Building Good Relations
Using MongoDB and a relational database in your apps
Hayes Davis
  @hayesdavis
 CheapTweet.com
If you’ve already got
        an app
You probably already
  have a database
It’s probably relational




                   http://www.mbari.org/ssds/ReferenceDocuments/RDB_ER.gif
It’s probably
gotten a little
     bit big

         http://www.neonlite.ca/archives/images/big%20cat.jpg
Or maybe it’s
gotten huge



                http://www.fahad.com/pics/liger.jpg
And it’s probably
pretty complicated
                 http://www.mazes.org.uk/i/101005m.gif
Or maybe
  really
complicated

              http://tommilsom.com/wp-content/files/france/maze.jpg
Which makes it harder
     to change
                  http://twitter.com/dacort/status/11023722831
But, you’re not
going to throw
  all that out

                  http://blog.makezine.com/284163191_6f09179853_o.jpg
So let’s make NoSQL
and SQL live in harmony




               http://curiousanimals.net/wp-content/uploads/2008/03/cat-an...
But first...
Do you even need to?
We all want to
play with shiny
   new toys

    http://actionfan.files.wordpress.com/2009/07/voltron_metallic-vinyl-edit.jpg
But sometimes
 that’s not the
   best plan

                  http://www.pwn3d.us/wp-content/uploads/2006/11/voltron_1.jpg
So, give yourself a test
#1
Is my data relational?
#1
Are my data relational?
#2
   Do my data access
patterns lend themselves
   to denormaliation?
#3
Do I expect a lot of
 schema change?
#4
    Can I drop ACID?
(Atomicity, Consistency, Isolation, Durability)
#5
Do I want to support a
     new piece of
    infrastructure?
If you answered yes to
any of these questions...
... at least for parts of
        your app...
... then
 MongoDB
  might be
right for you

                http://www.rankopedia.com/CandidatePix/25781.gif
Where to start...
Utilities and supporting
           tools
Logging & analysis
              http://sbadrinath.files.wordpress.com/2009/03/different26rqcu3.jpg
We built Parrot




           http://filmfanatic.org/reviews/wp-content/uploads/2008/01/anfscd-parrot.png
Isolated
subsystems


             http://themarkvolta.files.wordpress.com/2009/01/lost-map.jpg
Comments might be a
   good choice
           http://www.readwriteweb.com/archives/facebook_wants_to_be_your_one_true_logi...
Getting practical
   (in Rails, at least)
Using MongoMapper
 and ActiveRecord
Getting set up
config/mongodb.yml
development:
  host: 127.0.0.1

test:
  host: 127.0.0.1

production:
  host: mongo-server.local
config/initializers/mongo.rb
# Read in the config info
mongo_cfg = YAML.load(
  IO.read("#{RAILS_ROOT}/config/mongodb.yml")...
Mixing your MM with
      your AR
              http://i.treehugger.com/images/2007/10/24/frankenstein-jj-001.jpg
app/models/
preferences.rb
class Preferences

  include MongoMapper::Document

  key :user_id, Integer

end
apps/models/user.rb
class User < ActiveRecord::Base

  after_save :save_prefs

  def preferences
    @preferences ||= Pref...
Usage
# Set any preferences you like
user = User.find_by_login('thatguy')
user.preferences[:foreground] = '#FF0000'
user.p...
Our general solution
active-expando
 (very, very alpha)
Any attribute, any time
# Grab a user
user = User.find(1)
# Now set an attribute that didn't exist before
user.expandos.fo...
Skip expandos, use delegate
 class Post < ActiveRecord::Base
   expando_config do
     delegate :tags
   end
 end

 p = Po...
It’s a rails plugin
It’s on GitHub
(http://github.com/hayesdavis/active-expando)
Other issues
Where we’re going we
don’t need migrations
       (or do we?)
                     http://www.gordtep.com/files/2009/08/btt...
Flexibility is great
   (until it bites you)
A general
word of
 caution
MongoDB is a moving
      target
So are the tools
There will be bugs




           http://nitishkrishna.files.wordpress.com/2009/07/2007_there_will_be_blood_013.jpg
So, be ready to upgrade
Questions?
Upcoming SlideShare
Loading in...5
×

Using MongoDB and a Relational Database at MongoDB Day

25,271

Published on

Talk given at MongoDB Day in Austin about how to make MongoDB and a relational database work together in your application.

Published in: Technology
0 Comments
9 Likes
Statistics
Notes
  • Be the first to comment

No Downloads
Views
Total Views
25,271
On Slideshare
0
From Embeds
0
Number of Embeds
19
Actions
Shares
0
Downloads
212
Comments
0
Likes
9
Embeds 0
No embeds

