Ian Foster Computation Institute Argonne National Lab & University of Chicago
Abstract <ul><li>The past decade has seen increasingly ambitious and successful methods for outsourcing computing. Approac...
1890
1953
“ Computation may someday be organized as a public utility …  The computing utility could become the basis for a new and i...





I-WAY, 1995
The grid, 1998 <ul><li>“ Dependable, consistent, pervasive access to resources” </li></ul><ul><li>Dependable : Performance...
Application Infrastructure
Application Infrastructure Service oriented  infrastructure
Layered grid architecture Initially custom … later Web Services Application Fabric “ Controlling things locally”: Access t...

www.opensciencegrid.org
www.opensciencegrid.org
Bennett Berthenthal et al., www.sidgrid.org
Brian Tieman
Simplified example workflows Genome sequence analysis Physics data analysis Sloan digital sky survey www.opensciencegrid.org
“ Sine” workload, 2M tasks, 10MB:10ms ratio, 100 nodes, GCC policy, 50GB caches/node Ioan Raicu
Same scenario, but with dynamic resource provisioning
Data diffusion ine-wave workload: Summary <ul><li>GPFS      5.70 hrs,  ~8Gb/s,  1138 CPU hrs </li></ul><ul><li>DD+SRP   ...
Application Infrastructure Service oriented  infrastructure
Application Service oriented  applications Infrastructure Service oriented  infrastructure

Creating Services in 2008 Introduce and gRAVI  <ul><li>Introduce </li></ul><ul><ul><li>Define service </li></ul></ul><ul><...
As of  Oct 19 , 2008: 122 participants 105   services 70   data 35  analytical
Microarray clustering  using Taverna <ul><li>Query  and retrieve microarray data from a caArray data service: cagridnode.c...
The Globus-based LIGO data grid  Birmingham • Replicating >1 Terabyte/day to 8 sites >100 million replicas so far MTBF = 1...
<ul><li>Pull “missing” files to a storage system </li></ul>Data replication service List of required Files GridFTP Local R...
Why not leverage dynamic deployment capabilities? Physical machine Procure hardware VM VM Deploy virtual machine State exp...
Maybe we need to specialize further … User D S1 S2 S3 Service Provider “ Provide access to data D at S1, S2, S3 with perfo...
Infrastructure Applications
Energy Progress of adoption

US$3
Credit: Werner Vogels
Credit: Werner Vogels
Animoto EC2 image usage Day 1 Day 8 0 4000
Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways
Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways Amazon, GoGrid, Sun, Microsoft...
Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways Amazon, GoGrid, Sun, Microsoft...
Dynamo: Amazon’s highly available key-value store (DeCandia et al., SOSP’07) <ul><li>Simple query model </li></ul><ul><li>...
Technologies used in Dynamo Problem Technique Advantage Partitioning Consistent hashing Incremental scalability High Avail...
Application Service oriented  applications Infrastructure Service oriented  infrastructure
Energy Internet The Shape of Grids to Come?
Killers apps for COTB? <ul><li>Biomedical informatics/Evidence-based medicine </li></ul><ul><li>Human responses to global ...
Using IaaS in biomedical informatics My servers Chicago Chicago handle.net BIRN Chicago IaaS provider Chicago BIRN Chicago
“ The computer revolution hasn’t happened yet.” Alan Kay, 1997
Time Connectivity (on log scale) Science Enterprise Consumer “ When the network is as fast as the computer's    internal l...
Thank you! Computation Institute www.ci.uchicago.edu
Upcoming SlideShare
Loading in …5
×

Computing Outside The Box

3,256 views

Published on

The past decade has seen increasingly ambitious and successful methods for outsourcing computing. Approaches such as utility computing, on-demand computing, grid computing, software as a service, and cloud computing all seek to free computer applications from the limiting confines of a single computer. Software that thus runs "outside the box" can be more powerful (think Google, TeraGrid), dynamic (think Animoto, caBIG), and collaborative (think FaceBook, myExperiment). It can also be cheaper, due to economies of scale in hardware and software. The combination of new functionality and new economics inspires new applications, reduces barriers to entry for application providers, and in general disrupts the computing ecosystem. I discuss the new applications that outside-the-box computing enables, in both business and science, and the hardware and software architectures that make these new applications possible.

