Jon Meredith [email_address]
    2. 2. What isn't NoSQL? <ul><li>NOT a standard.
    3. 3. NOT a product.
    4. 4. NOT a single technology. </li></ul>
    5. 5. Well, what is it? <ul>It's a buzzword . <li>A banner for non-relational databases to organize under.
    6. 6. Mostly created in response to scaling and reliability problems.
    7. 7. Huge differences between 'NoSQL' systems – but have elements in common. </li></ul>
    8. 8. Where did it come from? <ul><li>They've been around for a while </li><ul><li>Local key/value stores
    9. 9. Object databases
    10. 10. Graph databases
    11. 11. XML databases </li></ul><li>New problems are emerging </li><ul><li>Internet search
    12. 12. e-commerce
    13. 13. Social networking </li></ul></ul>
    14. 14. Where did it come from? <ul><li>Some efforts came from scaling the web...
    15. 15. Several papers published </li><ul><li>2006 – Google BigTable
    16. 16. 2007 – Dynamo Paper </li></ul><li>In 2008 - explosion of data storage projects
    17. 17. All shambling under the NoSQL banner. </li></ul>
    18. 18. Really, why not use RDBMs? <ul><li>I need to perform arbitrary queries
    19. 19. My application needs transactions
    20. 20. Data needs to be nicely normalized
    21. 21. I have replication for scalabilty/reliability </li></ul>
    22. 22. Data Mapping Woes <ul><li>Relational databases divide data into columns made up of tables.
    23. 23. Programmers use complex nested data structures </li><ul><li>Hashes
    24. 24. Sets
    25. 25. Arrays
    26. 26. Things of things </li></ul><li>Have to map between the two </li></ul>
    27. 27. Data Mapping Woes (2) <ul><li>Data in systems evolve over time … which means changes to the schema.
    28. 28. Upgrade/rollback scripts have to operate on the whole database – could be millions of rows.
    29. 29. Doing phased rollouts is hard … the application needs to do work </li></ul>
    30. 30. Alternative! <ul><li>Let the application do it
    31. 31. Use convenient language features </li><ul><li>PHP serialize/unserialize </li></ul><li>… or use standards for mixed platforms </li><ul><li>JSON very popular and well supported
    32. 32. Google's protocol buffers
    33. 33. … even XML </li></ul><li>Design for forward compatibility </li><ul><li>Preserve unknown fields
    34. 34. Version objects </li></ul></ul>
    35. 35. Scalability and Availability <ul><li>Scalability </li><ul><li>How many requests you can process </li></ul><li>Availability </li><ul><li>How does your service degrade as things break. </li></ul><li>RDBMS solutions - replication and sharding </li></ul>
    36. 36. Scaling RDBMs - Replication <ul><li>Master-Slave replication is easiest
    37. 37. Every change on the master happens on the slave.
    38. 38. Slaves are read-only. Does not scale INSERT, UPDATE, DELETE queries.
    39. 39. Application responsible for distributing queries to correct server. </li></ul>
    40. 40. Scaling RDBMs - Replication <ul><li>Multi-master ring replication </li><ul><li>Can update any master
    41. 41. Updates travel around the ring
    42. 42. What happens when it fails? </li><ul><li>Reconfigure the ring </li></ul><li>What happens on return </li><ul><li>Synchronize the master
    43. 43. Add back in to the ring </li></ul></ul></ul>
    44. 44. Replication <ul><li>Replication is usually asynchronous for performance – you don't want to wait for the slowest slave on each update.
    45. 45. Replication takes time – there is time lag between the first and last server to see an update.
    46. 46. You may not read your writes – not getting aCid properties any more. </li></ul>
    47. 47. Scaling RDBMS – Sharding <ul><li>Do application level splitting of data </li><ul><li>Split large table into N smaller tables
    48. 48. Use Id modulo N to find the right table </li></ul><li>Tables could be spread across multiple database servers </li><ul><li>But the application needs to know where to query </li></ul></ul>
    49. 49. Availability <ul><li>If you want availability you need multiple servers – maybe even multiple sites.
    50. 50. In the real world you get network partitions </li><ul><li>Just because you can't see your other data center doesn't mean users can't. </li></ul><li>What should you do if you can't see the other data center? </li></ul>
    51. 51. Availability <ul><li>Degrade one site to read-only </li><ul><li>Defeats availability </li></ul><li>If you allow both sites to operate </li><ul><li>There's a chance two users could modify the same data.
    52. 52. The application needs to know how to resolve it </li></ul></ul>
    53. 53. The bottom line... <ul><li>Building systems that are </li><ul><li>...Scalable...
    54. 54. ...Available...
    55. 55. ...Maintainable...
    56. 56. with an RDBMs requires large efforts by application developers and operational staff </li></ul></ul>
