Building loosely coupled and   scalable systems using Event-Driven Architecture         Jonas Bonér       Patrik Nordwall ...
Why is EDA Important for Scalability?
What building blocks does EDA consists of?
OutlineConcepts        Patterns               ChallengesHighly Scalable Web Sites
Concepts
MessagingPublish-Subscribe Point-to-Point Store-forward Request-Reply
Publish-Subscribe
Point-to-Point
Store-Forward
Request-Reply
StandardsAMQP JMS
Some Products                ...
Domain Events“Its really become clear to me in the lastcouple of years that we need a new buildingblock and that is the Do...
Domain Events“State transitions are an important part of ourproblem space and should be modeled withinour domain.”        ...
Domain Events Something that hashappened in the past    CustomerRelocated      CargoShippedInventoryLossageRecorded
Domain EventsUniquely identifiable               Self containedObservable                 Time relevant
Patterns
Event Stream Processingselect  *  from  Withdrawal(amount>=200).win:length(5)
Actors• Share NOTHING• Isolated lightweight processes• Communicates through messages• Asynchronous and non-blocking• No sh...
ActorsEasier to reason aboutRaised abstraction level    Easier to avoid    Race conditions      Deadlocks      Starvation ...
ActorsTransparent remoting  • Client-managed  • Server-managedPub-Sub  • Redis  • ZeroMQGuaranteed deliveryPersistent mail...
Command and Query  Responsibility Segregation“A single model cannot be appropriatefor reporting, searching andtransactiona...
CQRS•   Aggregate roots receive Commands and    publish Events•   All state changes are represented by    Domain Events•  ...
The traditional way...                 DB              Data access               Domain               Service     Update  ...
The CQRS way...    DB                                            DBData access              publish       subscribe  Domai...
The CQRS way...                                DB   DB                       Data access                              Serv...
CQRS Benefits•   Separation of concern•   Fully encapsulated domain that only    exposes behavior•   Queries do not use the...
Event Sourcing• Every state change is materialized in an Event• All events are stored in an Event Log• System can be reset...
Storing Structure            *   Line Item Purchase  Order                 Shipping                Information
Event Sourcing -       Storing Deltas                              Shipping Cart     Added 2   Added 2                    ...
Aggregates are tracking events as to   what has changed within them   Current state is constructed by        replaying all...
Event Sourcing -        Replaying Events1   2      3   4    5      6   7
Event Sourcing -        Rolling Snapshot               Snapshot1   2   ...   100     101   102   103   104
Event Sourcing -              Benefits•   No object-relational impedance mismatch•   Bullet-proof auditing and historical t...
Simple CQRS Samplehttp://github.com/patriknw/    sculptor-simplecqrs/
Challenges
Clustering of BrokersActiveMQ•   Master-Slave•   Store and Forward Network of BrokersRabbitMQ•   Cluster of Erlang nodesZe...
ZeroMQNetwork protocol - thin layer above TCP/IPTransports         Text• INPROC• IPC• MULTICAST• TCP
ZeroMQForwarding devices• QUEUE• FORWARDER• STREAMER
ZeroMQPatternsREQUEST/REPLY (load-balanced)PUB/SUBUPSTREAM/DOWNSTREAM (pipelining)PAIR (exclusive)
Wire FormatsJava serialization (binary, schema, runtime)Protobuf (binary, schema, compiled)Avro (binary, schema, compiled ...
Guaranteed DeliveryDo I really need it?Persistence increasesreliability at the expenseof performance
Competing Consumers                                     Pattern for solving:                                     •   Load ...
Duplicate Messages  What do I need?  • Once-and-only-once  • At-least-once  • At-most-once               QOS              ...
How to get back on track?Point-to-point: no problem, justmake the queue persistentPub/sub: well, not so straightforward  P...
Producer Flow ControlWhat to do when producers flood youwith messages?Running low on broker resources, slowconsumersGracefu...
Behind the Scenes of Highly    Scalable Web Sites
caching is important, but also...
Minimize latencyFlickr: Do The Essential Work Up-Front And Queue The Rest             Amazon: ~99% of content is staticRed...
Changes - pull or pushFacebook: Pull on Demand               Digg: Push on ChangeTwitter: Push tweets
Truly event-driven web clientsRequest-response doesntfit collaborative systems      WebSockets enable real event-      driv...
Why is EDA Important for          Scalability?• Scale out and up• Load balance• Parallel execution• Non-blocking• Loosely ...
?
thanksfor listening
