High Availability Reloaded IVAN ZORATTI Chief Technology OfﬁcerOracle, MySQL and InnoDB are registered trademarks of Oracle and/or its afﬁliates. Other names may be trademarks of their respective owners. 1201.01.01Tuesday, 24 January 12

Agenda • SkySQL - 3 (+1) slides! • A bit of theory • High availability solutions • ...and the famous last words! 2Tuesday, 24 January 12

SkySQL Ab • Funded by: –MySQL® AB founders Monty Widenius and David Axmark –US Investment group OnCorps.org • A team of 40, operating in 14 countries, 90% from MySQL® AB • Backed by: –Product Engineering MontyProgram Ab –Top Community contributors, commercial partners and end users 3Tuesday, 24 January 12

SkySQL Offering • SkySQL Enterprise Subscriptions – Monitoring, Administration and End User tools – Specialised modules for High Availability and performance improvements1 • SkySQL Enterprise Cluster and SkySQL Enterprise HA – Up to L3 Technical and Consultative Support for the most used MySQL® distributions and branches • SkySQL Consulting – Top class team for MySQL® technology – Extended service offering from Health Check to continuous administration • SkySQL Training – MySQL® Training and Certification 1 - Option 4Tuesday, 24 January 12

The SkySQL Reference Architecture Components Integra&on Integra&on Tools Tools Migra&on Migra&on Tools Tools 5Tuesday, 24 January 12

High Availability ...a bit of theory 6Tuesday, 24 January 12

High Availability “High availability is a system design protocol and associated implementation that ensures a certain degree of operational continuity during a given measurement period.” 7Tuesday, 24 January 12

Fault-tolerant? “Fault-tolerant design enables a system to continue operation, possibly at a reduced level (also known as graceful degradation), rather than failing completely, when some part of the system fails.” 8Tuesday, 24 January 12

Switchover / Failover • Switchover – “Switchover is the capability to manually switch over from one system to a redundant or standby computer server, system, or network upon the failure or abnormal termination of the previously active server, system, or network.” • Failover – “Failover is the capability to switch over automatically to a redundant or standby computer server, system, or network upon the failure or abnormal termination of the previously active application, server, system, or network.” • Aided Switchover? • Failback? 9Tuesday, 24 January 12

Downtime • Planned/Scheduled • Unplanned/Unscheduled • “Downtime or outage duration refers to a period of time that a system fails to provide or perform its primary function.” 10Tuesday, 24 January 12

Single Point Of Failure - SPOF “A Single Point of Failure, (SPOF), is a part of a system which, if it fails, will stop the entire system from working.” 11Tuesday, 24 January 12

Disaster Recovery and Business Continuity “Disaster recovery is the “Disaster recovery process, policies and planning is a subset of a procedures related to larger process known preparing for recovery as business continuity or continuation of planning and should technology include planning for infrastructure critical to resumption of an organization after a applications, data, natural or human- hardware, induced disaster.” communications (such as networking) and other IT infrastructure.” 12Tuesday, 24 January 12

Disaster Recovery and Business Continuity “Disaster recovery is the process, policies and procedures related to preparing for recovery or continuation of technology infrastructure critical to an organization after a natural or human- induced disaster.” 13Tuesday, 24 January 12

Designing a Highly Available System • Which level of High Availability do I need? • Do I require no loss of data? • Do I need failover or is switchover enough? • Can I provide a reasonable service when a component is down? 14Tuesday, 24 January 12

Something to clarify... • Availability vs Scalability • HA Costs • HA for your systems, not only for your database • Review your SLAs 15Tuesday, 24 January 12

High Availability Solutions 16Tuesday, 24 January 12

High Availability with MySQL HigherAvailability • Combined solutions • Shared nothing distributed cluster with MySQL Cluster • Geographical Replication for disaster recovery • Virtualised Environments • Active/Passive Clusters through shared storage • MySQL synchronous replication • Generic synchronous replication • MySQL Replication with agents and failover • MySQL Replication 17Tuesday, 24 January 12

