Mobile
Augmented Reality



     Marc René Gardeya -   - www.hoppala.eu
www.hoppala.eu



Marc René Gardeya, Founder and CEO
Mobile
Augmented Reality
 What it is and how it works
      Layar and PHP

        Marc René Gardeya -   - www.hoppala.eu
Augmented Reality
        airtagging
      optic internet
  synthetic environment

       Marc René Gardeya -   - www.hopp...
Marc René Gardeya -   - www.hoppala.eu
It‘s been there before




      Columbia University Computer Graphics and User Interfaces Lab

        Marc René Gardeya ...
What‘s so great
combines real and virtual
 interactive and realtime
                       3D
      Marc René Gardeya -   ...
How it works
 Camera
  Screen
 Location
 Direction
Information
                                                Layer devel...
Markerless
 Tracking



gps                           compass
      Marc René Gardeya -   - www.hoppala.eu
Markerbased
 Tracking



  Marc René Gardeya -   - www.hoppala.eu
Markerless                     Markerbased




works everywhere                  needs markers
  only outside             ...
Future
converging technologies
  image recognition
    standardization

     Marc René Gardeya -   - www.hoppala.eu
Marc René Gardeya -   - www.hoppala.eu
Layar Open Platform

       Brands & Content




 Developers                                       Users
         Marc Ren...
Worlds Largest Platform

      500 layers published
   2.000 layers in development
 3.000 content creators worldwide
     ...
Layar Distribution

       Global preinstallation

Tens of millions of phones with Layar
  preinstalled already in the sho...
Best practices


   Marc René Gardeya -   - www.hoppala.eu
City marketing




                                           Layer developed by NAi / IN10
  Marc René Gardeya -   - www....
Entertainment




                                           Layer developed by AugmentReality
  Marc René Gardeya -   - w...
Art




 Chris Manzione: „Key element of our layer is that the objects are site-specific. This
is different than most other...
Ubisoft‘s Splintercell




                                              Layer developed by Muzar.org
     Marc René Garde...
www.hoppala.eu
Easter Greetings
Place 3D easter eggs from web and mobile


                                           Leave a message
   ...
Berlin Wall




                                  Layer developed by Hoppala / Superimpose
Marc René Gardeya -   - www.hop...
Marc René Gardeya -   - www.hoppala.eu
Layar Architecture




    Marc René Gardeya -   - www.hoppala.eu
Basic webservice
<?php
   define( 'LAYERNAME', 'mylayer' );
   $hotspots = array();

     $response = array(
        'hots...
JSON Response

{
    "hotspots":[],
    "layer":"mylayer",
    "errorCode":0
}


      Marc René Gardeya -   - www.hoppala...
Return Points of Interest




       Marc René Gardeya -   - www.hoppala.eu
Return Points of Interest
  <?php
     $hotspots = array();

       $hotspot = array(
          'title'        => 'Restaur...
World Geodetic System 1984
                                       Stuttgart
  WGS 84                               Latitud...
POI next to you
<?php
   $lat = $_GET['lat'];
   $lon = $_GET['lon'];

     $hotspot = array(
        'title'        =>   ...
Provide actions




  Marc René Gardeya -   - www.hoppala.eu
Provide actions
<?php
   $hotspot = array(
      'title'        => 'Bäckerei Blank',

          ...

          'actions'  ...
3D model




Marc René Gardeya -   - www.hoppala.eu
3D model
<?php
   $hotspot     = array(
      ...

          'dimension'      => 1,
          'object'         => array(
 ...
www.layar.com


Marc René Gardeya -   - www.hoppala.eu
THANK YO U!
     www.hoppala.eu



 Marc René Gardeya, Founder and CEO
Upcoming SlideShare
Loading in...5
×

PHP Usergroup Stuttgart

1,407

Published on

Mai, 12th 2010, PHP Usergroup Stuttgart

Published in: Technology
0 Comments
1 Like
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
1,407
On Slideshare
0
From Embeds
0
Number of Embeds
1
Actions
Shares
0
Downloads
14
Comments
0
Likes
1
Embeds 0
No embeds

No notes for slide

Transcript of "PHP Usergroup Stuttgart"

