1. J SR-2 9 9
Co n t e x t & De p e n d e n c y
Injec t ion
Max Rydahl Andersen
JBossian, Red Hat
27th. November
1

2. Ro a d M a p
Background
Concepts
Status
2 M a x Ry d a h l A n d e r s e n

3. J av a EE 6
• The EE 6 web profile removes most of the “cruft” that
has developed over the years
• mainly totally useless stuff like web services, EJB 2 entity
beans etc.
• some useful stuff (e.g. JMS) is missing, but vendors can
include it
3 M a x Ry d a h l A n d e r s e n

4. J av a EE 6
• EJB 3.1 - asynch, no-interface views, embeddable
• JPA 2.0 - typesafe criteria API, many more O/R mapping
options
• JSF 2.0 - Ajax, easy component creation, bookmarkable
URLs
• Bean Validation 1.0 - annotation-based validation API
• Servlet 3.0 - async support, better support for
frameworks
• Standard global JNDI names
• Managed Beans
4 M a x Ry d a h l A n d e r s e n

5. Managed Beans
• Container-managed POJOs with minimal requirements
• support a set of basic services
• resource injection
• lifecycle callbacks
• interceptors
5 M a x Ry d a h l A n d e r s e n

6. Managed Beans
• the foundation for all other component types in the
platform
• core services centralized under Managed Beans
• Other specifications will add support for additional
services
• remoting
• instance pooling
• web services
6 M a x Ry d a h l A n d e r s e n

7. Go a l s
• JSR-299 defines a unifying dependency injection and
contextual lifecycle model for Java EE 6
• a completely new, richer dependency management
model
• designed for use with stateful objects
• integrates the “web” and “transactional” tiers
• makes it much easier to build applications using JSF and
EJB together
• includes a complete SPI allowing third-party frameworks
to integrate cleanly in the EE 6 environment
7 M a x Ry d a h l A n d e r s e n

8. Loose c oupling
• Events, interceptors and decorators enhance the loose-
coupling that is inherent in this model:
• event notifications decouple event producers from event
consumers
• interceptors decouple technical concerns from business
logic
• decorators allow business concerns to be
compartmentalized
8 M a x Ry d a h l A n d e r s e n

9. Go i n g b e yo n d t h e s p e c
• Weld provides extra integrations
• Tomcat/Jetty/Google App Engine support
• Java SE support
• OSGi containers
• ???
9 M a x Ry d a h l A n d e r s e n

10. Go i n g b e yo n d t h e s p e c
• and features which can be used in any CDI
environment
• Seam2 bridge
• Spring bridge
• Wicket support
• Logger
• Prototype new ideas for the next version of the spec
10 M a x Ry d a h l A n d e r s e n

11. Se a m 3
• Use the CDI core
• Provide a development environment
• JBoss Tools
• Seam-gen (command line tool)
11 M a x Ry d a h l A n d e r s e n

12. Se a m 3
• include a set of modules for any container which
includes CDI
• jBPM integration
• Seam Security
• Reporting (Excel/PDF)
• Mail
• etc.
12 M a x Ry d a h l A n d e r s e n

13. Ro a d M a p
Background
Concepts
Status
13 M a x Ry d a h l A n d e r s e n

14. Es s e n t i a l i n g r e d i e n t s
• API types
• Qualifier annotations
• Scope
• Alternatives
• A name (optional)
• Interceptors and Decorators
• The implementation
14 M a x Ry d a h l A n d e r s e n

15. Si m p l e Ex a m p l e
public class Hello { Any Managed Bean
public String sayHello(String name) {
return "hello" + name; can use these
} services
}
@Stateless So can EJBs
public class Hello {
public String sayHello(String name) {
return "hello" + name;
}
}
15 M a x Ry d a h l A n d e r s e n

16. Si m p l e Ex a m p l e
public class Printer { @Inject defines an
injection point. @Default
@Inject Hello hello; qualifier is assumed
public void printHello() {
System.out.println( hello.sayHello("world") );
}
}
16 M a x Ry d a h l A n d e r s e n

17. Co n s t r u c t o r i n j e c t i o n
Mark the constructor to be
public class Printer { called by the container
private Hello hello; @Inject
@Inject
public Printer(Hello hello) { this.hello=hello; }
public void printHello() {
System.out.println( hello.sayHello("world") );
}
}
Constructors are injected by
default; @Default is the
default qualifier
17 M a x Ry d a h l A n d e r s e n

