“Divide and conquer
      riding rabbits and
        trading gems”
   - a tale about distributed programming -

   • http:...
Resources

• http://www.slideshare.net/hungryblank
• http://github.com/hungryblank/rabbit_starter
About me
Time
       GNU/Linux - Dbs
                          Perl
         “systems”
                                   ...
Summary:
Distributed
Concurrent
Programming
rabbitMQ




http://www.flickr.com/photos/myxi/448253580
Control
The problem
   Given a dictionary of
1.000.000 search phrases,
  compare for each one
the first page of results on
 google....
Don’t do it.
It’s a violation of terms
        of service!
(Sorry, I needed an example that
required little or no explanat...
Comparison
The whole process
Great! but...

• Fetching, parsing and analyzing
  2.000.000 pages of results will take a
  long time
• we want to collect...
Distributed Computing
Is a method of solving computational
problem by dividing the problem into
  many tasks run simultane...
Map Reduce "Map" step

  the master node takes the
input, chops it up into smaller
sub-problems, and distributes
   those ...
Problems:

• How many nodes?
• How many workers?
• Distribution mechanism to
 feed the workers?
What about queuing?

• the master node takes the input, chops
  it up into smaller sub-problems, and
  publishes them in a...
Here comes

• RabbitMQ is an implementation of AMQP,
  the emerging standard for high
  performance enterprise messaging
•...
Erlang?
• general-purpose concurrent programming
  language designed by Ericsson
• first version written by J. Armstrong in...
Erlang - is coming back
• Projects
 • CouchDB - RESTful document storage
 • WebMachine - REST toolkit
 • Nitrogen - web fr...
+ Erlang


It’s messages all the way down
Install it


    • sudo apt-get install rabbitmq
    • sudo gem install tmm1-amqp
Note: rabbitMQ must be v1.6.0 and amqp g...
Do it! - master node
Do it! - worker node
Get for free

• Decoupling master/worker
• Workers take care of feeding themselves
• Flexible number of workers
Behind the scenes

                            Worker1
Master

msg A    Exchange   Queue   Worker2


                     ...
Behind the scenes

                            Worker1
Master

         Exchange   Queue   Worker2
          msg A

      ...
Behind the scenes

                                  Worker1
Master

         Exchange   Queue msg A   Worker2


         ...
Behind the scenes

                            msg A   Worker1
Master

         Exchange   Queue           Worker2


     ...
RabbitMQ
• Multiple exchanges (and multiple types of
  exchange)
• Multiple queues
• Queues are connected by bindings to
 ...
RabbitMQ

• Exchanges and queues have names
• BUT direct exchanges created implicitly are
  not public and don’t have name...
What and where
                          Master
                          (ruby)
     RabbitMQ
      (Erlang)            W...
Problem #1




If a worker has a problem we might lose one
             or more messages
                    http://www.fli...
Solution - ACK in worker
Acknoledgement
• messages - 1 or more depending by
  prefetch settings - are passed to the client
• the client processes a...
http://www.flickr.com/photos/streetfly_jz/2770586821/



           Problem #2




No convenient way to control the workers
System queue - worker
System queue - control




• save it as system_command.rb
• ruby system_command.rb halt
System queue

                              Queue1   Worker1
Control script

   msg A           Exchange   Queue2   Worker...
System queue

                              Queue1   Worker1
Control script
                   Exchange   Queue2   Worker2...
System queue

                              msg A Queue1   Worker1
Control script
                   Exchange   msg A Queu...
EventMachine
EventMachine
Is an implementation of Reactor Pattern


• Non blocking IO and lightweight
  concurrency
• eliminate the com...
without EM                with EM
Ruby process          Ruby process
               Time
    code                  code


...
EventMachine

amqp gem is built on top of
EventMachine => you’re in a
  context where you can
    leverage concurrent
    ...
EM - Deferrables

“The Deferrable pattern allows you to specify
 any number of Ruby code blocks that will be
executed at s...
EM - Deferrables
EM - Deferrables
EM - Deferrables
EM - Deferrables
Deferrables
without deferrables      with deferrables


    GooglePage          GooglePage
                               ...
http://www.flickr.com/photos/philocrites/341850461/



          Problem #3




How many of them?
what are they doing?
Heartbeat - worker
Heartbeat monitor
Heartbeat queue

Worker1 msg A


Worker2           Exchange   Queue   Monitor


Worker3
          msg B
Heartbeat queue

Worker1

             msg A
Worker2     Exchange   Queue   Monitor
             msg B

Worker3
Heartbeat queue

Worker1


Worker2     Exchange   Queue msg B msg A   Monitor


Worker3
Clustering
         RabbitMQ - node A   RabbitMQ - node B

TCP/IP                                           TCP/IP



    ...
async vs sync
       Syncronous clients on github



• famoseagle/carrot
• celldee/bunny
Rabbits on github
• danielsdeleo/moqueue Tests/stubbing
• Check out ezmobius/nanite
  “self assembling fabric of ruby daem...
More rabbits on github

• tmm1/em-spec
• eventmachine/eventmachine
• tmm1/amqp
• macournoyer/thin
Q&A


 ?
Thanks!
(Thanks Mark!)

    Paolo Negri

/        hungryblank
