(Mobile) Device APIs          James Pearce         @jamespearce     http://tripleodeon.com
What are Device APIs? “Client-side APIs that enable the development of Web Applications that interact with device hardware...
Why are they important?• They’re not...    ...if you’re happy with a web of documents• They are...    ... if you want the ...
HistoryCurrent Work Use Cases
WTAI Make Call<a	  href="wtai://wp/mc;16505551234">	  	  Call	  us</a><a	  href="call.wmls#makeCall()">	  	  Call	  us</a>...
WTAI Call Control<a	  href="calls.wmls#setupCall()">Call	  us!</a><a	  href="calls.wmls#acceptCall()">Brring!</a><a	  href...
WTAI Messaging//	  sms.wmlsextern	  function	  sendMsg()	  {	  	  WTANetText.send("16505551234",	  "WML	  rocks");}extern	...
WTAI Contacts//	  contacts.wmlsextern	  function	  addFriend(i,	  num,	  name)	  {	  	  WTAPhoneBook.write(i,	  num,	  nam...
I may be laboring the point But that was 1998... ... and you still can’t do any of this with a contemporary mobile browser
BONDI“enables web based content to access nativedevice capability, intermediated through arobust, but flexible security fra...
Messagingvar	  sms	  =	  bondi.messaging.createSMS({	  	  to:	  ["16505551234"],	  	  body:	  "Home	  soon"});var	  mms	  ...
Messagingbondi.messaging.sendSMS(	  	  function	  ()	  {},	  //	  success	  	  function	  ()	  {},	  //	  error	  	  sms,	...
Messagingbondi.messaging.subscribeToSMS(	  	  function	  ()	  {},	  	  	  	  	  	  	  	  	  	  	  //	  success	  	  functi...
Contactsbondi.pim.contact.getAddressBooks(	  	  function(books)	  {	  //	  success	  	  	  	  var	  contact	  =	  books[0]...
Telephonybondi.telephonyLog.findLogEntries(	  	  function	  ()	  {},	  //	  success	  	  function	  ()	  {},	  //	  error,...
App Launcherbondi.applauncher.launchApplication(	  	  function	  ()	  {},	  //	  success	  	  function	  ()	  {},	  //	  e...
On one hand...• Security-conscious architecture• Comprehensive API support• Consistent API patterns• Conformance specificat...
On the other...
bondi.*deviceapis.*
WAC 2.0• Accelerometer        • File system• Calendar             • Geolocation• Camera               • Messaging• Contact...
Which is all awesome Except...
Device APIs Working Group “to create client-side APIs that enable the development of Web Applications and Web Widgets that...
W3C Device APIs• Media Capture(HTML)                        • Vibration• Media Capture(gUM)                        • Calen...
Media Capture (HTML)<input	  type="file"	  accept="image/*"	  /><!-­‐-­‐	  	  	  The	  accept	  attribute	  is	  a	  hint....
Brad Lassey, September 2008
Media Capture (HTML)<input	  type="file"	  accept="image/*"	  	  capture="camera"/><!-­‐-­‐	  	  	  Again,	  a	  hint.	  V...
Media Capture (HTML)<input	  type="file"	  accept="image/*"	  	  capture="camera"	  id="photo"/>var	  photo	  =	  document...
MediaFileDatainterface	  MediaFileData	  {	  	  	  	  attribute	  DOMString	  	  	  	  	  codecs;	  	  	  	  attribute	  u...
Media capture (gUM)navigator.getUserMedia(	  	  {	  	  	  	  audio:	  true,	  	  	  	  video:	  false	  	  },	  	  functio...
LocalMediaStreamvar	  recorder	  =	  stream.record();//	  recorder	  is	  a	  MediaStreamRecorderrecorder.getRecordedData(...
Messagingnavigator.sendMessage(	  	  "sms:16505551234?"	  +	  	  	  	  "body=JavaScript%20says%20hi",	  	  	  [],	  	  	  ...
Sensorsnavigator.findSensors().onsuccess	  =	  function()	  {	  	  this.result.forEach(function	  (sensor)	  {	  	  	  	  ...
Sensors• Temperature, ºC• AmbientLight, Lux• AmbientNoise, dbA• MagneticField, uTesla• Proximity, cm• AtmPressure, kP• Rel...
Contactsnavigator.contacts.find(	  	  [	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  //	  fields	  ...
Contactinterface	  Contact	  {	  	  	  	  readonly	  attribute	  DOMString	  	  	  	  	  	  	  	  	  	  	  	  	  	  	  id;...
Cool, but... “The ability to add and update contact information is not a function of the API provided in this specification.”
Holy Contacts Editing WTFvar	  vcard	  =	  	  	  BEGIN:VCARDrn	  +	  	  VERSION:3.0rn	  +	  	  UID:	  +	  contact.id	  +	 ...
WebAPI “We are aiming at providing all the necessary APIs to build a basic HTML5 phone experience within the next 3-6 mont...
WebAPI• Telephony   • Embedded browser• Messaging   • Battery• Contacts    • Device Status• Camera      • Settings• Networ...
Hopefully W3C++• “Our proposal might or might not look like  it for the moment”
Telephony!var	  tcall	  =	  	  navigator.telephony.dial("16505551234");tcall.readyState;	  	  //	  dialing,	  ringing,	  b...
Contacts “We need read/write”
USBvar	  usb	  =	  new	  MozUSBManager();usb.addEventListener("attachdevice",	  	  	  function	  ()	  {});usb.addEventList...
We deserve Device APIs...• As forward-looking as WTAI• As well-structured as BONDI• As comprehensive as WAC• As respectabl...
And we’ve got...
PhoneGap• Accelerometer   • Events• Camera          • File• Capture         • Geolocation• Compass         • Media• Connec...
Use Cases
Useless Demos                https://github.com/jamesgpearce/compios5
Fixing layout bugs, FMLwindow.addEventListener("deviceorientation",	  	  function	  (e)	  {	  	  	  	  orientation	  =	  M...
Camera• Profile pictures• Review sites• Photo sharing• Recognition • Bar-codes • Text • Faces
Filters!$(img).vintage({	  	  vignette:	  {	  	  	  	  black:	  0.8,	  	  	  	  white:	  0.2	  	  },	  	  noise:	  20,	  	...
Augmented reality?                     http://fhtr.org/JSARToolKit/
Contacts & calendaring• Add business details to address book• Web-based messaging• Facial recognition again...• Presence• ...
Messaging• Sharing• Notifications• Offline transport fallback• Frictionless web sign-on
Expect more
I still want... • Audio processing • Bluetooth • RFID & NFC • Both cameras • Memory & power • Native recognition
window.addEventListener(	  	  appointmentdue,	  	  function(appt)	  {	  	  	  	  if	  (device.near(WORK))	  {	  	  	  	  	...
James Pearce    @jamespearcehttp://tripleodeon.com
