Introduction to Fire Protection 3rd Edition
Chapter 12 Fire Protection Systems  and Equipment
Objectives <ul><li>Describe the components of a water supply system </li></ul><ul><li>Explain the importance of a dependab...
Objectives (con’t.) <ul><li>Describe different types of extinguishing systems and their components </li></ul><ul><li>Descr...
Introduction <ul><li>Water is most common extinguishing agent </li></ul><ul><li>Over the years, water systems have been be...
Public Water Companies <ul><li>Water is one of the single most important factor in municipal fire protection </li></ul><ul...
Private Water Companies <ul><li>Usually established to address industrial or commercial needs </li></ul><ul><li>Maintain o...
Water Supply Systems <ul><li>Storage capacity and redundancy of system </li></ul><ul><li>Factors for determining required ...
Water Supply Systems (con’t.) <ul><li>Types of supply systems </li></ul><ul><ul><li>Gravity fed systems </li></ul></ul><ul...


Water Supply Systems (con’t.) <ul><li>Adequacy criteria </li></ul><ul><ul><li>Average daily consumption </li></ul></ul><ul...
Distribution System <ul><li>From storage to treatment to consumer </li></ul><ul><li>Water mains </li></ul><ul><ul><li>Unde...
Distribution System (con’t.) <ul><li>Secondary feeders </li></ul><ul><ul><li>Reinforce grid </li></ul></ul><ul><ul><li>Con...



Fire Hydrants <ul><li>Two basic types (see Figure 12-5) </li></ul><ul><ul><li>Wet barrel </li></ul></ul><ul><ul><ul><li>Co...


Fire Hydrants (con’t.) <ul><li>Special hydrant types </li></ul><ul><ul><li>Airport taxiway/runway </li></ul></ul><ul><ul><...
DRY HYDRANT WALL HYDRANT
Fire Hydrants (con’t.) <ul><li>Hydrant maintenance program </li></ul><ul><ul><li>Inspect, clean, and lubricate all parts <...
Fire Hydrants (con’t.) <ul><li>Hydrant testing </li></ul><ul><ul><li>Performed on new systems to assess flow rates </li></...
NFPA Coding System <ul><li>1,000 GPM + Green Caps and Bonnet </li></ul><ul><li>500 to 999 Orange Caps </li></ul><ul><li>49...
PITOT TUBE PITOT TUBE MEASURES FLOW.

Water Systems Program <ul><li>Used to promote cooperation between fire department and water companies </li></ul><ul><ul><l...
Auxiliary Sources of Water Supply <ul><li>In areas with lack of an adequate water supply system, especially rural areas </...

Private Fire Protection Systems <ul><li>Designed to protect individual properties from fire </li></ul><ul><li>Uses detecti...
Detection Devices <ul><li>Smoke detectors </li></ul><ul><ul><li>For public education purposes, the NFPA prefers the term “...


Detection Devices (con’t.) <ul><li>Smoke/flame detector types </li></ul><ul><ul><li>Ionization chamber </li></ul></ul><ul>...
Detection Devices (con’t.) <ul><li>Alarm system activation </li></ul><ul><ul><li>Manual pull stations (see Figure 12-14) <...
Extinguishing Agents <ul><li>Water </li></ul><ul><ul><li>Most commonly used agent </li></ul></ul><ul><ul><li>High specific...
Extinguishing Agents (con’t.) <ul><li>Foam </li></ul><ul><ul><li>Consists of concentrate added to water </li></ul></ul><ul...
Extinguishing Agents (con’t.) <ul><li>Types of foam </li></ul><ul><ul><li>Chemical </li></ul></ul><ul><ul><ul><li>Combinat...

