OpenSolaris 2009.06 Workshop OpenSolaris 2009.06 Workshop Presentation Transcript

  • OpenSolaris 2009.06 A Workshop for some key Technologies Markus Weber Sun Microsystems, Inc. Iban Nieto OpenSolaris Community
  • Agenda
    • Install OpenSolaris 2009.06
    • Sun VirtualBox
    • IPS, Package Manager, and Repositories
    • ZFS & Time Slider
    • DTrace
    • If time permits: Crossbow & Containers
  • Install OpenSolaris 2009.06
    • Options:
      • Upgrade from a previous version
      • Natively on your laptop
      • In a partition on your laptop
      • In VirtualBox
  • Install OpenSolaris 2009.06
    • Basic System Requirements:
      • At least 512MB memory, more is better
      • Recommended at least 9GB disk space
  • Upgrade to OpenSolaris 2009.06
    • Package Manager
      • “Update All”
      • Follow instructions
    • Command Line:
      • pfexec su
      • pkg image-update [-nv]
      • Follow instructions
  • Install OpenSolaris 2009.06 Natively
    • Boot from
      • OpenSolaris LiveCD
      • OpenSolaris LiveUSB
    • Use “Device Driver Utility”
      • To check support for your devices
    • If ok, install
      • Go through easy installation wizard
      • Reboot
      • Done !
  • Install OpenSolaris 2009.06 in Partition
    • Notes if running Windows:
    • If you have Windows installed, and you set up sufficient space for installing the OpenSolaris 2009.06 operating system, the installation should be straightforward. All versions of the OpenSolaris software for the x86 platform use the GNU Grand Unified Bootloader (GRUB). The OpenSolaris software recognizes Windows and ensures that the Windows partitions remain unchanged during an installation. When the OpenSolaris installation completes, and the system reboots, the GRUB menu displays both the Windows and the OpenSolaris boot entries.
  • Install OpenSolaris 2009.06 in Partition
    • Notes if running Linux:
    • If you have either the Linux or Windows operating systems installed on your system, before installing the OpenSolaris operating system, save a copy of the menu.lst file. You will need to manually update the menu.lst file to add the Linux information after the OpenSolaris installation completes. For instructions on that, please check: http://dlc.sun.com/osol/docs/content/2009.06/getstart/linuxgrub.html#linuxgrubtask
  • Install OpenSolaris 2009.06 in Partition
    • Notes if running Solaris 10:
    • The installer cannot be used to multiboot the OpenSolaris operating system. However, the installer can be used to replace the Solaris 10 1/06 and later releases in an existing multiboot Solaris system.
    • Notes on Extended Partitions: If you have another operating system installed on an extended partition, the existing extended partition is neither changed nor lost during an OpenSolaris installation. Existing extended partitions are not visible during the installation, but the primary fdisk partition in which the extended partition resides is visible. No data in these partitions is lost as a result of the installation. The operating system on an extended partition is not displayed in the GRUB menu.
  • Install OpenSolaris 2009.06 in Partition
    • For more information on how to install OpenSolaris 2009.06 in a multiboot environment, please check:
    • http://dlc.sun.com/osol/docs/content/2009.06/getstart/partition.html
  • Install OpenSolaris 2009.06 in VirtualBox
    • http://www.virtualbox.org
      • Download and install binaries according to your OS
        • For any Windows, Linux, Solaris/OpenSolaris, Mac OS X (Intel)
    • http://www.opensolaris/get
      • Download OpenSolaris .iso file
      • Or use LiveCD
  • Install OpenSolaris 2009.06 in VirtualBox
    • In VirtualBox: “New”
      • Choose OS, a name, memory size, (virtual) disk image, Finish
      • Change graphic memory, attached .iso or LiveCD.
      • “Start”
      • Install OpenSolaris
      • Install Guest Additions !!
        • “Devices” -> “Install Guest Additions...”
