Ruby Proxies for Scale, Performance and Monitoring Ilya Grigorik CTO / AideRSS Event-Driven Architectures  @igrigorik #mes...
postrank.com/topic/ruby The slides… Twitter My blog
<ul><li>Proxy Love </li></ul>
<ul><li>Myth: Slow Frameworks </li></ul>“ Rails, Django, Seaside, Scala…” cant scale.
<ul><li>The Proxy Solution </li></ul>
<ul><li>The “More” Proxy Solution </li></ul>
<ul><li>Transparent, Cut-Through Proxy </li></ul>Transparent
<ul><li>Transparent Proxy = Scalability Power Tool </li></ul>90% use case
Proxies for Monitoring, Performance and Scale welcome to   the wonderful world of intercepting, caching, … , proxy servers
Problem: Staging Environment Production Simulated User
“ Representative Load / Staging” Duplication Simulating traffic?
Staging fail. Profile of queries has changed Fail Load on production has changed Fail Parallel environment Fail Slower rel...
Replay  log data,  rinse, repeat github.com/igrigorik/autoperf
<ul><li>Benchmarking Proxy </li></ul><ul><li>flash of the obvious </li></ul>Real (production) traffic Duplex Ruby Proxy, F...
Transparent Duplex Proxy, FTW
Same response, different turnaround time Different response body!
<ul><li>github.com/igrigorik/em-proxy </li></ul>Duplex Ruby Proxy, FTW!
<ul><li>EM-Proxy Workflow </li></ul>1. Accept connection - Connect & Forward to Production - Connect & Forward to Staging ...
Ruby EventMachine crash course EM::Connection #receive_data   - new data ready for processing #unbind -  connection termin...
Duplex incoming data
Forward Production Response Analyze Results
Open connection to application server
Buffer until connected
Pass response to Duplex Notify when done
Analyze Time, Response…
Analyze Time, Response… Response Time
Cute, right? but so what…
%w[  <Transparent>  Intercepting  Caching … ]  solution for every problem
Validating Proxy easy, real-time diagnostics Woops!
Who said you’re not allowed to touch the data? Intercepting Proxy for those hard-to-reach spots
SMTP / Mail:  inject SPAM detection De(encrypt):  stream data MySQL:  inject sharding logic Intercepting Proxy for those h...
@PostRank:  Beanstalkd + Ruby Proxy  because RAM is still expensive
<ul><li>Beanstalkd  Math </li></ul>~ 93  Bytes of overhead per job ~300  Bytes of data / job x 80,000,000  jobs in memory ...
<ul><li>Extending Beanstalkd </li></ul>Observations:  1.  Each job is rescheduled several times 2.  > 95%  are scheduled f...
@PostRank: “Chronos Scheduler” 1 “Medium” EC2 Instance Intercepting Proxy
Extend the protocol Chronos Scheduler Beanstalkd persistence Process incoming data Buffer “SCHEDULE” requests, otherwise f...
Archive to MySQL Chronos Scheduler Beanstalkd persistence Buffer “SCHEDULE”
@PostRank: “Chronos Scheduler” Extend the protocol ARCHIVE RESERVE, … 10 line patch to client: queue.archive(job)
@PostRank: “Chronos Scheduler” ~79,000,000 jobs, 4GB RAM ARCHIVE RESERVE, … Upcoming jobs: ~ 1M 400% cheaper + extensible!...
%w[ Transparent  <Intercepting>   Auth  Cache … ]  easy to make & a powerful hammer
Cheers. Questions? The slides… Twitter My blog
