    Migration from ASP to ASP.NET Migration from ASP to ASP.NET Presentation Transcript

    • Migration from ASP to ASP.NET Anand M. Hegde Developer Support Engineer Microsoft Developer Support Microsoft Corporation
    • Overview
      • Why should you migrate?
      • Introduction to Microsoft® ASP.NET
      • Key changes from ASP to ASP.NET
      • Migrating from ASP to ASP.NET
      • Migrating applications that use COM components
      • Migrating applications that use databases
      • Migration best practices
      • ASP to ASP.NET compatibility FAQ
      • Resources for ASP.NET and migration
    • Why Should You Migrate?
      • Increased scalability and reliability
      • Minimum 2X to 3X performance gain
      • Built-in cross-browser compatibility
      • Rich server-side controls, Microsoft Visual Studio® .NET designer support, and configuration options
      • X-copy deployment of pages and components
      • Better debugger; tracing options
      • Content-code separation
      • Take advantage of new caching features
      • Enhanced state-management features
      • ASP and ASP.NET can run side-by-side if required
      • Many new features
    • Before You Migrate
      • Get a good understanding of ASP.NET
      • Know the changes from ASP to ASP.NET
      • Understand that migration requires code changes
      • Although ASP.NET has excellent backward compatibility, migration may not be as easy as it seems in many cases
    • Introduction to ASP.NET
      • ASP.NET is:
        • A new programming framework for Web applications
        • An overhaul of ASP
        • A part of Microsoft .NET
        • Compiled and event driven programming model
      • It permits you to:
        • Rapidly develop powerful Web applications and services
        • Easily build, deploy, and run Web applications that can target any browser or device
      • It requires:
        • Microsoft Windows® 2000 or later for hosting and development
    • ASP.NET Architecture
    • ASP.NET Request Flow ASPX engine Gen’d page class file Page class ASPX file Request Parse Generate Instantiate, process, and render Response Request Code behind class file Response Instantiate
    • ASP.NET Page Life Cycle
      • ASP.NET pages are event based
      • Event flow in ASPX pages
        • Page_Init: the page and controls are initialized
        • Page_Load: all the controls and page are loaded
        • Change events for controls are processed
        • Click events for controls are processed
        • Page_PreRender: page is about to render
        • Page_Unload: page is unloaded from memory
    • ASP Programming Models
      • Two types of programming models exist
        • ASPX page only: contains HTML, control tags, and code
        • Code behind model: ASPX file contains HTML and control tags, and a “code behind” file contains code
          • A true separation between code and content
      One File Two files. (“code behind” model) Page.aspx Page.aspx Page.aspx.vb <Tags> + Code <Tags> Code
    • ASP.NET Features
      • Life made easy for developers
        • Excellent backward compatibility with classic ASP
        • Visual Studio designer support, rich server controls, and base class library support
        • Write code in the language of your choice
        • Call Microsoft Win32® APIs directly
        • Structured error handling
        • Great debugging and tracing support
    • ASP.NET Features (2)
      • Performance, scalability, and reliability
        • Compiled code means speed
        • Cache APIs to improve performance and scalability
        • Built-in support for WebFarms and WebGardens
        • Nonstop availability and protection against deadlocks, memory leaks, and so on
    • ASP.NET Features (3)
      • Easy deployment
        • X-copy deployment
        • Dynamic updates without interrupting the service
        • No more registry! — u se XML-based configuration files
      • New application models
        • Develop mobile Internet applications with ease
        • Built-in support to use XML WebServices
      • More control with the new security model
      • Flexible session state management
      • Many other new features
    • Core Object Changes
      • Request object changes:
        • Request(item) , Request.QueryString(item) , and Request.Form(item) now return a name value collection
          • In classic ASP, they return an array of strings
      • Use Response.Write with caution
        • It will output results at the top of the page before the <HTML> tag
        • Instead:
          • Use server controls (placeholder)
          • Use <% %> tags if you want the output to appear in the right place
      • Each of the core objects now have many new properties and methods.
