GigaSpaces Data Caching / Data Grid overview August 2009
<ul><li>Scaling Up Your Database by Adding a Data Grid </li></ul>
Scaling Up Your Database by Adding a Data Grid <ul><li>To scale up your database, use the IMDG directly </li></ul><ul><li>...
Benefits of using GigaSpaces as the system of record <ul><li>Decreasing database load  through partitioning and data distr...
IMDG Access support  <ul><li>Main Features: </li></ul><ul><ul><li>Direct persistency (Write/Read Through) </li></ul></ul><...
Step 2: Access data via IMDG SQL Queries <ul><li>Supported Options and Queries </li></ul><ul><ul><li>Opeations: =, <>, <,>...
<ul><li>GigaSpaces In-Memory-Data-Grid </li></ul>
The IMDG – Runtime Modes – Embedded <ul><li>An IMDG (space) instance that runs within the application memory address space...
The IMDG – Runtime Modes – Remote <ul><li>Accessing a remote space involves network calls and serialization/de-serializati...
The IMDG – Runtime Modes – Master-Local Cache <ul><li>A local ‘cache’  </li></ul><ul><ul><li>Embedded with a client </li><...
The IMDG – Runtime Modes – Master-Local View <ul><li>A local 'View' </li></ul><ul><ul><li>Embedded with a client </li></ul...
The IMDG – Runtime Modes – Persistent <ul><li>Stores data both into memory and on disk in a relational database </li></ul>...
Asynchronous Reliable Persistency - Write Behind <ul><li>The most common architecture </li></ul><ul><li>Database is out of...
The Initial Load – Fast Data load from the Database
<ul><li>IMDG </li></ul><ul><li>Deployment Topologies </li></ul>
IMDG Basic Deployment Topologies <ul><li>Primary-Backup </li></ul>Partitioned Feeder Feeder Partitioned + Backup Feeder
<ul><li>IMDG </li></ul><ul><li>Operations </li></ul>
IMDG Basic Operations
<ul><li>Move into SBA </li></ul>
What is Space Based Architecture (SBA) Space-Based Architecture  ( SBA ) is a  software architecture pattern  for achievin...
Move into SBA <ul><li>Deploy Application components as Processing Units </li></ul><ul><ul><li>Form a composite SOA Applica...
Space Based Architecture – Business logic and data collocated Pushing data into the backend system In-Memory-Data-Grid and...
Map-Reduce Approach to perform Parallel Query <ul><li>How The GigaSpaces Task Executors works? </li></ul><ul><ul><li>Phase...
Map-Reduce Approach to perform Parallel Query <ul><li>How Task Executors works?   </li></ul><ul><ul><li>Phase 2 - Getting ...
Distributed Task  Example <ul><li>public class MyDistTask implements DistributedTask<Integer, Long> { </li></ul><ul><li>pu...
<ul><li>SBA Fundamental </li></ul>
Space Based Architecture Fundamentals <ul><li>The CAP properties: </li></ul><ul><li>Strong  C onsistency:  </li></ul><ul><...
Using SBA to Virtualize the Middleware = GigaSpaces XAP <ul><li>Steps to virtualize the middleware: </li></ul><ul><ul><li>...
The Service Grid <ul><li>Continuous Application Availability To Achieve 99999’s  </li></ul><ul><ul><li>Automatically provi...
Typical Web Application Architecture Dynamic LB Configuration  Managed Jetty Web Containers,  Http Session on top of the S...
