%w(map reduce).first - A Tale About Rabbits, Latency, and Slim Crontabs

  1. %w(map reduce).first A Tale About Rabbits, Latency and Slim Crontabs Paolo Negri thanks to: www.autoscout24.de
  2. Summary:
  3. Map http://www.matthiasdittrich.com/projekte/dliste/visualisations/index.html
  4. rabbitMQ http://www.flickr.com/photos/myxi/448253580
  5. crontab diet http://www.flickr.com/photos/tim_norris/2600843131/
  6. Map Reduce “Programming model for processing and generating large data sets” (Google)
  7. Map Reduce quot;Mapquot; step the master node takes the input, chops it up into smaller sub-problems, and distributes those to worker nodes. (Wikipedia)
  8. The problem Invoicing our clients
  9. Is it as simple as... clients.map do |client| client.invoice end
  10. No! Because the process is: • distributed • concurrent
  11. Problems: • How many nodes? • How many workers? • Distribution mechanism to feed the workers?
  12. What about queuing? • the master node takes the input, chops it up into smaller sub-problems, and publishes them in a queue • workers independently consume the content of the queue
  13. Here comes • RabbitMQ is an implementation of AMQP, the emerging standard for high performance enterprise messaging • It’s opensource • Can be used to manage queues • Written in Erlang
  14. Erlang? • Erlang is a general-purpose concurrent programming language designed by Ericsson • distributed • fault tolerant • soft real time • high availability
  15. Install it • sudo apt-get install rabbitmq • sudo gem install tmm1-amqp
  16. Do it - master node
  17. Use it - worker node
  18. What and where Master (ruby) RabbitMQ Worker TCP/IP (Erlang) (ruby) Worker (ruby)
  19. Get for free • Decoupling master/worker • Workers take care of feeding themselves • Flexible number of workers
  20. Get for free • RabbitMQ can be clustered • Support of message acknowledgement • Queues can be persisted on disk (at a price) • low latency
  21. Queue • Is an actual entity • has a name • can be inspected and managed
  22. EventMachine
  23. EventMachine Is an implementation of Reactor Pattern • Non blocking IO and lightweight concurrency • eliminate the complexities of high- performance threaded network programming
  24. EventMachine
  25. EventMachine amqp gem is built on EventMachine => you’re in a context where you can leverage concurrent programming
  26. EM - Deferrables
  27. EM - Deferrables “The Deferrable pattern allows you to specify any number of Ruby code blocks that will be executed at some future time when the status of the Deferrable object changes “
  28. EM - Deferrables
  29. EM - Deferrables
  30. Deferrables without deferrables with deferrables ClientStat ClientStat Arrears Arrears Time
  31. Achieved so far • Easy distribution of tasks • Architecture that supports arbitrary number of workers (and masters) • Concurrency within the single worker
  32. More rabbits Analogy with email system
  33. Multicasting - producer
  34. Multicasting - consumer
  35. Multicasting Cons1 Queue1 Publisher Queue2 Cons2 Exchange msg A Cons3 Queue3
  36. Multicasting Cons1 msg A Queue1 Publisher msg A Queue2 Cons2 Exchange Cons3 msg A Queue3
  37. Not only queues then Use messages distribution to build the nervous system of your app • communication across hosts, heterogeneous systems • low latency • clustering
  38. Where to start? crontab -l 5 * * * * bin/do_the_quick_thing.rb 0 2 * * * bin/do_the_scary_thing.rb
  39. Cron • Simple • Reliable • No maintenance • Status is not explicit • Locking? • Shot and forget
  40. Queue • Distributed easily • Reliable • Can be inspected • Add/decrease workers • Makes you think! • Adds more complexity
  41. On github - Projects • eventmachine/eventmachine • tmm1/amqp • macournoyer/thin • famoseagle/carrot • celldee/bunny • ezmobius/nanite
  42. Q&A ?
  43. Thanks! Paolo Negri / hungryblank

×