Published in: Technology, Business

Computing Outside The Box

  1. Ian Foster Computation Institute Argonne National Lab & University of Chicago
  2. Abstract <ul><li>The past decade has seen increasingly ambitious and successful methods for outsourcing computing. Approaches such as utility computing, on-demand computing, grid computing, software as a service, and cloud computing all seek to free computer applications from the limiting confines of a single computer. Software that thus runs &quot;outside the box&quot; can be more powerful (think Google, TeraGrid), dynamic (think Animoto, caBIG), and collaborative (think FaceBook, myExperiment). It can also be cheaper, due to economies of scale in hardware and software. The combination of new functionality and new economics inspires new applications, reduces barriers to entry for application providers, and in general disrupts the computing ecosystem. I discuss the new applications that outside-the-box computing enables, in both business and science, and the hardware and software architectures that make these new applications possible. </li></ul>
  3. 1890
  4. 1953
  5. “ Computation may someday be organized as a public utility … The computing utility could become the basis for a new and important industry.” John McCarthy (1961)
  6.
  7.
  8.
  9.
  10.
  11. I-WAY, 1995
  12. The grid, 1998 <ul><li>“ Dependable, consistent, pervasive access to resources” </li></ul><ul><li>Dependable : Performance and functionality guarantees </li></ul><ul><li>Consistent : Uniform interfaces to a wide variety of resources </li></ul><ul><li>Pervasive : Ability to “plug in” from anywhere </li></ul>
  13. Application Infrastructure
  14. Application Infrastructure Service oriented infrastructure
  15. Layered grid architecture Initially custom … later Web Services Application Fabric “ Controlling things locally”: Access to, & control of, resources Connectivity “ Talking to things”: communication (Internet protocols) & security Resource “ Sharing single resources”: negotiating access, controlling use Collective “ Managing multiple resources”: ubiquitous infrastructure services User “ Specialized services”: user- or appln-specific distributed services Internet Transport Application Link Internet Protocol Architecture
  16.
  17. www.opensciencegrid.org
  18. www.opensciencegrid.org
  19. Bennett Berthenthal et al., www.sidgrid.org
  20. Brian Tieman
  21. Simplified example workflows Genome sequence analysis Physics data analysis Sloan digital sky survey www.opensciencegrid.org
  22. “ Sine” workload, 2M tasks, 10MB:10ms ratio, 100 nodes, GCC policy, 50GB caches/node Ioan Raicu
  23. Same scenario, but with dynamic resource provisioning
  24. Data diffusion ine-wave workload: Summary <ul><li>GPFS  5.70 hrs, ~8Gb/s, 1138 CPU hrs </li></ul><ul><li>DD+SRP  1.80 hrs, ~25Gb/s, 361 CPU hrs </li></ul><ul><li>DD+DRP  1.86 hrs, ~24Gb/s, 253 CPU hrs </li></ul>
  25. Application Infrastructure Service oriented infrastructure
  26. Application Service oriented applications Infrastructure Service oriented infrastructure
  27.
  28. Creating Services in 2008 Introduce and gRAVI <ul><li>Introduce </li></ul><ul><ul><li>Define service </li></ul></ul><ul><ul><li>Create skeleton </li></ul></ul><ul><ul><li>Discover types </li></ul></ul><ul><ul><li>Add operations </li></ul></ul><ul><ul><li>Configure security </li></ul></ul><ul><li>Grid R emote A pplication V irtualization Infrastructure </li></ul><ul><ul><li>Wrap executables </li></ul></ul>Index service Repository Service Introduce Container Ohio State University and Argonne/U.Chicago Appln Service Create Store Advertize Discover Invoke; get results Transfer GAR Deploy Globus
  29. As of Oct 19 , 2008: 122 participants 105 services 70 data 35 analytical