        • As root, cd /media, pkgadd -d .pkg
  • Sun VirtualBox Host Platforms Guest Platforms x86 Hardware
  • Sun VirtualBox
    • Broad platform support
      • Hosts: Windows, Solaris, Linux, OS X
      • Guests: Support for practically any x86-based OS
    • Powerful virtual hardware and device support
    • Versatile Networking options
    • Rich host/guest integration
    • Virtual SATA or IDE: u p to 32 disks
    • Virtual NICs: g igabit ethernet E1000
    • Virtual USB Controller: USB 1.1 and 2.0 (with USB device filter)
    • Full ACPI Support: g uests reflect power status of host
    • Virtual CD/DVD: p assthru for CD/DVD writing
    • Processor: 32-bit and 64-bit guests; PAE support
    • Graphics Acceleration: OpenGL for Windows Guests
  • Sun VirtualBox: a useful example
  • Sun VirtualBox: the main window Check out all the Configuration options. And play around with it !!
  • What is IPS ? Image Packaging System
    • Repositories
    • Easy to package for the developer
    • Determine, control and resolve dependencies
    • Rapid delivery of fixes
    • Upgrade and rollback with ZFS snapshots
  • What are Repositories ? Community Sun Release Develop Contribute Pending Extra Support
  • Command Line Interface to IPS
    • beadm (boot environment administration)
      • beadm get a list of option (some require pfexec / root)
      • man beadm for man pages
      • beadm list list current boot environments
    • pkg (image packaging retrieval client)
      • pkg get a list of options (some require pfexec / root)
      • man pkg for man pages
      • pkg publisher check current publishing authorities
      • pkg history some history information
      • pkg info [ |more ] check all packages installed (long output !)
  • Command Line Interface to IPS
    • Curious or adventerous ? Let's add the /dev repository:
      • pkg publisher
      • pfexec pkg set-publisher -O http://pkg.opensolaris.org/dev dev.opensolaris.org
      • pkg publisher
      • pkg unset-publisher dev.opensolaris.org (if you want)
    • Want VirtualBox and flash ? Let's add the /extra repository:
      • Go to http://pkg.sun.com and register
      • Download SSL key & certificate
      • pfexec pkg set-publisher -k <path-to-key> -c <path-to-cert> -O https://pkg.sun.com/opensolaris/extra/ extra.opensolaris.org
  • Command Line Interface to IPS
    • Flash
      • pkg info -r flash
      • pfexec pkg install flash
    • VirtualBox
      • pkg info -r virtualbox
      • pfexec pkg install virtualbox
    • OpenOffice
      • pkg info -r openoffice
      • pfexec pkg install openoffice
  • Enhanced Package Manager
  • Package Manager
    • Discover 'Repository' drop-down menu on the top right
    • Discover categories drop-down menu on the top left
    • Discover sub-categories on the left panel
    • Click on a package, and check out 'Files', 'Dependencies', and 'Licence on the bottom
    • Play with the 'Search' function
    • Click on 'File' -> 'Manage Boot Environments...'
    • Click on 'File' -> 'Manage Repositories...'
  • Package Manager: Manage Repositories
    • Click on 'File' -> 'Manage Repositories...'
    • Let's add the sunfreeware.com repository:
  • Package Manager: Manage Repositories
    • Browse or search through the packages
    • Click on a package, and select 'Install/Update'
  • ZFS & Time Slider
  • Time Slider
    • Let's configure it
    • Let's use it
    • Use it everyday, even for your own version control !
  • Time Slider
    • 'System' -> 'Administration' -> 'Time Slider':
    • Enable it
    • Choose 'All' or 'Custom'
    • Also note the 'Delete Snapshots...' button
  • Time Slider
    • Open the File Browser (the house/home button)
    • Navigate to any directory that is snapshot'ed
    • Click on 'Restore'
    • Notice the 'Time Slider'
    • Slide the 'Time Slider' (note: if you setup Time Slider only a few minutes ago, of course the will not be any snapshots yet)
    • However, New: create a snapshot of this directory manually by clicking on the camera icon !
  • Time Slider
  • Time Slider
    • Once you have snapshots, delete a file
    • Then, 'travel back' in time on the slider.
    • Select the deleted file, right-click, select 'Restore to Desktop'
    • Backup / Restore as easy as that !!!
    • Open a new tab, compare directories
    • To close Time Slider, click on the white cross in red circle button on the top left.
