Professional Tools for Embedded LinuxJeff Osier-Mixon, Intel CorporationYocto Project Community ManagerOSCON | 7/19/2012© ...
[ yoc-to ]The smallest unit of measure,equal to one septillionth (10-24). Agenda:  Introduction  Development Process  G...
Introduction
Introducing the Yocto Project    •        Overall goals    •        Project components    •        Governance    •        ...
Introducing the Yocto Project    → Overall Goals    •        Unify the embedded Linux development experience by providing ...
Introducing the Yocto Project    → Overview    [video: https://vimeo.com/24743626]    Yocto Project presentation @ OSCON 2...
Introducing the Yocto Project    → Project Components    •        Build system                 – Poky reference system    ...
Introducing the Yocto Project    → Governance    •         Open source umbrella project    •         Organized under the L...
Introducing the Yocto Project    → Governance: Roles                                                          Technical Te...
Introducing the Yocto Project     → Governance: Relationships                                                        The L...
Introducing the Yocto Project     → Governance: Relationships                                                             ...
Development
Development Process     •        Build system components     •        Workflow diagram     •        Adjustment points     ...
Development Process     → Build System Components     •        BitBake: build engine, follows metadata instructions     • ...
Development Process     → Build System Components: BitBake     •        Build engine, originally derived from Portage     ...
Development Process     → Build System Components: Layers     •        openembedded-core                  – Core classes a...
Development Process     → Build System Components: Poky     •        Reference build system – a representation of the Yoct...
Development Process     → Workflow Diagram     Yocto Project presentation @ OSCON 201218   © 2012 The Linux Foundation. Al...
Development Process     → Adjustment Points     •        During development     •        Configuration     •        During...
Getting Started
Getting Started     •        Download     •        Configure your environment     •        Configure the image     •      ...
Getting Started     → Download     •        Tarball (packaged release):                $ wget http://downloads.yoctoprojec...
Getting Started     → Configure Your Environment     •   Install required packages (Ubuntu shown):         $ sudo apt-get ...
Getting Started     → Configure the Image     # This file is your local configuration file and is where all local user set...
Getting Started     → Build & Rebuild     Pseudo is not present but is required, building this first before the main build...
Getting Started     → Build & Rebuild     NOTE: Running task 1 of 63 (ID: 11, /Mondo/poky/poky/meta/recipes-devtools/quilt...
Getting Started     → A Look at Hob     Yocto Project presentation @ OSCON 201227   © 2012 The Linux Foundation. All right...
More information at yoctoproject.orgThank You!
