IB Biology2 Cells2.4 Cell MembranesAll syllabus statements ©IBO 2007All images CC or public domain or link to original mat...
2.4.1 Draw and label a diagram to show the structure of membranes.                                                        ...
2.4.2 Explain how the hydrophobic and hydrophilic properties of phospholipids help to maintainthe structure of cell membra...
The Oil droplet stays together and makesa perfect circular shape.                               The oil                   ...
Phospholipid                                          molecules have a                                            polar (c...
When put into water, an emergent property is thatphospholipids will self-organise to keep their heads            ‘wet’ and...
In this 3D representation    you can see that a phospholipid bilayer is  one way that the tailscan be removed from the    ...
But wait! there’s more!The plasma membrane is not just made of             phospholipids           http://commons.wikimedi...
Proteins:Integral proteins are permanently embedded, many go all the waythrough and are polytopic (poly = many, topic = su...
Beta-secretase 1               (peripheral) has a role                    in creating myelin                              ...
Glycoproteins:Are proteins with an oligosaccaride (oligo = few, saccharide = sugar)chain attached.They are important for c...
Cholesterol: (It’s not all bad!)It makes the phospholipids pack more tightly and regulates thefluidity and flexibility of ...
2.4.3 List the functions of membrane proteins         List: Give a sequence of names or other brief answers with no explan...
1    Cell Adhesion Molecules:    Enable cells to make tight    connections to one    another                              ...
2   Channel Proteins: Allow or help ions and large molecules to    pass through the membrane by diffusion                 ...
3   Protein Pumps move ions    across the membrane to    create and maintain    concentration gradients.    They require e...
4   Hormone Binding sites (hormone    receptors) bind to specific hormones and    start signalling processes to change the...
5   Cell to cell communication:    e.g. receptors for    neurotransmitters at    synapses                               Ou...
6                                             Enzymes on the surface of                                              the c...
2.4.4 Define diffusion and osmosis     What is                                     http://www.flickr.com/photos/dpup/33389...
Diffusion, is the motion of all (liquid or gas) particles attemperatures above absolute zero.• The rate of this movement r...
1. Grab your classmates or a group     Simulate!                of friends.                           2. Take one die each...
What is  osmosis?          http://www.flickr.com/photos/luchilu/399970490/
Osmosis may occur when there is a partiallypermeable membrane, such as a cellmembrane.When a cell is submerged in water, t...
Theimportanceof osmoticcontrol             http://commons.wikimedia.org/wiki/File:Osmotic_pressure_on_blood_cells_diagram....
2.4.5 Explain passive transport across membranes in terms of simple diffusion and facilitateddiffusion.          Simple   ...
Facilitated Diffusion:Large and polar molecules can’t get across the membrane viasimple diffusionTransmembrane (polytopic)...
2.4.6 Explain the role of protein pumps and ATP in active transport across membranes    Primary active transport requires ...
In secondary active transport, the required energy isderived from energy stored in the form of concentrationdifferences in...
Typically, theconcentrationgradient of thesecond solute wascreated by primaryactive transport,and the diffusion ofthe seco...
2.4.7 Explain how vesicles are used to transport materials within a cell between the roughendoplasmic reticulum, Golgi app...
2.4.8 Describe how the fluidity of the membrane allows it to change shape, break and reformduring endocytosis and exocytos...
Constitutivesecretionoccurscontinuously incells,depending ontheir function                                               R...
“Cell eating”   “Cell drinking”                           http://commons.wikimedia.org/wiki/File:Endocytosis_types.svg
As mentioned, phospholipids can move freely past each other    laterally but very rarely do they move vertically or flip  ...
Further information:   Most of the excellent biology images in this slideshow are by graphic designer   Mariana Ruiz Villa...