      • There are some new objects available
        • For example: cache, user and trace
    • Structural Changes
      • One page – one language
        • No mixing of languages in single page
      • A page can have only one server-side Form tag and it must submit to the same page
      • An ASPX page may contain:
        • Directives: <%@ Directive %>
        • Server controls: <tag runat=server>
        • Code blocks: <script runat=server>
        • Data binding expressions: <%# %>
        • Server-side comments: <%-- --%>
        • Server-side includes: <!-- #include -->
        • Render code: <%= %> and <% %>
    • Structural Changes (2)
      • Code block – related changes
        • You cannot declare functions inside <% %> tags
        • Declare all your functions and variables inside the server-side <SCRIPT> blocks
          • <Script runat=“server” language=“vb”>
          • dim gVar as String ‘Page level variable
          • private sub MySubRoutine()
          • Label1.Text = gVar
          • End Sub
          • </Script >
    • Structural Changes (3)
      • No Render functions permited
        • Change:
            • <% MyRenderFunction
            • Sub MyRenderFunction() %>
            • <h1> Hi there! </h1>
            • <%end sub%>
        • To:
          • <% Call MyRenderFunction()%>
          • <script runat=“server” language=“vb”>
          • Response.Write(“Hi there!”)
          • </script>
    • Structural Changes (4)
      • New page directives
        • In ASP, directives had to be at the top of the page, but you do not have to do this anymore
        • You can now have multiple directives on the same page
        • Sample page directive:
          • <%@ Page Language=&quot;VB&quot; ContentType=&quot;text/xml&quot; %>
        • See the documents on new page directives
    • Application Configuration Changes
      • ASP.NET application settings are stored in XML configuration files
      • Types of configuration files
        • Machine.config
          • Contains machine-wide settings
        • Web.Config
          • Contains project/application-wide settings
      • Easy programmatic access to the data in these files
      • Some of the settings in the IIS snap-in are ignored
        • For example: application protection level, session state
    • Session Management Changes
      • New session state storage mechanisms
        • InProc – session data stored on local computer (fastest)
        • StateServer – session data stored in a state service that can be located anywhere; ideal for WebFarms (faster)
        • SQLServer – session data stored in Microsoft SQL Server™ (fast)
        • Off – disable session state
      • Session state can be configured using <sessionState> section
      • Can store COM components in session only in InProc
      • Can store managed components in any session state modes
    • Security Related Changes
      • The IIS part of the security remains same
      • New robust and flexible security model is based on the security sections in the configuration files
      • New authentication modes
        • Windows: uses Windows Authentication
        • Forms: uses cookie-based custom logon forms
        • Passport: uses the Microsoft .NET Passport Service
        • None: no authentication
      • Authorization modes permit you to control access to resources:
        • File authorization
        • URL authorization
        • Permit and deny users access to the application
    • Migrating VBScript to Visual Basic .NET
      • No VBScript in ASP.NET — it’s all Microsoft Visual Basic® .NET!
