SharePoint Performance Optimization In 10 Steps for the IT Professional

Joel Oleson Contributions: SharePoint Product Architect Mike Watson Quest Software Aptimize http://www.sharepointjoel.com Fpweb

Agenda Measuring Performance 10 Steps for Optimizing Performance Front End Backend Caching, Caching, Caching Dedicated Disks Compression Application settings Memory Index Optimization App Pools SharePoint Configuration Offloading Auth & SSL Page Optimization Webpart Optimization End to End Q&A

Fast performance = Happy Users better user experience more traffic more revenue

Understanding Performance Server Network Client Server Tuning Network Infra Upgrades Browser Render time Data Centers NIC Upgrades Page Optimization Content Delivery WAN Solutions Hardware, Driver and Networks overcoming latency OS Upgrades Offloading Compression Caching Differencing

Page Performance Methodology Methodology • Page Goal: 5 seconds or less • Measure • Improve • Measure What can we change? • Hardware • Platform • Application • Network

Free Tools for Measuring Performance www.Fiddler2.com Ping (for latency) www.WebPageTest.org www.Aptimize.com Perfmon

Caching, Caching, Caching Client Cache Page Far Future Expires Server Cache Reduce SQL Round Trips Output Cache Publishing Site Collection Page Webparts Never Cache a Search Results not fully anonymous! Disk Based Caching Blob Cache Atom Feeds & RSS = 5 minutes by default

Gzip Compression Reduce first view load time 30%-40% Reduces size: HTML JavaScript StyleSheets No effect on images: (JPEG, PNG, GIF) SharePoint is configured for Collab workload out of the box… Lots of Reads/Writes Check for HTTP request header Accept-Encoding: gzip, deflate

Memory Out of Memory Minimize App Pools Dedicate App pool to customizations and consolidate all else SQL timeouts Warm up Users Complain about 1 minute render times Intermittent performance issues SpDisposeCheck Check for memory leaks, unclosed – Very common!

Webparts What to watch out for… Watch for closed webparts – very comon Force webpart maintenance page or Designer to delete closed webparts Poor performing webparts Dynamic Navigation – list based or cross site with no caching Cross site rollups Content Query Webpart Why doesn’t SharePoint ship with cross site collection rollups and what’s new webparts??? Performance!!! Msdn: Smart Core.js

Managing 2010 Perf Hosted by FPWeb

Identify Poorly Performing Code & Content Look for memory leaks recycle often and/or fix Avoid App pool memory limits or processor limits Look for processor intensive code Render customizations via load tests Identify Software boundaries Large & Wide lists Deep Large site collections with lots of webs Large DBs TechNet: Plan for software boundaries

Health Rules - Definitions Health Rules Runs on a Timer Job Create your own! Repair Auto- magically!

Performance Optimizations Cleaner Pages and XHTML Compliance Core.js size reduced 12% List retrieval optimized Content DB optimized for scale SQL Blocking reduced with list throttling Performance Point incorporated into SharePoint Server 2010 Distributed Indexing - Each crawl database can have many crawlers associated with it

Performance Controls HTTP Throttling - Every five seconds, a job runs that checks server resources Server CPU, Memory, Request in Queue, and Request Wait After 3 failed checks, server is throttled until a successful check. List Controls – List is automatically throttled to max 5000 items

Health Report – Slowest Pages Extensibility for reporting and possibilities are limitless

Performance Dev Dashboard Selected Scope general info SQL queries Info SPMonitoredScopes and WCF Calls their associated cost web part info Off – default, On, and Ondemand – best practice for intranets!

Top Performance Killers 1. Indexing/Crawling 2. Backup (SQL & Tape) 3. Profile Import 4. Users - Inefficient views (Throttling in 2010 helps) 5. Timer Jobs – i.e. User Sync for large #s of Users 6. Poor Storage Configuration 7. STSADM Backup/Restore (Replace with third party or 2010 unattached recovery) 8. Large List Operations Delete/Update 9. Network Saturation/Congestion, i.e. Streaming Video 10. Misconfigured Network

Why is SQL that important? SQL Health = SharePoint Health! Sub-optimal SQL perf will radiate to other components in the farm Slow Slow Slow response from SQL Server will result in App SQL queued App requests As the app slows down, so does SQL

Database Disk I/O Demand Most Demand Medium Demand Low Demand Search Config *Content.. Temp +SSP Model Tlogs Master New Logging in Service 2010 App Usage * Except during backup and Indexing + Except during Profile Import

Scaling SQL - Up Design is Paramount! Consider the following: Overall SQL Throughput (transactions/sec) Disk throughput (IOPS) Network throughput (MB/sec) Disk backup throughput (MB/sec) Network based backup throughput (MB/sec) Length of maintenance windows (hours -> minutes)

New SharePoint 2010 Databases Workload based optimization Config Search_Service_Application WSS_Content_GUID Admin_Content Crawlstore WSS_Content_GUID1… Application Registry Service SearchDB WSS_Content_GUID2… StateService PropertyStore Web Analytics Web Service WSS_Search Content Farm WSS_Usage Services SocialDB Reporting_DB ProfileDB (was SSP db) Staging DB SyncDB BDC_Service_DB Word Conversion Service Application Performance_Point ManagedMetadata Secure_Store_Service

