Introduction to      Spring Data Neo4jMichael Hunger
Me & You ? ๏ Me: Michael Hunger, Neo Technology    • passionate software developer / Neo4j German Division    • Spring Dat...
What‘s up?๏ NOSQL overview๏ Spring Data overview๏ Networks are everywhere๏ Graph Databases๏ Neo4j introduction๏ Spring Dat...
NOSQL overview                 4
What does NOSQL stand for?
What does NOSQL stand for?   It’s not “No to SQL”
What does NOSQL stand for?   It’s not “No to SQL”                          It’s not “Never SQL”
What does NOSQL stand for?   It’s not “No to SQL”                           It’s not “Never SQL”         It’s “Not        ...
What does NOSQL stand for?   It’s not “No to SQL”                             It’s not “Never SQL”         It’s “Not      ...
Why NOSQL now?We have observed four trends:๏ Trend 1: Size of data is growing๏ Trend 2: Data is increasingly connected๏ Tr...
NOSQL categoriesWe see four main categories in the NOSQL space:
NOSQL categoriesWe see four main categories in the NOSQL space:    Key-Value           •Redis           •Riak            •...
NOSQL categoriesWe see four main categories in the NOSQL space:                                 Column-family/    Key-Valu...
NOSQL categoriesWe see four main categories in the NOSQL space:                                 Column-family/    Key-Valu...
NOSQL categoriesWe see four main categories in the NOSQL space:                                 Column-family/    Key-Valu...
Scaling to size vs. Scaling to complexity     Size        Key-Value stores                     Bigtable clones            ...
Scaling to size vs. Scaling to complexity     Size        Key-Value stores                     Bigtable clones            ...
Scaling to size vs. Scaling to complexity     Size        Key-Value stores                     Bigtable clones            ...
Spring Data overview
What is Spring Data๏ VMWare/SpringSource initiative to give Spring developers easy     access to the emerging world of NOS...
Spring Data projects ๏ Code is in SpringSource git repository:       • http://springsource.org/spring-data       • https:/...
Spring Data Neo4j๏ Focus on Spring Data Neo4j๏ VMWare is collaborating with Neo Technology, the company behind    the Neo4...
Graphs areeverywhere             13
Even in the Matrix                           - everything is a grpah      Google Image Search: „graph OR network“         ...
Graphs Everywhere ๏ Relationships in    • Politics, Economics, History, Science,Transportation ๏ Biology, Chemistry, Physi...
Good Relationships๏ the world is rich, messy and related data๏ relationships are as least as important as the things they ...
Questions and Answers๏ Complex Questions๏ Answers lie between the lines (things)๏ Locality of the information๏ Global sear...
Categories ?๏ Categories == Classes, Trees ?๏ What if more than one category fits?๏ Tags๏ Categories vi relationships like ...
Fowler & Christakis „Connected“                                  19
New York Times R&D „Cascade“                               20
Deb Roy - MIT & Bluefin Labs                    „Birth of a Word“ TED Talk                    Researches Social Reactions  ...
Neo4j introduction
What is Neo4j?                 data model
What is Neo4j?                      data model           A Graph Database
What is Neo4j?                      data model           A Graph Database
What is Neo4j?                      data model           A Graph Database
What is Neo4j?                          data model               A Graph Database        Node                           Node
What is Neo4j?                                    data model               A Graph Database                   Typed relati...
What is Neo4j?                                     data model                A Graph Database         Node       Typed rel...
For example
For example   name: Oliver
For example   name: Oliver   name: Michael
For example                  WORKS_WITH                  project: spring-data   name: Oliver                          name...
For example                        WORKS_WITH                        project: spring-data   name: Oliver                  ...
For example                                 name: Rod                                                     KN              ...
For example                                       name: Rod                                                           KN  ...
Best NOSQL Database for Spring ?Why ? Explain !•Written in Java•Embeddable or standalone Server•Schema-free - perfect for ...
Whiteboard friendly
Whiteboard friendly                            Ally’s                            Blog                       NS            ...
Whiteboard friendly         Blog         Post     BEL                        ON                          GS               ...
Whiteboard friendly         Blog         Post     BEL                        ON                          GS               ...
Whiteboard friendly         Blog         Post     BEL                        ON                          GS               ...
Show me some code, pleaseGraphDatabaseService graphDb =   new EmbeddedGraphDatabase(“var/neo4j”);Node david = graphDb.crea...
Show me some code, pleaseGraphDatabaseService graphDb =   new EmbeddedGraphDatabase(“var/neo4j”);Transaction tx = graphDb....
Traversal framework
Traversal frameworkExample: a dependency graph      A            B                              D  C
Traversal frameworkExample: a dependency graphQuery: Find all dependencies of A, transitively       A              B      ...
Traversal frameworkExample: a dependency graphQuery: Find all dependencies of A, transitively       A              B      ...
Traversal frameworkExample: a dependency graphQuery: Find all dependencies of A, transitively       A              B      ...
Traversal frameworkExample: a dependency graphQuery: Find all dependencies of A, transitively       A              B      ...
Traversal frameworkExample: a dependency graphQuery: Find all dependencies of A, transitively               A             ...
So how do I find a nodeto traverse from?                     ?
So how do I find a nodeto traverse from?                               g!                             in                  ...
So how do I find a nodeto traverse from?                               g!                             in                  ...
So how do I find a nodeto traverse from?                               g!                             in                  ...
So how do I find a nodeto traverse from?                               g!    Andreas                             in       ...
Cypher Query Language๏ Declarative query language   • Describe what you want, not how   • Based on pattern matching๏ Examp...