      • Changing the file name extension to .aspx is the first step
      • Visual Basic language changes
        • Option Explicit is now the default
        • No more “variant” type — use type “Object”
        • Method and function calls with parameters now require parenthesis, so change:
        • <% Response.Write “Hi” %> to <% Response.Write (“Hi”) %>
        • By default, arguments are passed by value
        • Arrays are now zero based
    • Visual Basic Language Changes
      • Let and Set are not supported, so change:
        • Set MyObj1 = MyObj2 to MyObj1 = MyObj2
      • No more default properties (except for indexed properties), so change:
      • MyString as string = Textbox1 to MyString as string = Textbox.Text
      • Integer data type is now 32 bits and a Long data type is 64 bits
      • Use structured error handling (try catch block) instead of On Error (On Error still works)
      • Must cast data types explicitly:
      • Response.Write (“Count=“ & CStr(MyCount))
          • or Response.Write(“Count=“ & CType(MyCount, String))
    • Visual Basic Language Changes (2)
      • Must have spaces around “&” while doing string concatenation, so change:
        • x = str1&str2
        • to x = str1 & str2
      • Property Get, Property Set, and Property Let are not supported anymore, so instead use:
        • Public Property MyCount as Integer
        • Get
        • MyCount = InternalValue
        • End Get
        • Set
        • InternalValue = value
        • End Set
        • End Property
    • Migrating JScript to JScript .NET
      • Start by changing the file name extension to .aspx
      • Declare your variables explicitly
      • Microsoft JScript® .NET language changes
        • You can now pass variables by reference
        • “ expando” modifier available to extend user-defined objects
        • Can use COM components directly from JScript .NET
        • Server Object’s methods are case sensitive
        • The Arguments object is not available — use a parameter array instead
        • Functions cannot be redefined
        • For Large pages, move function/method code out of <% %> blocks to <Script runat=“server”> blocks
    • Migrating Applications that Use COM Components
      • COM related changes:
        • ASP.NET uses MTA instead of STA
        • Pages with STA components may or may not perform well
        • Early binding is preferred in ASP.NET
        • Cannot use ASPCOMPAT with WebServices
      • COM Interop
        • Can use all your former COM components in ASP.NET
        • Use ASPCOMPAT keyword if you plan to use existing STA components in ASP.NET
        • Use ASPCOMPAT only when using STA objects or when your COM objects access ASP intrinsic objects
    • COM Objects Migration — FAQ
      • What if the page contains both MTA and STA?
        • Use ASPCOMPAT
      • What if I have a middle tier containing COM objects?
        • Use horizontal or vertical migration strategies
      • What about the performance if I use existing COM objects?
        • Very little overhead if the method does substantial tasks
        • Significant overhead if the method does not do much
    • COM Objects Migration — FAQ (2)
      • What about deploying COM objects used in ASPX pages?
        • If you want to use Server.CreateObject, then there is no change
        • If you use early binding then use the PIA (Primary Interop Assembly) for the COM component and make sure you deploy the PIA on the target server
      • How can I use STA components from XML WebServices?
        • Register the component in COM+ and make sure you are running Windows 2000 SP2
    • Migrating Applications that Use Databases
      • Data access changes
        • ADO (through Interop) can be used, but Microsoft does not recommend it
        • ADO and ADO.NET are quite different
        • ADO.NET is not exactly backward compatible
        • Three main objects in ADO.NET: DataSet, DataReader, and DataAdapter
        • Two built-in managed data providers: SQLClient and OLEDB
        • Built-in designer support for ADO.NET objects in Visual Studio .NET
    • Migrating Applications that Use Databases (2)
      • Strategies
        • Rewrite ADO code in ADO.NET instead of migrating
        • Keep ADO code as a short term approach
        • If you use ADO code in ASP pages, use Primary Interop Assembly for ADO on both the developer box and the server
        • If you need read-only data, use a DataReader
    • Data Access Migration — FAQ
      • What if my application has straight ADO code in ASP pages?
        • Use ASPCOMPAT to use the code as it is (may be slower)
        • Rewrite the data access code to use ADO.NET
      • What if my application has COM objects that use data access?
        • Use the ASPCOMPAT attribute (if component uses STA)
      • What if my database has no managed providers?
        • You can use OLEDB providers in ADO.NET
        • If there are no OLEDB providers, use ODBC managed provider
    • Data Access migration — FAQ (2)
      • What if I have a data access tier?
        • Make these objects call Web Services or managed components
        • Later on, modify the presentation layer to use only .NET middle tier
      • Do I have to package ADO Components during deployment?