  30. Microarray clustering using Taverna <ul><li>Query and retrieve microarray data from a caArray data service: cagridnode.c2b2.columbia.edu:8080/wsrf/services/cagrid/CaArrayScrub </li></ul><ul><li>Normalize microarray data using GenePattern analytical service node255.broad.mit.edu:6060/wsrf/services/cagrid/PreprocessDatasetMAGEService </li></ul><ul><li>Hierarchical clustering using geWorkbench analytical service: cagridnode.c2b2.columbia.edu:8080/wsrf/services/cagrid/HierarchicalClusteringMage </li></ul>Workflow in/output caGrid services “ Shim” services others Wei Tan
  31. The Globus-based LIGO data grid Birmingham • Replicating >1 Terabyte/day to 8 sites >100 million replicas so far MTBF = 1 month LIGO Gravitational Wave Observatory <ul><li>Cardiff </li></ul>AEI/Golm
  32. <ul><li>Pull “missing” files to a storage system </li></ul>Data replication service List of required Files GridFTP Local Replica Catalog Replica Location Index Data Replication Service Reliable File Transfer Service Local Replica Catalog GridFTP “ Design and Implementation of a Data Replication Service Based on the Lightweight Data Replicator System,” Chervenak et al., 2005 Replica Location Index Data Movement Data Location Data Replication
  33. Why not leverage dynamic deployment capabilities? Physical machine Procure hardware VM VM Deploy virtual machine State exposed & access uniformly at all levels Provisioning, management, and monitoring at all levels JVM Deploy container DRS Deploy service GridFTP LRC VO Services GridFTP Hypervisor/OS Deploy hypervisor/OS
  34. Maybe we need to specialize further … User D S1 S2 S3 Service Provider “ Provide access to data D at S1, S2, S3 with performance P” Resource Provider “ Provide storage with performance P1, network with P2, …” D S1 S2 S3 Replica catalog, User-level multicast, … D S1 S2 S3
  35. Infrastructure Applications
  36. Energy Progress of adoption
  37.
  38. US$3
  39. Credit: Werner Vogels
  40. Credit: Werner Vogels
  41. Animoto EC2 image usage Day 1 Day 8 0 4000
  42. Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways
  43. Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways Amazon, GoGrid, Sun, Microsoft, …
  44. Software Platform Infrastructure Saleforce.com, Google, Animoto, …, …, … caBIG, TG gateways Amazon, GoGrid, Sun, Microsoft, … Amazon, Google, Microsoft, …
  45. Dynamo: Amazon’s highly available key-value store (DeCandia et al., SOSP’07) <ul><li>Simple query model </li></ul><ul><li>Weak consistency, no isolation </li></ul><ul><li>Stringent SLAs (e.g., 300ms for 99.9% of requests; peak 500 requests/sec) </li></ul><ul><li>Incremental scalability </li></ul><ul><li>Symmetry </li></ul><ul><li>Decentralization </li></ul><ul><li>Heterogeneity </li></ul>
  46. Technologies used in Dynamo Problem Technique Advantage Partitioning Consistent hashing Incremental scalability High Availability for writes Vector clocks with reconciliation during reads Version size is decoupled from update rates Handling temporary failures Sloppy quorum and hinted handoff Provides high availability and durability guarantee when some of the replicas are not available Recovering from permanent failures Anti-entropy using Merkle trees Synchronizes divergent replicas in the background Membership and failure detection Gossip-based membership protocol and failure detection. Preserves symmetry and avoids having a centralized registry for storing membership and node liveness information
  47. Application Service oriented applications Infrastructure Service oriented infrastructure
  48. Energy Internet The Shape of Grids to Come?
  49. Killers apps for COTB? <ul><li>Biomedical informatics/Evidence-based medicine </li></ul><ul><li>Human responses to global climate disruption </li></ul>
  50. Using IaaS in biomedical informatics My servers Chicago Chicago handle.net BIRN Chicago IaaS provider Chicago BIRN Chicago
  51. “ The computer revolution hasn’t happened yet.” Alan Kay, 1997
  52. Time Connectivity (on log scale) Science Enterprise Consumer “ When the network is as fast as the computer's internal links, the machine disintegrates across the net into a set of special purpose appliances” (George Gilder, 2001) Grid Cloud ????
  53. Thank you! Computation Institute www.ci.uchicago.edu

×
