Programming Social Applications Programming Social Applications Presentation Transcript

  • Programming Social Applications
    Jonathan LeBlanc
    Principal Software Engineer
    Yahoo! Developer Network
    Twitter: @jcleblanc
    Web: http://www.jcleblanc.com
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • Core Concepts: What is a Social Application?
  • Core Concepts: What Makes up a Social Application?
    The Social Graph
    Sharing Model
    Relationship Model
  • Core Concepts: The Social Graph
  • Core Concepts: Applying the Real Life Social Graph Online
  • Core Concepts: The Different Sharing Models
    The Opt-in Model
    The Opt-out Model
  • Core Concepts: Relationship Models
    Follower Model
    Connection Model
    Group Model
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • WebFinger
    http://code.google.com/p/webfinger/
  • WebFinger: Origin Through the Finger Protocol
    finger jleblanc@yahoo-inc.com
    Login name: jleblanc
    In real life: Jonathan LeBlanc
    Home phone: 123-4567
    Office: Sunnyvale, CA
    Last Login: Tue Jun 21 15:41 on ttys000
    jleblanc@yahoo-inc.com
    http://www.jcleblanc.com
  • WebFinger: How it Works
  • WebFinger: How it Works
  • WebFinger: How it Works
  • WebFinger: PerformingWebFinger Discovery
    curl http://gmail.com/.well-known/host-meta
    <XRD xmlns='http://docs.oasis-open.org/ns/xri/xrd-1.0'
    xmlns:hm='http://host-meta.net/xrd/1.0'>
    <hm:Hostxmlns='http://host-meta.net/xrd/1.0'>
    gmail.com</hm:Host>
    <Link rel='lrdd' template=
    'http://www.google.com/s2/webfinger/?q={uri}'>
    <Title>Resource Descriptor</Title>
    </Link>
    </XRD>
  • WebFinger: PerformingWebFinger Discovery
    curl http://www.google.com/s2/webfinger/?q=nakedtechnologist@gmail.com
    The User Profile: http://www.google.com/profiles/nakedtechnologist
    The portable contacts link: http://www-opensocial.googleusercontent.com/api/people/118167121283215553793/
    The public Google Buzz feed: https://www.googleapis.com/buzz/v1/activities/118167121283215553793/@public
  • WebFinger: Homework
    Using the well-known host-meta file, attempt to obtain your public profile from www.yahoo.com
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • The Open Graph Protocol
    http://ogp.me/
  • Open Graph Protocol: How Web Semantics Work
  • Open Graph Protocol: How Web Semantics Work
    Geo
    <span class="geo">
    <span class="latitude">52.48</span>,
    <span class="longitude">-1.89</span>
    </span>
    vCard
    <div class="vcard">
    <div class="fn">Joe Doe</div>
    <div class="org">The Example Company</div>
    <div class="tel">604-555-1234</div>
    <a class="url" href="http://site.com/">http://site.com/</a>
    </div>
  • Open Graph Protocol: Vision of the Semantic Web
  • Open Graph Protocol: Reality of the Semantic Web
  • Open Graph Protocol: What Changed?
  • Open Graph Protocol: How it Works
  • Open Graph Protocol: How it Works
  • Open Graph Protocol: How it Works
  • Open Graph Protocol: The Meta Data Format
    <html xmlns:og="http://ogp.me/ns#">
    <head>
    <title>Restaurant at Wente Vineyards – Livermore</title>
    <meta property="og:url"
    content="http://www.yelp.com/biz/gATFcG9HTaXJpg">
    <meta property="og:type" content="restaurant">
    <meta property="og:title"
    content="The Restaurant at Wente Vineyards">
    <meta property="og:image"
    content="http://media2.px.yelpcdn.com/iVSnIs">
    ...
    </head>
    ...
    </html>
  • Open Graph Protocol: What is Defined?
    • Basic Metadata
    • Location
    • Contact Information
    • Video Data
    • Audio Data
    • Objects
    • Activities
    • Businesses
    • Groups
    • Organizations
    • People
    • Places
    • Products and Entertainment
    • Websites
  • Open Graph Protocol: Drawbacks
    How do we differentiating like objects from one another?
    How do we define definitions for an entire page versus a single object?
  • Open Graph Protocol: Homework
    Construct an Open Graph meta-data parser, then extract Open Graph meta-data from a restaurant page on www.yelp.com
    Hint: The www.ogp.me page has parser helpers.