MySQL Replication • Something you may have missed... –Asynchronous or Semi-synchronous –Pros and Cons of RBR vs SBR –Mono-thread pull from the slaves –sync_binlog = 0/1 –Antilope vs Barracuda Read-Write –Group Commit Read-Only Read-Only –Multi-engines –Rolling upgrades binlog 99 18 relaylog relaylog relaylog relaylogTuesday, 24 January 12

MySQL Replication with MMM (Multi-Master replication Manager) • Master-Master features: –Monitoring –Automatic failover –Data backup –Resynch Read-Write mmm_agentd mmm_agentd • http://code.openark.org/blog/mysql/ problems-with-mmm-for-mysql Read-Only Read-Only • http://www.xaprb.com/blog/2011/05/ 04/whats-wrong-with-mmm/ binlog binlog mmm_mond relaylog relaylog relaylog relaylog http://mysql-mmm.org 19Tuesday, 24 January 12

MySQL Replication with MHA • Something to consider... –read-only=1 and log-bin on slaves –Master IP failover –Filtering rules –multi-tier replication http://code.google.com/p/mysql-master-ha/ 20Tuesday, 24 January 12

Tungsten Replicator • Open Source, heterogenous replication • Truly multi-master and fan-in with Global ID • Per-schema Read-Write multi-thread Replicator Replicator agent agent Replicator Replicator agent agent http://code.google.com/p/tungsten-replicator/ 21Tuesday, 24 January 12

Tungsten Enterprise Connector Connector Connector Connector Connector Read-Write • Tungsten Replicator + Replicator + Monitor Replicator + Monitor –Client Connector with R/W Replicator Replicator split and load balancing + Monitor + Monitor –Replication Monitoring –Integrated backup http://www.continuent.com/solutions/overview 22Tuesday, 24 January 12

Synchronous Replication with DRBD • Typical Active/Standby • Cross active/active servers implementations • Possible issues: –Dependencies –Infrastructure SPOFs –Write performance impact Active/Hot Passive/Std-by Server Server –InnoDB only • DRBD in a virtualized environment Block Block 23 Device DeviceTuesday, 24 January 12

Synchronous Replication through DRBD Conﬁguration Gateway 192.168.1.1 192.168.1.X Active/Hot VIP 192.168.1.2 Passive/Std-by Server Server HB1: 10.0.3.X HB2: 10.0.4.X 15 16 DRBD: 10.0.5.X /dev/sdb /mysqldata /dev/sdb /mysqldata Block Device Block Device 24Tuesday, 24 January 12

Synchronous Replication with Galera • Synchronous replication for InnoDB • Multi-master, no SPOF • Application Read-Write Read-Write failover must be managed • Conflict resolution wsrep wsrep wsrep http://www.codership.com 25Tuesday, 24 January 12

Percona XtraDB Cluster • Alpha version of Galera + XtraDB • Multi-master, no SPOF • Application failover must be Read-Write Read-Write managed • Conflict resolution with aborted COMMITs • Auto Increment • No XA TXN • NoPK operations issues wsrep wsrep wsrep http://www.percona.com/doc/percona-xtradb-cluster 26Tuesday, 24 January 12

SchoonerSQL • Synchronous master-slave replication for InnoDB • Retrieve/Inject in the transaction log and buffer pool • Monitoring/ Administration tool • Closed source 27Tuesday, 24 January 12

Active/Passive Clusters using Shared Storage • Points to consider: Active/Hot Passive/Std-by –Redundancy and replication Server Server must be guaranteed by the shared storage (and this is not trivial) –InnoDB only –File Systems Shared Storage 28Tuesday, 24 January 12

Active/Passive Clusters using Shared Storage Large Deployments VIP01 VIP02 VIP03 VIP04 VIP05 VIP06 VIP07 VIP08 in01 in02 in03 in04 in05 in06 in07 in08 01 02 03 04 05 06 07 08 Shared Storage 29Tuesday, 24 January 12

Active/Passive Clusters using Shared Storage Failover in Large Deployments VIP01 VIP05 VIP02 VIP03 VIP04 VIP06 VIP07 VIP08 in02 in03 in04 in06 in07 in08 in01 in05 01 02 03 04 05 06 07 08 Shared Storage 30Tuesday, 24 January 12