No notes for slide

Using MongoDB and a Relational Database at MongoDB Day

  1. 1. Building Good Relations Using MongoDB and a relational database in your apps
  2. 2. Hayes Davis @hayesdavis CheapTweet.com
  3. 3. If you’ve already got an app
  4. 4. You probably already have a database
  5. 5. It’s probably relational http://www.mbari.org/ssds/ReferenceDocuments/RDB_ER.gif
  6. 6. It’s probably gotten a little bit big http://www.neonlite.ca/archives/images/big%20cat.jpg
  7. 7. Or maybe it’s gotten huge http://www.fahad.com/pics/liger.jpg
  8. 8. And it’s probably pretty complicated http://www.mazes.org.uk/i/101005m.gif
  9. 9. Or maybe really complicated http://tommilsom.com/wp-content/files/france/maze.jpg
  10. 10. Which makes it harder to change http://twitter.com/dacort/status/11023722831
  11. 11. But, you’re not going to throw all that out http://blog.makezine.com/284163191_6f09179853_o.jpg
  12. 12. So let’s make NoSQL and SQL live in harmony http://curiousanimals.net/wp-content/uploads/2008/03/cat-and-dog-sleep.jpg
  13. 13. But first...
  14. 14. Do you even need to?
  15. 15. We all want to play with shiny new toys http://actionfan.files.wordpress.com/2009/07/voltron_metallic-vinyl-edit.jpg
  16. 16. But sometimes that’s not the best plan http://www.pwn3d.us/wp-content/uploads/2006/11/voltron_1.jpg
  17. 17. So, give yourself a test
  18. 18. #1 Is my data relational?
  19. 19. #1 Are my data relational?
  20. 20. #2 Do my data access patterns lend themselves to denormaliation?
  21. 21. #3 Do I expect a lot of schema change?
  22. 22. #4 Can I drop ACID? (Atomicity, Consistency, Isolation, Durability)
  23. 23. #5 Do I want to support a new piece of infrastructure?
  24. 24. If you answered yes to any of these questions...
  25. 25. ... at least for parts of your app...
  26. 26. ... then MongoDB might be right for you http://www.rankopedia.com/CandidatePix/25781.gif
  27. 27. Where to start...
  28. 28. Utilities and supporting tools
  29. 29. Logging & analysis http://sbadrinath.files.wordpress.com/2009/03/different26rqcu3.jpg
  30. 30. We built Parrot http://filmfanatic.org/reviews/wp-content/uploads/2008/01/anfscd-parrot.png
  31. 31. Isolated subsystems http://themarkvolta.files.wordpress.com/2009/01/lost-map.jpg
  32. 32. Comments might be a good choice http://www.readwriteweb.com/archives/facebook_wants_to_be_your_one_true_login.php
  33. 33. Getting practical (in Rails, at least)
  34. 34. Using MongoMapper and ActiveRecord
  35. 35. Getting set up
  36. 36. config/mongodb.yml development: host: 127.0.0.1 test: host: 127.0.0.1 production: host: mongo-server.local
  37. 37. config/initializers/mongo.rb # Read in the config info mongo_cfg = YAML.load( IO.read("#{RAILS_ROOT}/config/mongodb.yml") )[RAILS_ENV] # Create the connection from mongodb.yml args = [mongo_cfg['host'],mongo_cfg['port']].compact MongoMapper.connection = Mongo::Connection.new(*conn_args) # Pick the Mongo database db_cfg = Rails.configuration.database_configuration[RAILS_ENV] MongoMapper.database = mongo_cfg['database'] || db_cfg['database']
  38. 38. Mixing your MM with your AR http://i.treehugger.com/images/2007/10/24/frankenstein-jj-001.jpg
  39. 39. app/models/ preferences.rb class Preferences include MongoMapper::Document key :user_id, Integer end
  40. 40. apps/models/user.rb class User < ActiveRecord::Base after_save :save_prefs def preferences @preferences ||= Preferences.find_or_create_by_user_id(id) end private def save_prefs @preferences.save if @preferences end end
  41. 41. Usage # Set any preferences you like user = User.find_by_login('thatguy') user.preferences[:foreground] = '#FF0000' user.preferences[:foo] = 'bar' user.save # Later on, you can do this user = User.find_by_login('thatguy') user.preferences[:foreground] #returns '#FF0000'
  42. 42. Our general solution
  43. 43. active-expando (very, very alpha)
  44. 44. Any attribute, any time # Grab a user user = User.find(1) # Now set an attribute that didn't exist before user.expandos.foreground = '#FF0000' # foreground is saved in Mongo user.save # Find any users with a red foreground color users = User.expando_all( :conditions=>{:foreground=>'#FF0000'} )
  45. 45. Skip expandos, use delegate class Post < ActiveRecord::Base expando_config do delegate :tags end end p = Post.find(1) p.tags = ['foo','bar'] p.save # Find any Post with the tag "foo" Post.expando_all(:conditions=>{'tags'=>'foo'})
  46. 46. It’s a rails plugin
  47. 47. It’s on GitHub (http://github.com/hayesdavis/active-expando)
  48. 48. Other issues
  49. 49. Where we’re going we don’t need migrations (or do we?) http://www.gordtep.com/files/2009/08/bttf2.jpg
  50. 50. Flexibility is great (until it bites you)
  51. 51. A general word of caution
  52. 52. MongoDB is a moving target
  53. 53. So are the tools
  54. 54. There will be bugs http://nitishkrishna.files.wordpress.com/2009/07/2007_there_will_be_blood_013.jpg
  55. 55. So, be ready to upgrade
  56. 56. Questions?
