“RabbitMQ
     python and ruby staring
       at the looking glass”
               - an asynchronous tale -

 •   http://w...
Resources

• http://www.slideshare.net/hungryblank
• http://github.com/hungryblank/rabbitmq_rupy_2009
About me
Time
       GNU/Linux - Dbs
                          Perl
         “systems”
                                   ...
AMQP
Advanced Message Queuing Protocol

   • standard for high performance
     enterprise messaging
   • totally open
   ...
AMQP
     Why is it interesting?
“We use asynchronicity heavily in those
cases where performance is an issue.
This is gen...
Summary

“AMQP as a case of asynchronous
protocol implementation in python
and ruby”
AMQP - Entities

Producer   msg



Consumer         msg
                       Broker


                       http://www....
AMQP - Entities
Producer   msg

Producer   msg



                       Broker
Producer   msg


Consumer         msg

Con...
AMQP
     Implementations

• Producer/Consumer: libs available for
  python and ruby
• Broker no python or ruby
  implemen...
• RabbitMQ is an implementation of
  AMQP Broker
• It’s opensource
• Written in Erlang
Erlang?
• general-purpose concurrent programming
  language designed by Ericsson
• first version written by J. Armstrong in...
Erlang?
Erlang's main strength is support for
concurrency
“Process communication is done via a
shared-nothing asynchronous...
+ Erlang


It’s messages all the way down
Async Python libs
            txAMQP

• “twisted AMQP”
• based on twisted python
• https://launchpad.net/txamqp
Async Python libs
               amqpev

• based on eventlet
• experimental, not ready for
  production
• http://bitbucket...
Async Python libs
                pika

• based on asyncio
• young but mantained by member of
  RabbitMQ core team
• http:...
Async Ruby libs
              amqp

• amqp gem
• based on EventMachine
• mature and widely used
• http://github.com/tmm1/a...
Async?

• Twisted Python
• Asyncio (python stdlib)
• eventlet (python)
• EventMachine (ruby)
Reactor Pattern

• Non blocking IO and lightweight
  concurrency
• eliminate the complexities of high-
  performance threa...
synchronous          asynchronous
 process      Time   process

   code                 code



 network                  ...
Not only reactor


Some of the libs provide more i.e. eventlet
provides also coroutines
Python, pick one
              pika
• asyncio is part of python stdlib
• easy syntax
• developer member of RabbitMQ team
•...
Code! Producer (ruby)
Consumer (ruby)
Behind the scenes

Publisher

  msg       Exchange   Queue   Consumer
What and where

     RabbitMQ
      (Erlang)              Producer
                          (ruby/python)

              ...
Producer (python)
Producer (python)




 TCP/IP connection
Producer (python)



       channel 1

 TCP/IP connection
Producer (python)



       channel 1

 TCP/IPchannel 2
         connection
Producer (python)



       channel 1

 TCP/IPchannel 2
         connection
       channel n
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Producer (python)
Publisher

  msg       Exchange   Queue   Consumer
Producer (python)
Publisher

  msg       Exchange   Queue     Consumer



             key based routing
Producer (python)
                       binding by key
Publisher

  msg       Exchange   Queue            Consumer



   ...
Consumer (python)
Things go wrong




If a consumer has a problem we might lose
          one or more messages
                   http://www...
ACKing consumer.rb
ACKing consumer.rb
ACKing consumer.rb
ACKing consumer.py
ACKing consumer.py
ACKing consumer.py
Achieved: decoupling

Publisher

  msg       Exchange   Queue   Consumer
Achieved: easy work
   load distribution
                               Consumer
Publisher

 msg A      Exchange   Queue  ...
Achieved: easy work
   load distribution
                               Consumer
Publisher

            Exchange   Queue  ...
Achieved: easy work
   load distribution
                                     Consumer
Publisher

            Exchange   Q...
Achieved: easy work
   load distribution
                               msg A Consumer
Publisher

            Exchange   Q...
prefetch?




http://www.flickr.com/photos/balakov/327431271
prefetch?


                      tcp ip
                      buffer

http://www.flickr.com/photos/balakov/327431271
prefetch - ruby
prefetch - ruby
prefetch - python
prefetch - python
More routing models

     multicasting
with fanout exchange
Fanout producer.rb
Fanout producer.rb
Fanout consumer.rb
Fanout consumer.rb
Fanout consumer.rb
Fanout consumer.rb
Fanout

                      Queue1   Cons1
Producer

msg A      Exchange   Queue2   Cons2


                      Queue3...
Fanout

                      Queue1   Cons1
Producer
           Exchange   Queue2   Cons2
            msg A

            ...
Fanout

                      msg A Queue1   Cons1
Producer
           Exchange   msg A Queue2   Cons2


                 ...
Fanout producer.py
Fanout producer.py
Fanout producer.py
Fanout consumer.py
Exchanges

• Direct - based on binding routing key
• Fanout - always to all bound queues
• Topic - pattern matching on rou...
Clustering
         RabbitMQ - node A   RabbitMQ - node B

TCP/IP                                           TCP/IP



    ...
Plugins

• introduced with v 1.7.0
• Add functionalities to the broker
• makes a interesting first erlang project
Ecosystem


• 65 RabbitMQ / AMQP projects on github
• + more on bitbucket, and others
Sync?

• easier to add to web apps
• suitable for non performance critical
  messaging
• useful to build cli tools
Sync?

• celldee / bunny - Ruby (github)
• famoseagle / carrot - Ruby (github)
• py-amqplib - Python (http://barryp.org/so...
Distributed systems

• ezmobious / nanite - Ruby (github)
• ask / carrot - Python (github)
• ask / celery - Python (github...
Real time web


• RabbitHub PubSubHubBub
• dansimpson / amqp-js (github)
Thank you!



    ?