  • ZFS
    • ZFS is VERY cool !
      • The underlying technology that makes Time Slider possible
    • End-to-End data integrity
        • 256bit checksums
        • Copy-on-write transactions
    • Immense data capacity
        • 128bit filesystem
    • Easy to use
        • Pooled storage model – no more volume mgr
  • ZFS
    • To create one or more pools (zpool), let's simulate physical hard drives:
      • Files can be used for that:
        • mkfile 100m <path>/disk1
        • mkfile 100m <path>/disk2
        • etc.
      • Or, virtual SATA disks in VirtualBox:
        • On the powered-off OpenSolaris guest, open 'Hard Disks', then 'Enable Additional Controller', then create some virtual disks
  • ZFS
    • zpool to see options
    • man zpool for man pages
    • zfs to see options
    • man zfs for man pages
  • ZFS Reference, Commands and Examples
    • Create a ZFS storage pool # zpool create mpool mirror c1t0d0 c2t0d0
    • Add capacity to a ZFS storage pool # zpool add mpool mirror c5t0d0 c6t0d0
    • Add hot spares to a ZFS storage pool # zpool add mypool spare c6t0d0 c7t0d0
    • Replace a device in a storage pool # zpool replace mpool c6t0d0 [c7t0d0]
    • Display storage pool capacity # zpool list
    • Display storage pool status # zpool status
    • Scrub a pool # zpool scrub mpool
    • Remove a pool # zpool destroy mpool
    • Create a ZFS file system # zfs create mpool/devel
    • Create a child ZFS file system # zfs create mpool/devel/data
    • Remove a file system # zfs destroy mpool/devel
    • Take a snapshot of a file system # zfs snapshot mpool/devel/data@today
    • Roll back to a file system snapshot # zfs rollback -r mpool/devel/data@today
    • Create a writable clone from a snapshot # zfs clone mpool/devel/data@today mpool/clones/devdata
  • ZFS Reference, Commands and Examples
    • Remove a snapshot # zfs destroy mpool/devel/data@today
    • Enable compression on a file system # zfs set compression=on mpool/clones/devdata
    • Disable compression on a file system # zfs inherit compression mpool/clones/devdata
    • Set a quota on a file system # zfs set quota=60G mpool/devel/data
    • Set a reservation on a new file system # zfs create -o reserv=20G mpool/devel/admin
    • Share a file system over NFS # zfs set sharenfs=on mpool/devel/data
    • Create a ZFS volume # zfs create -V 2GB mpool/vol
    • Remove a ZFS volume # zfs destroy mpool/vol
  • ZFS Basics
    • Note: if you don't want to type pfexec all the time, just do ' pfexec su - '
    • Create a mirrored zpool
      • zpool create mypool mirror <path>/file1 <path>/file2 or
      • zpool create mypool mirror c1t0d0s2 c1t1d0s2 (example for VirtualBox, check with 'format')
      • zpool list
      • zpool status mysool
    • Add more disks to the pool (easy !)
      • zpool add mypool mirror file3 file 4 (or different for VirtualBox)
      • zpool list
      • zpool status mysool
  • ZFS Basics
    • Create a mirrored zpool
      • zpool create mypool mirror file1 file2 or
      • zpool create mypool mirror c1t0d0s2 c1t1d0s2 (example for VirtualBox, check with 'format')
      • zpool list
      • zpool status mysool
    • Add more disks to the pool (easy !)
      • zpool add mypool mirror file3 file 4 (or different for VirtualBox)
      • zpool list
      • zpool status mysool
    • Create a zfs filesystem
      • zfs list
      • zfs create mypool/myfs or
      • zfs create -o mountpoint=/export/myfs mypool/myfs
      • zfs list
    • Note: no format, no newfs, no /etc/vfstab, no mount !!
  • ZFS Basics
    • Let's do some snapshotting !
      • cd /mypool/myfs or /export/myfs
      • ls -l
      • echo “Before Snapshot” > file1.txt
      • zfs snapshot mypool/myfs@today
      • zfs list -t all | grep mypool (note, at that moment you might actually see also some snapshots created by time slider !)
