  1. Behind The Scenes Dr. Thanisa Kruawaisayawan www.imcinstitute.com
  2. Behind The Scene: HelloWorld (Single View Application)• ViewController is the File’s Owner of ViewController.xib. File’s Owner represents the object that loaded the nib file from disk and owns this copy of the nib file. 2
  3. Behind The Scene: HelloWorld (Single View Application)• ViewController has a view linked to View 3
  4. Revisit: iOS Application Life Cycle Souce: http://developer.bada.com/article/A-Comparison-between-iOS-and-bada-Application-Development-Part1 4
  5. main() => UIApplicationMain() • principalClassName • Pass nil when you have no UIApplication subclasses • delegateClassName • Pass a custom class that implements UIApplicationDelegate protocol 5
  6. AppDelegate.h• This class implements UIApplicationDelegate Protocol.• AppDelegate is the delegate of UIApplication object.• AppDelegate has two properties (named “window”, and “viewController”) which are instance of UIWindow and ViewController 6
  7. AppDelegate.m• UIWindow has a property named “rootViewController”, which is now pointed to viewController object. 7
  8. Behind The Scene 8
  9. Behind The Scene window(in AppDelegate) viewController view = 9
  10. Behind The Scene: HelloWorld_Storyboard• ViewController is the File’s Owner of MainStoryboard.storyboard. 10
  11. Behind The Scene: HelloWorld_Storyboard• ViewController has a view linked to View 11
  12. AppDelegate.h• AppDelegate has two properties (named “window”) which are instance of UIWindow. 12
  13. AppDelegate.m 13
  14. HelloWorld_Storyboard-Info.plist 14
  15. Behind The Scene window(in AppDelegate) viewController view = 15
  16. Model-View-Controller (MVC) Design Pattern 16
  17. Model-View-Controller (MVC) Design Pattern• Model (any data in your program) Are separated in such a manner that modifying either the view or• View (what the user sees) model component of your program has no effect on one• Controller (a layer that handles another.  all interaction between the view and model) 17
  18. What Files Are In The Project?• Source Files • AppDelegate.h & AppDelegate.m Controller • ViewController.h & ViewController.m View • ViewController.xib / MainStoryboard.storyboard• Supporting Files • HelloWorld-Info.plist • main.m 18
  19. New an Empty Application 19
  20. HelloWorldEmptyWindow 20
  21. AppDelegate.h• AppDelegate has two properties (named “window”) which are instance of UIWindow. 21
  22. AppDelegate.m• Window becomes the Key window and is Visible to the screen 22
  23. Run and See Result• This is a window with white background. 23
  24. AppDelegate.m• Add a label into the window 24
  25. Run and See Result 25
  26. New File > Window > MainWindow.xib 26
  27. MainWindow.xib• Set File’s Owner of MainWindow.xib to Class: UIApplication 27
  28. MainWindow.xib• Drag and drop Object 28
  29. MainWindow.xib• Set Object to Class: AppDelegate 29
  30. MainWindow.xib• Right click at File’s Owner• Link delegate to App Delegate 30
  31. AppDelegate.h• Add IBOutlet in front of UIWindow 31
  32. AppDelegate.m• Comment codes 32
  33. MainWindow.xib• Right click at App Delegate• Link window to Window 33
  34. MainWindow.xib• Drag and drop Label and change text into Hello World 34
  35. HelloWorldEmptyWindow-Info.plist• Add Row > Key: Main nib file base name and Value: MainWindow 35
  36. Launch the Application 36
  37. Run and See Result 37
  38. Conclusion for HelloWorldEmptyWindow• Create a new xib file • Goto AppDelegate.h and put New File -> Window -> IBOutlet in front of UIWindow MainWindow.xib *window;• Click at Files Owner of • Goto Window.xib again and MainWindow.xib -> change this connect window under Outlets to class to UIApplication Window• Drag and drop an Object under Objects -> select the third tab on • Also in plist file add a row the right -> change this class to Key: Main nib file base name AppDelegate Type: String• Right click at File’s Owner and Value: MainWindow connect delegate to App Delegate 38
  39. MainWindow.xib• Drag and drop Round Rect Button and change text into Say Hello Where to write action code? 39
  40. New an Empty Application 40
  41. HelloWorldEmptyViewController 41
  42. New File > Objective-C class• Apple calls the library to develop UI in iPhone as Cocoa Touch and in Mac as Cocoa. 42
  43. ViewController• Enter Class: ViewController, choose Subclass of UIViewController, and select With XIB for user interface 43
  44. ViewController.xib• File’s Owner of ViewController.xib is Class: ViewController 44
  45. ViewController.xib• Drag and drop label (delete text) 45
  46. ViewController.xib• Drag and drop Round Rect Button (change text to “Say Hello”) 46
  47. ViewController.xib to ViewController.h• Control + Drag from the label in ViewController.xib to ViewController.h 47
  48. ViewController.xib to ViewController.h• Control + Drag from the button in ViewController.xib to ViewController.h 48
  49. ViewController.m• Add code in sayHello method 49
  50. AppDelegate.h• Add codes 50
  51. AppDelegate.m• Add codes 51
  52. Run and See Result 52
  53. Revisit: New File > Objective-C class > ViewController• Enter Class: ViewController, choose Subclass of UIViewController, and forget to select With XIB for user interface 53
  54. New File > View > ViewController1.xib 54
  55. ViewController1.xib• Change File’s Owner of ViewController1.xib to Class: ViewController and Link view of ViewController to View 55
  56. ViewController1.xib• Drag and drop Label and change text to ViewController1 56
  57. AppDelegate.m• Change from ViewController to ViewController1 for initWithNibName 57
  58. Run and See Result 58
  59. References• Boonyanit Mathayomchan, Ph.D., “iPhone Application Development (BASIC)”, 2011• Chotipat Pornavalai, iPhone Basic #1, Mini Master of iOS Application #1• Dave Mark, et.al, “Beginning iOS5 Development: Exploring the iOS SDK”, 2012• Joe Conway & Aaron Hillegass, “iPhone Programming: The Big Nerd Ranch Guide”, 2010 59

×