Virtualised Environments • Data storage, high availability and load balancing are provided and managed by the virtualised software • In case of fault, the virtualised software restarts on any other physical server • MySQL Replication for disaster 01 03 05 07 recovery • InnoDB only 02 04 06 08 01 02 03 04 05 06 07 08 31 Shared StorageTuesday, 24 January 12

Geographical Replication for Disaster Recovery • Master-Master Asynchronous Replication is used to update the backup data centre • In case of fault, the network traffic is redirected to the backup data centre. Failback must be executed manually • Cross-platform and cross- engine Active Backup Data Data Centre Centre 32Tuesday, 24 January 12

Storage Snapshots for Disaster Recovery • Snapshots are managed by the NAS and SAN firmware. There is usually a short read-only freeze Active Data • Snapshots can be used as run-time Centre backup • InnoDB only, NetApp NASs and firmware are certified using Snapshot and Snapmirror Backup Data Centre 33Tuesday, 24 January 12

MySQL Cluster • Shared-nothing, fully transactional and distributed architecture used for high volume and small transactions. • MySQL Cluster is based on the NDB (Network DataBase) Storage Engine • Data is distributed for scalability and performance, and it is replicated for redundancy on multiple data nodes. Application Nodes • Nodes in a cluster: – SQL Nodes: provide the SQL interface to NDB – API Nodes: provide the native NDB API – Data Nodes: store and retrieve data, manage NDB API, ClusterJ/JPA SQL Nodes transactions – Management Nodes: manage the Cluster • Load balanced • Memory or disk-based • Geographically replicated for disaster recovery with conflict resolution • Full online operation for maintenance and Management administration Nodes 34 Data NodesTuesday, 24 January 12

Client-based Failover and Proxies • Connector/J –jdbc:mysql://[host][,failoverhost...][:port] • mysqlnd_ms for PHP –connection pooling for mysqli, mysql and PDO_MYSQL • ScaleBase 35Tuesday, 24 January 12

The absolutely necessary comparison chart... Galera MySQL Shooner Shared Geo Storage MySQL MHA Tungsten DRBD XtraDB VM Replica.on SQL Cluster Replica.on Snapshots Cluster Cluster 100% Data ✘ ✘ ✔ ✔ ✘ ✔ ✔ ✔ ✘ ✘ ✔ Safe All Storage ✔ ✔ ✔ ✘ ✘ ✘ ✘ ✘ ✔ ✘ ✘ Engines Automa&c ✘! ✔ ✔ ✔ ✘! ✔ ✘! ✔ ✘ ✘ ✔ Failover Performance Overhead * * ** *** ** ** -‐ ** * ** * (* -‐ Best) Easy admin/ conﬁg * * * *** * * * * ** ** *** (* -‐ Best) Scalability (***-‐ Best) ** ** *** * ** ** * * * * ** 36Tuesday, 24 January 12

The famous last words... • I need 5 nines – • Everything must be automatic – • I want to migrate to MySQL Cluster – • I can’t afford to lose any data – • I need a sub-second failover – 37Tuesday, 24 January 12

The famous last words... • I need 5 nines –Implement what you really need • Everything must be automatic –Aided switchover is sometimes more effective, inexpensive and easy to implement/administer • I want to migrate to MySQL Cluster –Is your application designed for Cluster? • I can’t afford to lose any data –People lose data every day. Is the drop in performance worth it? • I need a sub-second failover –Check the timeout periods and the caching warm- ups 38Tuesday, 24 January 12

SkySQL Enterprise HA • Full HA solution, supported on –Platforms: Linux, Windsows Solaris X86 –DB Servers: Oracle MySQL, MariaDB, Percona Server –2 to 3 days implementation guaranteed with acceptance tests • Technologies: –MySQL Replication –DRBD Active/Passive or Cross Active –MHA Tool with/without Multi-tier Replication –Linux or Windows Shared Storage –MySQL Cluster –Tungsten Enterprise 39Tuesday, 24 January 12

Thank You! ivan@skysql.com izoratti.blogspot.com mysql4all.wordpress.com 40Tuesday, 24 January 12