        • Make sure your server has MDAC 2.6 installed
        • Make sure you also deploy the PIA for ADODB on the server
    • General Migration Strategy
      • Identify the parts of the application that you have to migrate
      • Plan very carefully and try to have minimal impact on the existing application during the migration
      • In a multi-tier scenario, take the horizontal or vertical approach
        • Horizontal – migrate the whole tier (middle/presentation) at the same time
        • Vertical – migrate some pages, some components, at the same time
      • Decide if you want to reuse existing COM components
    • General Migration Strategy (2)
      • Decide if you want to keep current ADO code for a while
      • Rename the file name extension from .asp to .aspx
      • Make the language-specific changes first
      • Make COM- and database-specific changes
      • Test, test, test
    • Migration Best Practices
      • General
        • If the application is relatively small, consider rewriting
        • If the application is very large, then plan carefully and migrate part by part
        • If you only want to make a syntactic port, then consider only ASPX pages (that is, not using the “code behind” model) and do not make unnecessary changes
        • You do not have to port the whole site at the same time
          • Consider migrating the slow/critical parts
          • Remember, you can run ASP and ASP.NET side-by-side
        • Try to migrate the read-only pages first
        • Write automated tools to do some tasks
    • Migration Best Practices (2)
      • Language related
        • Strongly type all the variables
        • If possible, convert all the On Error statements to try catch blocks
          • Remember that they may not be as easy as they look
        • Convert Include files into assemblies or user controls (.ascx)
        • Use call keyword for function calls and use parenthesis for function and subroutine calls
        • Identify default properties and replace them appropriately
        • Always use Option Explicit
    • Migration Best Practices (3)
      • Data access related
        • If you have a data access tier, move it into .NET
      • COM related
        • Always use early binding
        • Explicitly free resources from code
      • Project management related
        • Keep two code trees while migrating, and make sure to update both of them while adding changes to the existing Web site
        • First try to modify the existing code as it is
          • After you complete this, try to modify the application to use the advantages provided by .NET
    • Migration Best Practices (4)
      • Testing related
        • Update existing links to your Web site/pages because the file name extension is now .aspx
        • Use a link checker to check any broken links, images, paths, and so on
        • Test very well
    • ASP to ASP.NET Compatibility — FAQ
      • How can ASP and ASP.NET co-exist?
        • Because they have different file name extensions (.asp and .aspx)
        • Because they have different application settings (registry and config files)
      • Can they share session and application data?
        • No – w rite custom code or use third-party component
      • What about Global.asa in ASP.NET?
        • In ASP.NET, it is called as Global.asax
    • ASP to ASP.NET Compatibility — FAQ (2)
      • Can I use .NET components from ASP, and COM components from ASP.NET?
        • Yes – use CCW to call managed components from ASP
        • Yes – u se RCW to call COM components from ASP.NET
      • What about the anonymous account in ASP.NET?
        • Remains the same
      • What about the hosting process in ASP.NET?
        • ASP.NET applications run under ASPNET_WP.EXE
        • By default, ASP.NET worker process runs under an account called ASPNET
    • ASP to ASP.NET Compatibility — FAQ (3)
      • Do I need to write code for different browsers?
        • No – ASP.NET produces HTML 3.2 compliant output
      • Can I still use ADO from ASP.NET?
        • Yes – y ou can use ADO through Interop, but ADO.NET is preferred
      • What about Include files?
        • Can be used, but better to convert them to class libraries or user controls (.ascx) instead
      • Can I call ASP pages from ASPX and vice versa?
        • Yes
    • ASP.NET Resources
      • ASP.NET Quick Start Tutorials
      • Authentication in ASP.NET Security
      • ASP.NET Security
      • Session State in ASP.NET
      • ASP.NET Configuration
      • http://www.gotdotnet.com
      • http://www.asp.net
      • http://www.ibuyspy.com
    • Migration Resources
      • Migrating to ASP.NET: Key Considerations
      • Migrating ASP Pages to ASP.NET
      • Converting ASP to ASP.NET
      • Upgrading to Microsoft .NET on GotDotNet
      • Upgrading to .NET on MSDN
      • Upgrading from JScript to JScript .NET
      • Microsoft .NET/COM Migration and Interoperability
      • Q314775 , “INFO: Migrating Visual InterDev Design-Time Controls to ASP.NET”
      • .NET Migration Case Study
      • Thank you for joining us for today’s Microsoft Support
      • WebCast.
      • For information about all upcoming Support WebCasts
      • and access to the archived content (streaming media
      • files, PowerPoint® slides, and transcripts), please visit:
      • http://support.microsoft.com/webcasts/
      • We sincerely appreciate your feedback. Please send any
      • comments or suggestions regarding the Support
      • WebCasts to [email_address] .