Understanding Website Speed Waterfall Diagram Breaks down page load Shows everything to load the page Server/Client/first render Create diagram using WebPageTest.org Fiddler

Vendors for Speeding Up SharePoint Software Based Solutions Page & Performance Optimization – Dynamic/Automated Best Practices - Aptimize WAX Dashboard Monitoring and Insight – Quest Foglight, System Center Hardware Based Solutions WAN Accelerators – hardware devices used to compress, difference, and offload – Cisco, Citrix, Certeon Reverse Proxy Compression, SSL Offload and Caching – F5, Microsoft ISA & IAG

Guideline What you can do to optimize your pages… Minimize HTTP Requests Merges JS, CSS files into fewer files. Merges images into sprites Add an Expires or a Automatically adds far-future-expires headers to resources and Cache-Control Header uses auto URL versioning to ensure cached resources are kept up-to-date Gzip Components Components are Gzipped and cached on the server to reduce CPU load Put Stylesheets at the Top Stlyesheets are moved to the top of the page Put Scripts at the Bottom Scripts can be moved to the bottom (or anywhere) on the page Reduce DNS Lookups External resources can be cached and served from the local server Minify JavaScript and CSS JS and CSS are minified Remove Duplicate Scripts Duplicate JS files, stylesheets and images are removed Configure ETags ETags are stripped from the resources Optimize Images Images can be resampled, and GIFs converted to PNGs Optimize CSS Sprites CSS Sprites are created and organized horizontally Make favicon.ico Small Favicon is configured for caching, and inserted if it is missing, and Cacheable removing a 404 condition.

Sharepoint2010.microsoft.com Challenge Improve performance for microsoft.com site High traffic, no downtime Applied Methodology Used 10 techniques http://www.aptimize.com/customers "The improvement in page loading time is tremendous." Tony Tai, Product Manager, Results Microsoft Corporation > 50% reduction in load time

SharePoint 2010 Acceleration Hosted by FPWeb

Website Accelerator Automates best practices for browser load times Aptimize Blog http://www.aptimize.com/blog Twitter http://twitter.com/aptimize Spoint.me (SharePoint Social Network) http://spoint.me/groups/sharepoint-performance/ Contact: 800-935-8414 USA Contact: mike.iem@aptimize.com Outside USA: aaron.bellingham@aptimize.com

Summary Memory, Disk and Network are frequent performance bottlenecks SQL is extremely important to SharePoint health and Performance Think IOPS when designing disk arrays Separate work loads: temp, log, search, content. SQL scales up and out. Don’t push the limits upward, but keep manageability and costs in mind when scaling out. SharePoint 2010 provides proactive management Check the HTML requests and how they affect performance with www.fiddler2.com or www.webpagetest.org Trial www.aptimize.com and improve your YSLOW score!

Resources WebPageTest http://www.webpagetest.org Fiddler http://www.fiddler2.com http://www.microsoft.com/Downloads/details. Visual Round-Trip Analyzer aspx?FamilyID=119f3477-dced-41e3-a0e7- d8b5cae893a3 http://blogs.msdn.com/sharepoint/archive/200 Microsoft case study 9/09/28/how-we-did-it-speeding-up- Sharepoint.microsoft.com sharepoint-microsoft-com.aspx http://www.iab.net/media/file/IAB_Ad_Load_P IAB guidelines erfomance_BP_FINAL.pdf

Hosted SharePoint 2010 Over 10 years of SharePoint Hosting experience. 1st company in the World to host SharePoint back in 1999. Over 1,000,000 SharePoint users in 80 countries. Complete Server Control (unrestricted RDP access). Secure VPN & Active Directory Integrations. World class hosting network – 3 tier redundant ISP backbone. No up-front costs – one predictable monthly price. We are every bit SharePoint. We do one thing – very, very well.

Technology Responsibilities Multiple Technology Responsibilities Toughest Challenges Exchange 1. User Provisioning/de-provisioning 14% MIIS/ILM Active 2. Delegation of Admin Rights 16% Directory 44% 3. Compliance Reporting DNS 26% 4. Disaster Recovery Technology Used / Deployed • 99% MS Server OS • 90% Management Frameworks • 55% - MOM • 27% - HP OpenView • 21% - IBM Tivoli • 87% Exchange • 74% SharePoint Source: DEC 2008 Attendee Survey Whitepaper 38

Aptimize Website Accelerator Aptimize software automates best practices for browser load times Aptimize Doubles Website Speeds:  Reduces HTTP requests by merging CSS and JS files  Reduces images with CSS sprite and CSS inlining  Compresses content using minification + Gzip  Increases caching using far-future-expires  50% reduction in data traffic and load times  40% increase in server throughput  Used in over 300 websites and intranets http://www.aptimize.com

Sample Waterfall Diagram Server vs. Client time
