AXIS2/C<br />Presented By:<br />Muktesh Mukul<br />
Flow of Discussion…<br />Introduction<br />Features<br />Architecture<br />Module Development<br />Usefulness<br />Conclus...
Introduction:<br />Apache Axis2/C is a Web services engine implemented in the C programming language.<br />Apache Axis2/C ...
Features:<br />Support for one-way messaging (In-Only) and request response messaging (In-Out).<br />Client APIs: Easy to ...
Transport proxy support.<br />REST support (more POX like) using both HTTP POST and GET .<br />WS-Policy implementation ca...
Architecture:<br />The Big Picture…<br />Each SOAP Node may be written in specific programming language, may it be Java, C...
Axis2 architecture lays out some principals to preserve the uniformity. They are as follows: <br />Axis2 architecture sepa...
Core Modules:<br />Information Model:<br />Axis2 defines a model to handle information and all states are kept in this mod...
XML Processing Model:<br />AXIOM(Axis Object Model) – <br />AXIOM is a lightweight, differed built XML infoset representat...
SOAP Processing Model:<br />The architecture identified two basic actions a SOAP processor should perform, sending and rec...
Axis2 Default Processing Model:<br />Axis2 has some inbuilt handlers that run in inbuilt phases and they create the defaul...
Processing an Incoming SOAP Message:<br />An incoming SOAP message is always received by a Transport Receiver waiting for ...
Let us see what happens at each phase of the execution. This process can happen in the server or in the client.<br />Trans...
Processing of the Outgoing Message:<br />The Out Pipe is simpler because the service and the operation to dispatch are kno...
Extending the SOAP Processing Model with Handlers:<br />The handlers in a module can specify the phase they need to be pla...
Extending the SOAP Processing Model with Modules<br />Axis2 defines an entity called a 'module' that can introduce handler...
Deployment Model:<br />The Deployment Model provides a concrete mechanism to configure Axis2. This model has three entitie...
Client API<br />There are three parameters that decide the nature of the Web service interaction.<br />Message Exchange Pa...
Message Exchange pattern(MEP)<br />The two supported MEPs are One-Way and the In-Out (Request-Response) scenarios in the C...
Transports<br />Axis2 has two basic constructs for transports, namely: Transport Senders and Transport Receivers.<br />Axi...
Code Generation:<br />
Data Binding:<br />
The following databinding extensions are available:<br />ADB - ADB (Axis Data Binding ) is a simple framework that allows ...