Cypher Query Language                 (E                                         xp๏ Declarative query language        en ...
Beyond basics๏ Graph algorithm library   • Cheapest path (Dijkstra, A*)   • Shortest path   • Simple paths   • All paths๏ ...
Spring Data Neo4j
Spring Framework Conveniences ๏ default enterprise development framework ๏ future Java Cloud stack ๏ POJO centric applicat...
Programming model overview ๏ SDN is the brain child of Rod Johnson and Emil Eifrém    • Wrote functional initial prototype...
Spring Data Neo4j features๏ Annotation-based programming model๏ Spring Data Commons Repository support๏ Neo4j Query (Cyphe...
Classic Neo4j domain classpublic class Actor {    private final Node underlyingNode;    Actor( final Node node ) {        ...
Spring Data Neo4j domain class@NodeEntitypublic class Actor {    @Indexed    private String name;    public String getName...
What about relationships@NodeEntityclass Actor {  ...  public Iterable                  <Movie> getMovi    final List<Movi...
Defining entity classes
Defining entity classes• @NodeEntity    • Represents a node in the graph    • Fields saved as properties on node    • Refe...
Defining entity classes
Defining entity classes• @RelationshipEntity    • Represents a relationship in the graph    • Fields saved as properties o...
Fields in node entities (@NodeEntity)• Primitive types and strings are directly persisted• For all other types, Spring con...
Fields in node entities (@NodeEntity)• Fields of types that represent a node (@NodeEntity)                                ...
Fields in node entities (@NodeEntity)• Fields of types that represent a node (@NodeEntity) @NodeEntity public class Movie ...
Fields in node entities (@NodeEntity)• Fields of types that represent a node (@NodeEntity) @NodeEntity public class Movie ...
Fields in node entities (@NodeEntity)• Fields of collections of node entities: @RelatedTo  @NodeEntity  public class Movie...
Fields in node entities (@NodeEntity)๏ Fields of collections of relationship entities: @RelatedToVia  @RelationshipEntity ...
Fields in relationship entities(@RelationshipEntity)• Primitive and convertible types work just the same• @StartNode and @...
IndexingBy annotating an entity field with @Indexed it becomes searchable:   @NodeEntity   public class Actor {     @Indexe...
Indexing @NodeEntity public class Actor {   @Indexed(type = FULLTEXT)   private String name;๏ Index name defaults to domai...
Traversal@NodeEntitypublic class Actor {  @GraphTraversal(     traversalBuilder = CoactorsTraversalDescriptionBuilder.clas...
Cypher query language@NodeEntitypublic class Actor {  @Query(“START actor=({self}) ” +         “MATCH (actor)-[:ACTS_IN]->...
Spring-Data-Mapping ๏ Based on Spring-Data-Commons infrastructure    • Extract Mapping Meta Information      ‣Neo4jPersist...
AspectJ ๏ Introduces interface to entities:     • NodeBacked into @NodeEntity classes     • RelationshipBacked into @Relat...
AspectJ - Tooling ๏ IDE‘s    • latest versions of STS / Eclipse with current AJDT plugin    • IntelliJ IDEA 10.5 compile +...
AspectJ - NodeBacked.relateTo<T extends RelationshipBacked> T NodeBacked.relateTo(    NodeBacked node,    Class<T> relatio...
Interface based Repositories๏ based on Repository infrastructure in Spring Data Commons๏ just define the interface and the ...
Repositoriesinterface MovieRepository extends GraphRepository<Movie> {    Movie findById(String id);    Page<Movie> findBy...
Other repository query methodsActor jeffGoldblum = actorRepo.findOne(42);boolean actorExists = actorRepo.exists(42);Iterab...
Repository-Query-Supportinterface MovieRepository extends GraphRepository<Movie> {    @Query("start m=({movie}) match m-[A...
Neo4j-Template (I)๏ well known Spring Template Pattern๏ Resource / Transaction Management๏ Convenience Methods๏ Nodes and ...
Neo4j-Template (II)template.lookup("node", "name", "David")   .to(String.class, new PropertyContainerNameConverter()).sing...
REST-Client-Support   <bean id="restGraphDatabaseService"         class="org.sf.data.neo4j.rest.SpringRestGraphDatabase"> ...
REST-Server-Supportpublic class HelloWorldInitializer extends SpringPluginInitializer {    public HelloWorldInitializer() ...
Cross-store persistence
A scenario...You have a traditional web app using JPA to persist data to a relational  database
Option C: Introducing cross-store	 persistence ๏ JPA data and NOSQL data can share a data model ๏ Could be the entire enti...
The JPA data model              Restaurant                           UserAccount      @Entity                       @Entit...
Adding to the data model                Restaurant                              UserAccount       @Entity                 ...
Adding to the data model                Restaurant                              UserAccount       @Entity                 ...
Adding to the data model                Restaurant                              UserAccount       @Entity                 ...
Adding to the data model                Restaurant                              UserAccount       @Entity                 ...
Adding to the data model                Restaurant                              UserAccount       @Entity                 ...
Spring Data Neo4j Roo add-on๏ Roo adding support for non-JPA    persistence providers๏ Spring Data Neo4j was the first    N...
Spring Data Neo4j Roo add-onroo> project --topLevelPackage org.neo4j.imdbroo> graph setup --provider NEO4J --databaseLocat...
Spring Data Neo4j Guidebook                       “Good Relationships”“I’m excited about Spring Data Neo4j.... Spring Data...
The end (and the beginning!) ๏ See the Spring Data Neo4j site for more info:      http://spring.neo4j.org ๏ Check out the ...
Cineasts.net Check Out: http://spring.neo4j.org/tutorial