      • rm file1.txt
      • echo “After Snapshot” > file1.txt
      • cat file1.txt
      • zfs rollback mypool/myfs@today
      • ls -l
      • cat file1.txt
  • ZFS Basics
    • Backup and Restore complete filesystems or pools
      • zfs send mypool/myfs@today > /tmp/zfsdata
      • zfs destroy -r mypool/myfs Note: the -r option recursively destroys all children, including snapshots.
      • ls -l /mypool/myfs (gone !)
      • zfs receive -d mypool < /tmp/zfsdata
      • ls -l /mypool/myfs (back !)
    • Note: you can also backup to different system(s) by using something like:
      • zfs send <snapshot> | ssh <host2> zfs receive <snapshot>
  • ZFS Basics
    • RAID-Z
      • RAID-Z (Redundant Array of Inexpensive Disks) is similar to RAID-5 but it's a bit better because it checksums on multiple disks, so data security is higher and performance is also better thanks to organizing data in a way that the disks are well harnessed (less going there and back to get data).
      • zpool destroy mypool
      • zpool create mypool raidz file1 file2 file3
      • zpool list
      • zpool status mypool
  • ZFS Basics
    • Other useful commands:
      • zfs create mypool/home
      • zfs create mypool/home/jorge
      • zfs create mypool/home/antonio
      • zfs create mypool/home/maria
      • Zfs list
      • zfs set quota=20m mypool/home/jorge
      • zfs set reservation=10m mypool/home/maria
      • zfs get quota mypool/home/jorge
      • zfs get quota mypool/home/maria
      • zfs get reservation mypool/home/jorge
      • zfs get reservation mypool/home/maria
  • ZFS Basics
    • Other useful commands (cont.):
      • cd /mypool/home/jorge/
      • mkfile 30m test
      • test: initialized 20840448 of 31457280 bytes: Disc quota exceeded
      • To see all properties:
        • zfs get mypool/home/jorge
  • ZFS Basics
    • Want to use OpenSolaris as a storage server ?
      • zfs create mypool/nfsshare
      • zfs set sharenfs=on mypool/nfsshare
      • zfs get sharenfs mypool/nfsshare
    • Happy Sharing !!
  • ZFS Basics
    • Want to use OpenSolaris as a storage server ?
      • pkg install SUNWsmbs (might be necessary to reboot)
      • svcadm enable -r smb/server
      • zfs create -o casesensitivity=mixed mypool/cifsshare
      • zfs set sharesmb=on mypool/cifsshare
      • zfs get sharesmb mypool/cifsshare
      • sharemgr show -vp
    • Happy Sharing !!
      • Note: if working with, and connecting from certain Windows workgroups, there are a few more steps. Check out the How to Guide !
  • DTrace
    • Tool to observe and understand dynamic behavior of entire software system
    • Fundamentally different from previous tools
      • Software does not have to be instrumented or explicitly built for monitoring
      • Safe for use on live production systems
      • No overhead until probes are enabled, and then only minimal overhead
    • Includes programming language (“D”) for expressing variety of tracing behavior
        • Not super simple, but many free scripts, some C-like elements
  • DTrace
    • Let's check what's available:
      • pfexec su -
      • dtrace -l | more
      • dtrace -l | wc -l
    • Create a file call syscall.d
        • syscall:::entry
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
  • DTrace
    • Let's check what's available:
      • pfexec su -
      • dtrace -l | more
      • dtrace -l | wc -l
    • Create a file call syscall.d
        • syscall:::entry
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
    • Not interested in Xorg calls ? Modify file:
        • syscall:::entry
        • /execname != “Xorg”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
  • DTrace
    • Not interested in Xorg calls ? Modify file:
        • syscall:::entry
        • /execname != “Xorg”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
    • Also not interested in dtrace calls ? Modify file:
        • syscall:::entry
        • /execname != “Xorg” && execname != “dtrace”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
  • DTrace
    • Only interested in calls by firefox ? Modify file:
        • syscall:::entry
        • /execname == “firefox-bin”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
    • Also not interested in dtrace calls ? Modify file:
        • syscall:::entry
        • /execname != “Xorg” && execname != “dtrace”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
  • DTrace
    • Only interested in calls by firefox ? Modify file:
        • syscall:::entry
        • /execname == “firefox-bin”/
        • {
        • printf(&quot;%s(%d) called %s &quot;, execname, pid, probefunc);
        • }
    • Execute the file with:
        • dtrace -qs syscall.d
    • So you already understand some very bascis !
