Cloud Foundry for Spring DevelopersGunnar Hillert, Member of Technical Staff, Spring Integration                          ...
Agenda§  Overview§  Deployment§  Debugging§  Profiling§  Agnostic War Files§  Modular Cloud Apps                    ...
What is Cloud Foundry?                         3
4
Three Layers of Cloud Computing§  SaaS  •  Software as a Service§  PaaS  •  Platform as a Service§  IaaS  •  Infrastruc...
Choice of clouds                                        .js       Data       Services                                     ...
Broad Support for Languages/Application Frameworks§  JVM  •  Spring, Grails, Roo, Lift, plain Java§  Ruby  •  Rails, Sin...
JVM Frameworks§  Unit of deployment: Java WAR files  •  Can run any standard War file  •  Servlet 2.5  •  Don’t assume pa...
Services§  Relational database  •  Postgres  •  MySQL§  Key-value store  •  Redis§  Document store  •  MongoDB§  Messa...
Open Source§  Source code available under Apache License v2.0 •  https://github.com/cloudfoundry/•  VCAP •  https://githu...
Logical View               11
Architecture     Architecture           25 Thursday, October 27, 11   12
Deployment Options                     13
Deployment Options§  VMC  •  Ruby based command line tool§  SpringSource Tool Suite (STS)§  Grails§  Spring Roo Cloud ...
DEMODeployment Options                     15
Debugging            16
Debugging§  Start Cloud Foundry applications in debug mode§  Set Break Points for Micro Cloud Foundry§  STS 2.8.1 suppo...
Caldecott§  TCP over HTTP tunnel§  Local client§  Remote server                           18
Caldecott - Multiple Services and Sessions§  One vcc server instance •  Manages multiple tunnels§  One vcc client instan...
DEMODebugging            20
Profiling            21
Profiling – Spring Insight§  Providing real-time application runtime performance and behavior information for Java Spring...
DEMOSpring Insight for Cloud Foundry                                   23
Agnostic War Files                     24
Agnostic War Files – Toolbox§  Auto Reconfiguration§  Cloud Namespace§  Spring 3.1 Profiles                            ...
Agnostic War Files – Auto Reconfiguration§  Move existing Applications easily to Cloud Foundry§  Makes 2 modifications a...
Agnostic War Files – Auto Reconfiguration        Service Type                 Replaced Bean Type           MySQL       jav...
Agnostic War Files – Auto Reconfiguration§  Limitations  •  one service of a given service type  •  one bean of the match...
Agnostic War Files – Cloud Namespace§  Explicit configuration of Cloud Foundry Services§  Finer grained control of confi...
Agnostic War Files – Cloud Namespace§  Setup – Maven<dependency>  <groupId>org.cloudfoundry</groupId>  <artifactId>cloudf...
Available Namespace Elements§  Define and use a DataSource <cloud:data-source id="dataSource" /> <bean id="jdbcTemplate” ...
Available Namespace Elements§  MongoDB Support •  <cloud:mongo-db-factory>§  Redis Support •  <cloud:redis-connection-fa...
Agnostic War Files – Spring Profiles§  Spring 3.1 adds new support for environments§  Deploy to Cloud Foundry and Stand-...
Modular Cloud Apps                     34
Monolithic Enterprise Application                                    35
Benefits of App-level Modularity§  Efficient Elasticity§  Fault Isolation§  Dynamic Configuration§  “always-on”/Rollin...
Modularized Enterprise Application                                     37
DEMOSpring Integration                     38
Resources            39
Resources§  Cloud Foundry on Ubuntu  http://blog.dustinkirkland.com/2011/08/howto-install-cloudfoundry-server-  paas.html...
Resources§  Cloud Foundry Maven Plugin  http://blog.springsource.com/2011/09/22/rapid-cloud-foundry-deployments-with-  ma...
Resources§  Spring Auto Reconfiguration  http://blog.springsource.org/2011/11/04/using-cloud-foundry-services-with-spring...
Resources§  Spring Integration  http://www.springsource.org/spring-integration  https://github.com/SpringSource/spring-in...
THANK YOU!     Sign up for a free account at: http://www.cloudfoundry.com/Email:      ghillert@vmware.comTwitter:    https...
