Model-Driven Engineering of User Interfaces: Promises, Successes, Failures, and Challenges Jean Vanderdonckt Université ca...
Talk’s outline <ul><li>What is model-based UI design? </li></ul><ul><ul><li>What is a UI model? </li></ul></ul><ul><ul><li...
What is the today’s situation regarding user interfaces? <ul><li>Technological aspects of user interfaces progress signifi...
What is model-based UI design? <ul><li>Classical approch to developing UIs with a UI builder (IDE) </li></ul><ul><ul><li>D...
What is model-based UI design? <ul><li>UI builders offer only partial solution </li></ul>Desired Interface <ul><li>Table w...
What is model-based UI design? <ul><li>UI builders cannot produce their own UI (no bootstrapping) </li></ul>
What is model-based UI design? <ul><li>Classical approch to developing UIs </li></ul><ul><ul><li>Advantages </li></ul></ul...
What is model-based UI design? <ul><li>Model-based UI design consists of </li></ul><ul><ul><li>Describing a UI in a UI mod...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Webster’s definitions: </li></ul></ul><ul><u...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>A simple example for understanding purposes:...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Finding the right model abstractions IS </li...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Finding the right model abstractions IS </li...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Because different evolutions </li></ul></ul>...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Because different evolutions </li></ul></ul>
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>Because same widget appears in many differen...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>In order to derive UIs systematically </li><...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>In order to derive UIs systematically </li><...
What is model-based UI design? <ul><li>What is a model? </li></ul><ul><ul><li>In order to derive UIs systematically </li><...
What is model-based UI design? <ul><li>What do we need to get a quality UI model? </li></ul><ul><ul><li>Abstractions are a...
What do we have so far? <ul><li>With this first set of abstractions, we go from Final UI (FUI) to Concrete UI (CUI) </li><...
And now what? <ul><li>UIs are not only graphical, but could be vocal, tactile, 3D, haptic, an multimodal </li></ul><ul><li...
What do we have so far? <ul><li>With this second set of abstractions, we go from CUI to Abstract UI (AUI) </li></ul><ul><l...
And now what? <ul><li>UIs, even if they are abstract, are structured according to the target system as opposed to be user-...
What do we have so far? <ul><li>With this third set of abstractions, we go from AUI to Task and Domain (T+D) </li></ul><ul...
Do we need  more models? <ul><li>Users want to determine their path on each platform </li></ul>[Forrester Research,2003]
Do we need more models? Demo FlashiXML
Do we need more models? <ul><li>Multiplicity of contexts of use </li></ul>TV is multi-media family device #1 Family Device...
Do we need more models? <ul><li>Property of plasticity = adaptation to the context of use while satisfying predefined usab...
So what we have now is Concrete user Interface S Final user Interface S Task and  Domain S Abstract user Interface S S=Sou...
Multi-platform for Emergency <ul><li>Three platforms </li></ul><ul><ul><li>Pocket PC </li></ul></ul><ul><ul><li>Desktop PC...
Multi-platform for Emergency <ul><li>Model and method </li></ul><ul><ul><li>Design the reference screen first </li></ul></...
Graceful degradation [Florins & Vanderdonckt,2004]
Transformation rules
Transformation rules Add all >> Add > << Remove all < Remove >> > << < > < Group box Item 1 Item 2 Item 3 Item 4 Item 5 It...
Transformation rules
What do we have now <ul><li>Cameleon Reference Framework </li></ul>Final user Interface T Concrete user Interface T Task a...
Other challenges raised <ul><li>C2: Need to cover </li></ul><ul><ul><li>Semantics: metamodel as a UML Class Diagram </li><...
Towards model-driven engineering <ul><li>Possible definition </li></ul><ul><ul><li>MDA is an OMG initiative that proposes ...
Towards model-driven engineering <ul><li>C5: Keep decision decision as SDLC is evolving </li></ul><ul><ul><li>Support for ...
Example of preference-based design <ul><li>Goal = to input the temperature of a human body </li></ul><ul><ul><li>Solution ...
How to argue for preference? <ul><li>Use the QOC notation </li></ul>Question? [McLean & Belotti,1998] Criteria 1 Criteria ...
Preference example Problem Solution 1 Solution 2 (RE1) (RE2) suggests suggests avoids contradicts respects = for = against...
Theory of argumentation [Toulmin,1975] [Perelman, 1978] Design problem Design option parameter (parameter, value) Is descr...
Towards model-driven engineering <ul><li>C6: Need to support (de)composition </li></ul>Demo FormiXML
Towards Model-Driven Engineering <ul><li>C7: Support for multi-path development </li></ul><ul><li>Different types of engin...
Revisitation [Bouillon,2006]
Towards Model-Driven Engineering <ul><li>C8: Support for multi-fidelity </li></ul>Demo SketchiXML
Towards model-driven engineering <ul><li>Other challenges (C13 -> C16) </li></ul><ul><ul><li>High ceiling </li></ul></ul><...
Towards model-driven engineering <ul><li>Other challenges (C13 -> C16) </li></ul><ul><ul><li>High ceiling </li></ul></ul><...
Towards model-driven engineering <ul><li>C17: Effort incrementality and C19: rendering engines </li></ul><ul><ul><li>UsiXM...
Developed by Donatien Grolaux <ul><li>Problem: how to design a UI that takes care of multiple displays? </li></ul><ul><li>...
Demonstration DistriXML [Grolaux & Vanderdonckt,2005]
Demonstration using two displays from two different computers DistriXML
Example using a Pocket PC DistriXML
UI Migration: DEMIPLAT <ul><li>De tach </li></ul>DistriXML
UI Migration: DEMIPLAT <ul><li>De tach -  Mi grate </li></ul>DistriXML
UI Migration: DEMIPLAT <ul><li>De tach -  Mi grate -  Pl astify </li></ul>DistriXML
UI Migration: DEMIPLAT <ul><li>De tach -  Mi grate -  Pl astify -  At tach </li></ul>DistriXML
This is not a floating toolbar Process DistriXML
This is migration ! Computer B Process Process Computer A DistriXML
Towards model-driven engineering <ul><li>C18: More dynamic aspects </li></ul><ul><ul><li>Mixed reality </li></ul></ul>Mino...
Conclusion <ul><li>What can be really supported? </li></ul>[Skezely,1996] 0 2000 4000 6000 8000 10000 12000 14000 16000 Wo...
Conclusion <ul><li>Successes: </li></ul><ul><ul><li>Work for very-well defined domains </li></ul></ul><ul><ul><li>Really f...
How to participate? <ul><li>Join the UsiXML Consortium today! </li></ul><ul><ul><li>Anybody can be a member: observer, par...
How to participate? <ul><li>Develop web services for UsiXML </li></ul><ul><li>Open positions in UsiXML project (from April...
Thank you very much for your attention For more information and downloading, http://www.isys.ucl.ac.be/bchi   http://www.u...