    • But what did the dtrace -l output actually mean ?
      • Dtrace uses 'Probes'
      • Probes are instrumentation points
        • Think of them as 'sensors' on your system, at any touch point of software (kernel, OS, applications, code, etc.)
      • The names are a four-tuple: provider:module:function:name
      • Examples:
        • fbt:zfs:zfs_create_unique_device:entry
        • fbt:zfs:zfs_create_unique_device:return
  • DTrace
    • provider:module:function:name means:
    • Provider A library of related probes.
    • Module The module the function belongs to, either a kernel module or user segment.
    • Function The function name that contains the probe.
    • Name The name of the probe.
  • DTrace
    • There a many D scripts, information, and tutorials out there !
    • Very good starting point:
      • http://www.opensolaris.org/os/community/dtrace/
  • Network Virtualization
    • Network virtualization (Project “Crossbow”)
      • Enable Open Networking
      • Bandwith Control
        • Down to the protocol and port level
      • Virtual Wire – virtualize everything
        • NICs, Firewall, Switches, Routers
      • Don't run out of physical NICs anymore !
  • Project Crossbow
  • Project Crossbow
  • Network Virtualization
    • A great 'Getting Started Guide':
      http://www.sun.com/bigadmin/features/articles/crossbow_net_virt.pdf
  • Network Virtualization
    • Let's create a VNIC, and then a zone with exclusive IP stack (to use dhcp):
      • dladm show-link (check your physical NIC – in this example, we have e1000g0)
      • dladm create-vnic -l e1000g0 zonenic1
      • dladm show-link
      • dladm show-vnic (notice also the randomly assigned MAC address)
      • ifconfig zonenic1 plumb
      • ifconfig -a
  • Network Virtualization
    • Let's see if we can get a dhcp address:
      • ifconfig zonenic1 dhcp
      • ifconfig -a
      • ifconfig zonenic1 unplumb
      • ifconfig -a
    • Let's create a filesystem for our zone(s):
      • zfs create rpool/export/zones
      • zfs list
  • Network Virtualization
    • Let's create a zone !
      • # zonecfg -z zone1
      • zone1: No such zone configured
      • Use 'create' to begin configuring a new zone.
      • zonecfg:zone1> create
      • zonecfg:zone1> set zonepath=/export/zones/zone1
      • zonecfg:zone1> set autoboot=false
      • zonecfg:zone1> set ip-type=exclusive
      • zonecfg:zone1> add net
      • zonecfg:zone1:net> set physical= zonenic1
      • zonecfg:zone1:net> end
      • zonecfg:zone1> verify
      • zonecfg:zone1> commit
      • zonecfg:zone1> exit
  • Network Virtualization
    • Let's install and boot the zone:
      • zoneadm -z zone1 install (note: this might take a while, as it will fetch the OpenSolaris image from the /release repository !)
      • zoneadm -z zone1 boot
      • zlogin -C zone1 (to get console access to the booting zone)
      • Go through the few installation steps
      • You might then have to configure it to use dhcp:
      • touch /etc/dhcp.zonenic1
      • Delete hostname entry in /etc/hosts
  • Network Virtualization
      • reboot (check out how fast a zone reboots !)
      • zlogin zone1 (from the global zone)
      • To monitor the virtual network interface:
        • netstat -a -I zonenic1 5
    • You just created a new 'virtual machine' on your laptop !!
  • OpenSolaris Books
  • opensolaris.org & opensolaris.com
  • OpenSolaris Unlocks Your Potential OpenSolaris: Get it. Use it. Learn it. opensolaris.com/get
  • OpenSolaris 2009.06 A Workshop for some key Technologies ? ? ? ? ? ? ? ? ? ? Markus Weber Sun Microsystems, Inc. Iban Nieto OpenSolaris Community
