Polymeric Biomaterials Presented by: Ikhwan Hidayat ( 이흐완 히다얏  )
Contents <ul><li>Introduction </li></ul><ul><ul><li>Natural Polymers </li></ul></ul><ul><ul><ul><li>Collagen, Chitosan, Al...
Natural Polymers <ul><li>Polymers derived from living creatures </li></ul><ul><li>“ Scaffolds” grow cells to replace damag...
Collagen <ul><li>Consist of three intertwined protein chains, helical structure </li></ul><ul><li>Collagen can be desorbed...
Chitosan <ul><li>Derived from chitin, present in hard exoskeletons of shellfish like shrimp and crab </li></ul><ul><li>Chi...
Alginate <ul><li>A polysaccharide derived from brown seaweed </li></ul><ul><li>Can be processed easily in water, non-toxic...
Synthetic Polymers <ul><li>Advantages of Synthetic Polymers </li></ul><ul><ul><li>Ease of manufacturability, process abili...
Polymerization <ul><li>Process of reacting monomer molecules together in a chemical reaction to form three-dimensional net...
Synthetic Polymers Used as Biomaterials <ul><li>Polyvinylchloride (PVC) </li></ul><ul><ul><li>Amorphous & rigid polymer, h...
<ul><li>Polypropylene (PP) </li></ul><ul><ul><li>High tensile strength </li></ul></ul><ul><ul><li>Excellent stress-crackin...
Biodegradable Polymers <ul><li>Advantages on biodegradable polymer </li></ul><ul><ul><li>Didn’t leave traces of residual i...
Surface Modification
Surface modification of polystyrene with atomic oxygen radical anions-dissolved solution <ul><li>The O −  water, generated...
<ul><li>Particularly, it was found that some hydrophilic groups were introduced onto the polystyrene surfaces via the O − ...
감사합니다 <ul><li>Thank you for your attention…. </li></ul><ul><li>- Questions & Discussion - </li></ul>[back to index of cont...