  1. 1. Mobile Augmented Reality Marc René Gardeya - - www.hoppala.eu
  2. 2. www.hoppala.eu Marc René Gardeya, Founder and CEO
  3. 3. Mobile Augmented Reality What it is and how it works Layar and PHP Marc René Gardeya - - www.hoppala.eu
  4. 4. Augmented Reality airtagging optic internet synthetic environment Marc René Gardeya - - www.hoppala.eu
  5. 5. Marc René Gardeya - - www.hoppala.eu
  6. 6. It‘s been there before Columbia University Computer Graphics and User Interfaces Lab Marc René Gardeya - - www.hoppala.eu
  7. 7. What‘s so great combines real and virtual interactive and realtime 3D Marc René Gardeya - - www.hoppala.eu
  8. 8. How it works Camera Screen Location Direction Information Layer developed by Hoppala Marc René Gardeya - - www.hoppala.eu
  9. 9. Markerless Tracking gps compass Marc René Gardeya - - www.hoppala.eu
  10. 10. Markerbased Tracking Marc René Gardeya - - www.hoppala.eu
  11. 11. Markerless Markerbased works everywhere needs markers only outside works inside Marc René Gardeya - - www.hoppala.eu
  12. 12. Future converging technologies image recognition standardization Marc René Gardeya - - www.hoppala.eu
  13. 13. Marc René Gardeya - - www.hoppala.eu
  14. 14. Layar Open Platform Brands & Content Developers Users Marc René Gardeya - - www.hoppala.eu
  15. 15. Worlds Largest Platform 500 layers published 2.000 layers in development 3.000 content creators worldwide 1.500.000 downloads Android & iPhone Marc René Gardeya - - www.hoppala.eu
  16. 16. Layar Distribution Global preinstallation Tens of millions of phones with Layar preinstalled already in the shops #1 in all markets except Japan (#2) Marc René Gardeya - - www.hoppala.eu
  17. 17. Best practices Marc René Gardeya - - www.hoppala.eu
  18. 18. City marketing Layer developed by NAi / IN10 Marc René Gardeya - - www.hoppala.eu
  19. 19. Entertainment Layer developed by AugmentReality Marc René Gardeya - - www.hoppala.eu
  20. 20. Art Chris Manzione: „Key element of our layer is that the objects are site-specific. This is different than most other digital media that can be easily transfered and shared. This requires the users presence and interaction with the site itself.“ Layer developed by Superimpose / VPAP Marc René Gardeya - - www.hoppala.eu
  21. 21. Ubisoft‘s Splintercell Layer developed by Muzar.org Marc René Gardeya - - www.hoppala.eu
  22. 22. www.hoppala.eu
  23. 23. Easter Greetings Place 3D easter eggs from web and mobile Leave a message for your friend Happy easter! again! Loo king forward to see you Layer developed by Hoppala Marc René Gardeya - - www.hoppala.eu
  24. 24. Berlin Wall Layer developed by Hoppala / Superimpose Marc René Gardeya - - www.hoppala.eu
  25. 25. Marc René Gardeya - - www.hoppala.eu
  26. 26. Layar Architecture Marc René Gardeya - - www.hoppala.eu
  27. 27. Basic webservice <?php define( 'LAYERNAME', 'mylayer' ); $hotspots = array(); $response = array( 'hotspots' => $hotspots, 'layer' => LAYERNAME, 'errorCode' => 0, ); $json = json_encode( $response ); header( 'Content-type: application/json'); echo $json; ?> Marc René Gardeya - - www.hoppala.eu
  28. 28. JSON Response { "hotspots":[], "layer":"mylayer", "errorCode":0 } Marc René Gardeya - - www.hoppala.eu
  29. 29. Return Points of Interest Marc René Gardeya - - www.hoppala.eu
  30. 30. Return Points of Interest <?php $hotspots = array(); $hotspot = array( 'title' => 'Restaurant', 'line2' => '', 'line3' => '', 'line4' => '', 'attribution' => 'Footnote', 'lat' => (int)(48.8 * 1000000.0), 'lon' => (int)(9.2 * 1000000.0) ); $hotspots[] = $hotspot; ?> Marc René Gardeya - - www.hoppala.eu
  31. 31. World Geodetic System 1984 Stuttgart WGS 84 Latitude: 48.8 Longitude: 9.2 +Latitude -Latitude -Longitude +Longitude Marc René Gardeya - - www.hoppala.eu
  32. 32. POI next to you <?php $lat = $_GET['lat']; $lon = $_GET['lon']; $hotspot = array( 'title' => 'Sticky POI', 'line2' => 'It sits right', 'line3' => 'next to you', 'line4' => '', 'attribution' => 'footnote', 'lat' => (int)($lat + 0.0005) * 1000000.0), 'lon' => (int)($lon * 1000000.0) ); ?> Marc René Gardeya - - www.hoppala.eu
  33. 33. Provide actions Marc René Gardeya - - www.hoppala.eu
  34. 34. Provide actions <?php $hotspot = array( 'title' => 'Bäckerei Blank', ... 'actions' => array( array( 'label' => 'Go to website', 'uri' => 'http://www.hoppala.eu' ) ) ); ?> Marc René Gardeya - - www.hoppala.eu
  35. 35. 3D model Marc René Gardeya - - www.hoppala.eu
  36. 36. 3D model <?php $hotspot = array( ... 'dimension' => 1, 'object' => array( 'baseURL' => BASEURL, 'full' => MODEL, 'size' => 20 // tell client before loading model ), 'transform' => array( 'angle' => 0, 'rel' => FALSE, 'scale' => 10 // make model 10 times larger ) ); ?> Marc René Gardeya - - www.hoppala.eu
  37. 37. www.layar.com Marc René Gardeya - - www.hoppala.eu
  38. 38. THANK YO U! www.hoppala.eu Marc René Gardeya, Founder and CEO
