  • 1. Bartłomiej Filipek www.bfilipek.com mail@bfilipek.com
  • 2.  How does this work?  General architecture  Advices  Tools The lecture will not cover the technical details about the gpu, it shows only overview needed to understand current technologies and standads.
  • 3. GPU CPU Vertex Fragment Processing Processing application BUS Commands, Textures, Framebuffer 3D Api Vertices, Shaders, (DirectX/OpenGL) Data… Memory Driver Display
  • 4. Vertex units Vertex Processing Memory/textures Fragment Processing As we can see, previous architectures matched vertex/fragment „fixed” chain… so at the beginning all the data was processed in Pixel units „vertex units” and then it was moved to fragment units.
  • 5.  SISD – Single Instruction Single Data  Standard way… one instruction is being executed per single data.  SIMD – Single Instruction Multiple Data  Instruction is being executed per several data – like for one 4D vector (128 bits)  MIMD – Multiple Instructions Multiple Data  Parrarel processing!
  • 6. Vertex units used Units Dynamic task division… Fragment units used Vertex units used u n u s e d fragment units used Effect that uses a lot vertex processing Effect that uses a lot vertex processing Vertex units used Units Fixed task division… u n u s e d Fragment units used fragment units used vertex units used Effect that uses a lot fragment processing Effect that uses a lot fragment processing Vertex units/Fragment units and their quantities were fixed – we had N vertex processors, and M fragment processors, but now we have unifed architecture. That means that we have K units that can process vertex and fragments… there is no difference between them.
  • 7. Controller Stream processors As we can see there are no vertex/fragment units… instead there Shared memory are stream processors that can handle both vertex and fragments… and even more.
  • 8.  Scalars… not Vectors!  Stream processor uses only one data per instruction.  But we have a lot of SP!  SP gives far more great flexibility.  GPGPU  SIMT – Single Instruction Multiple Threads
  • 9.  New architecture - NV  DX11, OpenCL  Miltithreaded Rendering  Rendering commands can be called from difrent threads  3 000 000 000 transistors!  End of 2009? End of winter 2010? Never?  Double precission callculations cost twice as much as float, not ten times as it was before!  Debugging – one can debug gpu directly from VisualStudio
  • 10. Fragment Vertex Shader Shader Geometry Shader CUDA Unified Shader OpenCL DirectX Compute ATI Stream
  • 11.  General-purpose computing on graphics processing units  Kernels – code that will be executed on the GPU  Not only graphics but also:  Physics ▪ Fluids ▪ Collisions ▪ N-body simulations…  Financial  Speach/Pattern recognition  Phenomena modelling – weather…  Neural nets  AI
  • 12.  Use as few as possible:  calculations  Huge textures – mimpaps instead  interpolators  Data  Rendering state changes  Dynamic Vertex Buffers  Textures… use texture atlases maybe  Texture fetches  Use more:  Batches  Triangle stripes
  • 13.  Use Maths Uniform sphere: p = sqrt(Rx^2 + Ry^2 + (Rz + 1)^2) = sqrt(Rx^2 + Ry^2 + Rz^2 + 2Rz + 1); R vector is normalized so: Rx^2 + Ry^2 + Rz^2 = 1 p = sqrt(2 * (Rz + 1)) = 1.414*sqrt(Rz + 1) Calculte this before it is send to the gpu!  Reduce calculation on uniform vars! half4 main(float2 diffuse : TEXCOORD0, uniform sampler2D diffuseTex, uniform half4 g_OverbrightColor) { return tex2D(diffuseTex, diffuse) * g_OverbrightColor * 3.0; }  Normalize dot(normalize(N), normalize(L)) uses two sqrts! but: (N/|N|) dot (L/|L|) = (N dot L) / (|N| * |L|) = (N dot L) / (sqrt( (N dot N) * (L dot L) ) = (N dot L) * rsq( (N dot N) * (L dot L) ) Now we have only one sqrt – three dots are much cheaper than sqrt
  • 14.  Texture lookups:  ~ 10 : 1 (ALU:Sampler)  Normalization cube map  Single „Dot” is not worth texture lookups…  But calculation of NormalDistribution… YES!  Early Z-Test  Depth-only Rendering, then full scene (for the second time)
  • 15.  Lighten number of attributes – „pack” them as possible.  float4 myData is better than: ▪ float3 myDataOne; ▪ float1 myDataTwo;  But do not pack in interpolators  Use as few scalars as possible  When vectors are packed no optimalizations can be performed  What do you really need?  Normal, binormal, tangent… no! You need only two of them!  Binormal = normal _Cross_ Tangent
  • 16. PerfKit •For DirectX mostly •Little support for OpenGL – via glExpert PiX for Windows •Shows everything! But only for Windows, DirectX… AMD GPU Perf Similar to Pix, but for OpenGL… 800$ ;(
  • 17. GLIntercept • OpenGL • free  • log every call of opengl command • edit shaders in realtime • although it is a bit simple it has a powerful impact on debugging…
  • 18. GPU ShaderAnalyzer • free, from AMD! • glsl/hlsl • shows number of asm instructions • ALU, TEX instructions, etc.. • bottlenecks
  • 19. FXComposer, by NVidia ShaderDesigner by TyphoonLabs RenderMonkey by AMD/ATI
  • 20.  PPAM – slajdy - PARALLEL PROCESSING AND APPLIED MATHEMATICS, Wrocław 2009  Developer.nvidia.com  glintercept.nutty.org  developer.amd.com  Nvidia GeForce GTX 260/280 Review
