PaaSing a JavaEE 6 Application                        Kshitiz Saxena                                         LOGO
The following is intended to outline our general product direction. Itis intended for information purposes only, and may n...
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
Cloud ComputingWhat’s new?• Illusion of infinite computing resources available on  demand• Elimination of an up-front comm...
Cloud ComputingEssential Characteristics•   On-demand Self-Service•   Broad network access•   Resource Pooling•   Rapid El...
Cloud ComputingDeployment Models• Private Cloud  – Operated solely for an organization  – On-premise or off-premise• Commu...
Cloud ComputingService Models• Software as a Service (SaaS)• Platform as a Service (PaaS)  –   Deploy customer-created app...
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
PaaS and Java EEJava EE design principles and capabilities•   Common programming model for enterprise developers•   Runtim...
PaaS and Java EEJava EE 7: “Making Java EE ready for the cloud”• Enhancements  – New Roles for PaaS  – Services as first c...
New PaaS Roles in Java EE 7•   PaaS Product Vendor•   PaaS Provider•   PaaS Account Manager•   PaaS Customer•   Applicatio...
Java EE 7 Roles in a PaaS scenario
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
PaaS Implications on Deployment• Simplified PaaS Application Deployment  – Single-click, self-service, “push to cloud”
PaaS Implications on DeploymentServices Management• Automatic Service Provisioning and Management – Service Orchestration ...
PaaS Implications on DeploymentVirtualized runtimes• Scalable virtualized on-demand environment  – Support multiple cloud ...
PaaS Implications on DeploymentScaling and Operations• Automatic Scaling of Services  – Scale to application’s needs  – Us...
A sample application stack
Traditional Java EE Application Deployment
Java EE PaaS Application Deployment
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
Terminology• Service• ServiceType  – Java EE, RDBMS, HTTP Load Balancer etc.• Services – scope and lifecycle  – Provisione...
Specification of Service Metadata• Optional!  – When not specified (vanilla EE app archives)    • Orchestration Engine aut...
Design Model
Specification of Service Metadata• Service Definition  – Metadata used to provision and configure a Service    • What : Se...
Service Dependency Specification
Sample Service Definition
Sample Service Reference
GlassFish PaaS Runtime Architecture
Service Orchestration Flow
DemoPaaSing a Java EE Application in the Cloud
Conference Planning in the Cloud                 <glassfish-services>                 <service-description init-type="LB" ...
PaaS Deployment for Demo
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
GlassFish PaaS Runtime Architecture
IMSOne-liner Provide common management interface across different virtualization technologies
IMS
IMS functionalities• Support virtualization definitions• Isolates from low level Virtual Machine allocation/interface  – I...
Templates• A virtual-machine disk  – can be duplicated  – used to instantiate a virtual-machine.• Virtualization Specific•...
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
GlassFish PaaS Runtime Architecture
Service OrchestrationOne-liner Enable single-click deployment of a PaaS application through automatic service dependency d...
Service Dependency Discovery
Service Provisioning
Service Association
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   IM...
GlassFish PaaS Runtime Architecture
Auto-ScalingOne-linerThe ability of a system to automatically adapt to volume of traffic without impacting throughput and ...
What we need• To determine the health of Services in the System  – Number of metrics can be used  – An arbitrary / complex...
Determining State of Services• Monitor System Resources – CPU   • Used and idle CPU times – Memory   • Process memory: All...
Determining State of Services (Contd.)  – Monitor Application Related Objects    • HTTP Sessions created / destroyed per s...
We have metrics. Now what?• Use relevant metrics to determine health of the services  – Such as Java EE Clustered Instance...
What Actions can you take?• Possible Actions  –   Send email to admin  –   Log some info  –   Scale up / Scale down to mee...
Program Agenda•   Cloud Computing•   PaaS and Java EE•   PaaS implications on application deployment•   Design Model•   Se...
ResourcesFor more information• GlassFish 4.0 http://download.java.net/glassfish/4.0/promoted/  – Spec http://bit.ly/sAZtEL...
Q&A
PaaSing a JavaEE 6 Application                             Kshitiz SaxenaConference Session - 25360                    LOGO