Extinguishing Agents (con’t.) <ul><li>Types of mechanical foam (Class B) </li></ul><ul><ul><li>AFFF </li></ul></ul><ul><ul...
Extinguishing Agents (con’t.) <ul><li>Class A foam </li></ul><ul><ul><li>When used with CAFS, will stick to vertical surfa...
Extinguishing Agents (con’t.) <ul><li>Wetting agents </li></ul><ul><ul><li>Reduce surface tension of water and allow it to...
Extinguishing Agents (con’t.) <ul><li>Fire retardant </li></ul><ul><ul><li>Short term  </li></ul></ul><ul><ul><ul><li>Depe...
Extinguishing Agents (con’t.) <ul><li>Other agents </li></ul><ul><ul><li>Carbon dioxide (CO 2 )   dilutes oxygen to smothe...
Extinguishing Agents (con’t.) <ul><li>Other agents (con’t.) </li></ul><ul><ul><li>Dry chemical </li></ul></ul><ul><ul><ul>...
Extinguishing Agents (con’t.) <ul><li>Other agents (con’t.) </li></ul><ul><ul><li>Dry powder </li></ul></ul><ul><ul><ul><l...
Extinguishing Systems <ul><li>Automatic sprinklers </li></ul><ul><ul><li>Proven 96% effective </li></ul></ul><ul><ul><li>F...
Residential Sprinklers <ul><li>Less expensive than commercial systems </li></ul><ul><li>Less complicated </li></ul><ul><li...
Commercial and Industrial Sprinkler Systems <ul><li>Basic components </li></ul><ul><ul><li>Fire department connection </li...
Wet Pipe System <ul><li>Used where freezing is not a concern </li></ul><ul><li>Water remains behind sprinkler heads at all...
Example Wet Pipe System
Post Indicator Valves Riser And Loop

Dry Pipe System <ul><li>Used where freezing is a concern </li></ul><ul><li>Compressed air in system keeps water below clap...
Dry Pipe System (con’t.) <ul><li>Fire department connection   </li></ul><ul><ul><li>Attached to riser </li></ul></ul><ul><...
Dry Pipe System (con’t.) <ul><li>Path of water through system </li></ul><ul><ul><li>Water main </li></ul></ul><ul><ul><li>...
Dry Pipe System (con’t.) <ul><li>Deluge system </li></ul><ul><ul><li>All sprinkler heads open at all times </li></ul></ul>...
Dry Pipe System (con’t.) <ul><li>Preaction system </li></ul><ul><ul><li>Closed sprinkler heads </li></ul></ul><ul><ul><li>...
Sprinkler Heads <ul><li>Include deflector to divide flow into droplets </li></ul><ul><li>Various types for differing appli...



Standpipe Systems <ul><li>Usually found in stairwells </li></ul><ul><li>Prevent having to lay hose to upper floors </li></...

Foam Systems <ul><li>Can create foam in several ways </li></ul><ul><ul><li>Eduction: draws concentrate into hose stream th...

Gas Extinguishing Systems <ul><li>Used when water will cause excessive damage to stock or electrical installations </li></...
Dry Chemical Systems <ul><li>Powder stored in a container </li></ul><ul><li>Common fire extinguisher </li></ul><ul><li>May...
Wet Chemical Extinguishing Systems <ul><li>Used for combustible cooking </li></ul><ul><li>Installed hood system or portabl...
Fire Pumps <ul><li>Boosts pressure in fixed systems </li></ul><ul><li>Diesel and/or electric powered </li></ul><ul><ul><li...
Fire Extinguishers <ul><li>From very small to very large </li></ul><ul><li>Found in all types of applications </li></ul><u...
EXTINGUISHER LABELS <ul><li>Class A  </li></ul><ul><li>•  Green Triangle </li></ul><ul><li>•  Picture of Trash Can </li></...
EXTINGUISHER LABELS <ul><li>Class B </li></ul><ul><li>•  Red Square </li></ul><ul><li>•  Gas Can with Flames </li></ul>
EXTINGUISHER LABELS <ul><li>Class C </li></ul><ul><li>•  Blue Circle </li></ul><ul><li>•  Picture of Electric Plug and Rec...
EXTINGUISHER LABELS <ul><li>Class D </li></ul><ul><li>•  Gold Star </li></ul>D
Extinguisher Labels <ul><li>Class K </li></ul><ul><li>Picture of a Frying Pan with Flames </li></ul>
Obsolete Agents <ul><li>Some obsolete extinguishers are still in use </li></ul><ul><ul><li>Soda acid, carbon tetrachloride...
Pressure-Reducing  Devices <ul><li>Used to reduce pressure on lower floors of high-rise buildings </li></ul><ul><li>Used t...
<ul><li>Fire department should maintain close relationship with local water company </li></ul><ul><li>Firefighters must:  ...