18. We b B e a n N a m e s
@Named("hello")
public class Hello {
By default not
public String sayHello(String name) { available through EL.
return "hello" + name;
}
} If no name is specified, then
a default name is used. Both
these Managed Beans have
@Named the same name
public class Hello {
public String sayHello(String name) {
return "hello" + name;
}
}
18 M a x Ry d a h l A n d e r s e n

19. J SF Pa g e
<h:commandButton value=“Say Hello”
action=“#{hello.sayHello}”/>
Calling an action on a
bean through EL
19 M a x Ry d a h l A n d e r s e n

20. Qu a l i f i e r
A qualifier is an annotation that lets a client choose
between multiple implementations of an API at runtime
20 M a x Ry d a h l A n d e r s e n

21. De f i n e a q u a l i f i e r
@Retention(RUNTIME)
@Target({TYPE, METHOD, FIELD, PARAMETER})
@Qualifier
public @interface Casual {} Creating a qualifer
is really easy!
21 M a x Ry d a h l A n d e r s e n

22. Using a qualifier
@Casual
We also specify the
public class Hi extends Hello {
public String sayHello(String name) {
@Casual qualifier. If
return "hi" + name; no qualifer is specified
} on a bean, @Default
} is assumed
22 M a x Ry d a h l A n d e r s e n

23. Using a qualifier
Here we inject the Hello
bean, and require an
public class Printer { implementation which is
@Inject @Casual Hello hello; qualified by @Casual
public void printHello() {
System.out.println( hello.sayHello("JBoss") );
}
}
23 M a x Ry d a h l A n d e r s e n

24. A l t e r n at i ve s
• An alternative bean is one which must be specifically
enabled for a particular deployment
• It replaces the managed or session bean for which it is
an alternative
• May also completely replace it
• all producers and observers defined on original bean are
disabled for this deployment)
• Alternatives enabled in XML deployment descriptor
24 M a x Ry d a h l A n d e r s e n

25. De f i n i n g a n a l t e r n at i ve
@Alternative Same API, different
public class Hola extends Hello { implementation
public String sayHello(String name) {
return "hola " + name;
}
}
25 M a x Ry d a h l A n d e r s e n

26. En a b l i n g a n a l t e r n at i ve
<beans>
<alternatives>
<class>com.acme.Hola</class>
<sterotype>com.acme.SouthernEuropean</stereotype>
</alternatives>
</beans>
Can also define a sterotype as
an alternatives. Any
stereotyped beans will be an
alternative
26 M a x Ry d a h l A n d e r s e n

27. St e r e o t y p e s
• We have common architectural “patterns” in our
application, with recurring roles
• Capture the roles using stereotypes
27 M a x Ry d a h l A n d e r s e n

28. St e r e o t y p e s
• A stereotype encapsulates any combination of:
• a default scope, and
• a set of interceptor bindings.
• A stereotype may also specify that:
• all beans with the stereotype have defaulted bean EL
names
• all beans with the stereotype are alternatives
28 M a x Ry d a h l A n d e r s e n

29. Cr e at i n g a s t e r e o t y p e
@RequestScoped Scope
@Named
@Alternative
@Stereotype Has a defaulted name
@Retention(RUNTIME)
@Target(TYPE)
public @interface AlternativeAction{}
All stereotyped beans
become alternatives
29 M a x Ry d a h l A n d e r s e n

30. Using a st ereot ype
@AlternativeAction
public class Hello {
public String sayHello(String name) {
return "hi " + name;
}
}
30 M a x Ry d a h l A n d e r s e n

31. Sc o p e s a n d Co n t ex t s
• Built-in scopes:
• Any servlet - @ApplicationScoped,
@RequestScoped, @SessionScoped
• JSF requests - @ConversationScoped
• Dependent scope (De fa u l t ): @Dependent
• Custom scopes
• A scope type is an annotation, can write your own
context implementation and scope type annotation
31 M a x Ry d a h l A n d e r s e n

32. Sc o p e s
@SessionScoped
public class Login { Session scoped
private User user;
public void login() {
user = ...;
}
public User getUser() { return user; }
}
32 M a x Ry d a h l A n d e r s e n