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • Activity Streams
    http://activitystrea.ms/
  • Activity Streams: What is an Activity?
  • Activity Streams: What is an Activity?
    Mary added to a new photo into her collection.
    • Mary: The Actor
    • Photo: The Object
    • Collection: The Target
  • Activity Streams: The Standard JSON Object
    {
    "items" : [{
    "verb": "post",
    "published": "2011-02-18T16:26:43Z",
    "provider": {
    "url": "http://providersite.com/activity-stream"
    },
    "title": "Mary added a photo to her album.",
    "actor": { ... },
    "object" : { ... },
    "target": { ... }
    }]
    }
  • Activity Streams: The Actor
    Mary added to a new photo into her collection.
    "actor": {
    "url": "http://providersite.com/mary",
    "objectType": "person",
    "id": "tag:provider.com,20110218,162643:mary",
    "image": {
    "url": "http://providersite.com/mary/image",
    "width": 125,
    "height": 125
    },
    "displayName": "Mary Smith"
    },
  • Activity Streams: The Object
    Mary added to a new photo into her collection.
    "object" : {
    "url": "http://site.com/mary/album/place.jpg",
    "objectType": "http://activitystrea.ms/schema/1.0/photo",
    "id": "tag:provider.com,20110218,162643:place",
    "image": {
    "url": "http://site.com/mary/album/thumb.jpg",
    "width": 100,
    "height": 100
    }
    },
  • Activity Streams: The Target
    Mary added to a new photo into her collection.
    "target": {
    "url": "http://targetsite.com/mary/album/",
    "objectType": "http://activitystrea.ms/schema/1.0/
    photo-album",
    "id": "tag:example.org,20110218,162643:album4323",
    "displayName": "Mary's Photo Album",
    "image": {
    "url": "http://site.com/mary/album/thumbnail.jpg",
    "width": 100,
    "height": 100
    }
    }
  • Activity Streams: Object Properties
    Object Properties
    attachments
    author
    content
    display
    name
    downstreamDuplicates
    id
    object
    type
    published
    summary
    updated
    upstreamDuplicates
    url
    url
    width
    Media Object Properties
    duration
    height
  • Activity Streams: Homework
    Take one of your activities (with a photo) from Facebook and convert it to an activity stream object.
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • PubSubHubbub
    http://code.google.com/p/pubsubhubbub/
  • PubSubHubbub: How it Works
  • PubSubHubbub: How it Works
  • PubSubHubbub: How it Works
  • PubSubHubbub: How it Works
  • PubSubHubbub: How it Works
  • The Salmon Protocol
    www.salmon-protocol.org
  • The Salmon Protocol: How it Works
  • The Salmon Protocol: How it Works
  • The Salmon Protocol: How it Works
  • The Salmon Protocol: Things to Consider
    • Is the content coming from a trusted source?
    • How does the publisher prevent spam or abuse?
    • How does the publisher ensure the quality of the updates?
  • The Salmon Protocol: Determining Source
    Subscriber sends signed request to publisher (e.g. using acct:johndoe@subscriber.example.com).
    Publisher performs discovery on endpoint to verify identity provider.
    • Webfinger
    • LRDD (Link-based Resource Descriptor)
    Provider verifies signature via public keys obtained during discovery.
  • Pubsubhubbub and Salmon: Homework
    Construct a subscriber to subscribe to a hub, then create a publisher to push a feed to a hub.
    Hint: www.superfeedr.com has a hosted hub solution at http://superfeedr.com/hubbub
  • What We’re Going to Cover
    • The Social Application: Core Concepts
    • Finger to Webfinger: Find User Social Data
    • Return of the Semantic Web: The Open Graph Protocol
    • Defining User Actions: Activity Streams
    • Controlling Content Syndication: PubSubHubbub and Salmon
  • Resources
    This Presentation:
    http://www.slideshare.net/jcleblanc/programming-social
    Code Sources:
    https://github.com/jcleblanc/programming-social-applications
    Purchase the Book:
    Amazon:http://amzn.to/mQrUkE
    O’Reilly:http://oreil.ly/gzEKiM
    O’Reilly ebook code (50% off): DDM97
    Follow Updates:
    Facebook:www.facebook.com/programmingsocialapps
    Twitter: @socialappsbook
  • Questions?
    http://www.slideshare.net/jcleblanc/slideshare.net/jcleblanc/programming-social
    Jonathan LeBlanc
    Twitter: @jcleblanc
    E-Mail: jleblanc@yahoo-inc.com