33. Sc o p e s
public class Printer {
No coupling between
@Inject Hello hello; scope and use of
@Inject Login login; implementation
public void printHello() {
System.out.println(
hello.sayHello( login.getUser().getName() ) );
}
}
33 M a x Ry d a h l A n d e r s e n

34. Pr o d u c e r m e t h o d s
• Producer methods allow control over the production of a
bean where:
• the objects to be injected are not managed instances
• the concrete type of the objects to be injected may vary
at runtime
• the objects require some custom initialization that is not
performed by the bean constructor
34 M a x Ry d a h l A n d e r s e n

35. Pr o d u c e r m e t h o d s
@SessionScoped
public class Login {
private User user;
public void login() {
user = ...;
}
@Produces
User getUser() { return user; }
}
35 M a x Ry d a h l A n d e r s e n

36. Pr o d u c e r m e t h o d s
public class Printer {
@Inject Hello hello;
@Inject User user; Much better, no
public void hello() { dependency on
System.out.println( Login!
hello.sayHello( user.getName() ) );
}
}
36 M a x Ry d a h l A n d e r s e n

37. Pr o d u c e r Fi e l d s
• Simpler alternative to Producer methods
Similar to
@SessionScoped outjection in
public class Login {
Seam
@Produces @LoggedIn @RequestScoped
private User user;
public void login() {
user = ...;
}
}
37 M a x Ry d a h l A n d e r s e n

38. J av a EE Re s o u r c e s
public class PricesTopic {
@Produces @Prices
@Resource(name="java:global/env/jms/Prices")
Topic pricesTopic;
}
public class UserDatabasePersistenceContext {
@Produces @UserDatabase
@PersistenceContext
EntityManager userDatabase;
}
38 M a x Ry d a h l A n d e r s e n

39. Eve n t s
• Event producers raise events that are then delivered to
event observers by the Web Bean manager.
• not only are event producers decoupled from observers;
observers are completely decoupled from producers
• observers can specify a combination of "selectors" to
narrow the set of event notifications they will receive
• observers can be notified immediately, or can specify that
delivery of the event should be delayed until the end of
the current transaction
39 M a x Ry d a h l A n d e r s e n

40. Ev e n t s Inject an instance of Event. Additional
qualifiers can be specified to narrow the
event consumers called. API type
specified as a parameter on Event
public class Hello {
@Inject @Any Event<Greeting> greeting;
public void sayHello(String name) {
greeting.fire( new Greeting("hello " + name) );
}
}
“Fire” an event, the
producer will be notified
40 M a x Ry d a h l A n d e r s e n

41. Ev e n t s
Observer methods, take the API
public class Printer { type and additional qualifiers
void onGreeting(@Observes Greeting greeting,
@Default User user) {
System.out.println(user + “ says “ + greeting);
}
}
Additional parameters can
be specified and will be
injected by the container
41 M a x Ry d a h l A n d e r s e n

42. Ro a d M a p
Background
Concepts
Status
42 M a x Ry d a h l A n d e r s e n

43. J SR-2 9 9 : Co n t ex t s a n d De p e n d e n c y
I n j e c t i o n fo r J av a EE
• Proposed Final Draft 2 published
• Reference Manual being written now
• http://www.seamframework.org/Weld
• look for an update soon!
• Send feedback to jsr-299-comments@jcp.org
43 M a x Ry d a h l A n d e r s e n

44. We l d
• The Reference implementation
• Feature complete preview of PFD2. Download it, try it
out, give feedback!
• http://seamframework.org/Download
• Working on second release candidate
44 M a x Ry d a h l A n d e r s e n

45. We l d
• Integrated into:
• JBoss 5.1.0.GA and above (6.0.0.Beta1 coming soon)
• GlassFish V3 (get a recent build)
• Available as an addon for:
• Tomcat 6.0.x
• Jetty 6.1.x
• Java SE
• Google App Engine
45 M a x Ry d a h l A n d e r s e n

46. J B o s s CDI To o l s (Wo r k i n p r o g r e s s )
• Code completion for @Named components
• Validation of CDI constructs (”red squigly lines”)
• Ambigious injection points
• Non-matching injection
•…
• CDI component explorer
• Show possible injection points for a given line
• Show matching event types
• Refactoring of EL result in updates to @Named
• ...
46

47. Q& A
http://in.relation.to/Bloggers/Max
http://www.seamframework.org/Weld
http://jcp.org/en/jsr/detail?id=299
47 M a x Ry d a h l A n d e r s e n
