TechMentor 2012: Deploying Windows Server 2012 Server Core

  1. 1. http://go.microsoft.com/fwlink/?LinkId=76620
  2. 2. Classic “Full Server” Server with a GUI • Full Metro-style GUI shell • Install Desktop Experience to run Metro-style apps NEW Full Server without Server Graphical Shell • No Explorer, Internet Explorer or associated files • MMC, Server Manager, and a subset of ControlMinimal Server Interface Panel applets are still installed • Provides many of the benefits of Server Core for those applications or users that haven’t yet made the transition Server Core • NEW Can move between Server Core and Full Server Core Server by simply installing or uninstalling components
  3. 3. POWERSHELLUninstall-WindowsFeature Server-Gui-Mgmt-Infra -Restart Single reboot required to restart all servicesPOWERSHELLInstall-WindowsFeature Server-Gui-Mgmt-Infra,Server-Gui-Shell -Restart NEW Can install multiple features with one command by separating with commas
  4. 4. Server with a GUI
  5. 5. POWERSHELLUninstall-WindowsFeature Server-Gui-Shell -RestartPOWERSHELLInstall-WindowsFeature Server-Gui-Shell -RestartPOWERSHELLInstall-WindowsFeature Server-Gui-Mgmt-Infra -Restart
  6. 6. calls to HTML Help API will return NULL!
  7. 7. http://www.dependencywalker.com
  8. 8. Server Core Minimal Server Server Graphical Interface ShellServerCore = 1 Set Set SetServerGuiMgmt = 1 Not Set Set SetServerGuiShell = 1 Not Set Not Set SetWin32_ServerFeaturehttp://msdn.microsoft.com/en-us/windows/cc280268
  9. 9. Server Core Minimal Server Interface Server with a GUI Desktop ExperienceCommand Prompt a a a aPowerShell/.NET a a a aServer Manager x a a aMMC x a a aControl Panel x x a aCPL Applets x Some a aExplorer Shell x x a aTaskbar x x a aSystem Tray x x a aInternet Explorer x x a aHelp x x a aThemes x x x aStart screen (Metro) x x a aMetro-style apps x x x aMedia Player x x x a
  10. 10. POWERSHELLUninstall-WindowsFeature <FeatureName> -Remove
  11. 11. CMDmkdir c:mountdirCMDDism /get-wiminfo /wimfile:<drive>:sourcesinstall.wimCMDdism /mount-wim /WimFile:<drive>:sourcesinstall.wim/Index:<#_from_step_2> /MountDir:c:mountdir /readonlyPOWERSHELL with mounted WIMInstall-WindowsFeature Server-Gui-Mgmt-Infra,Server-Gui-Shell–Restart –Source c:mountdirwindowswinsxs
  12. 12. CMDDism /get-wiminfo /wimfile:<drive>:sourcesinstall.wimPOWERSHELLInstall-WindowsFeature Server-Gui-Mgmt-Infra,Server-Gui-Shell–Restart –Source wim:<drive>:sourcesinstall.wim:4
  13. 13. POWERSHELLInstall-WindowsFeature <FeatureName>-Source <Source>
  14. 14. POWERSHELL with mounted WIMInstall-WindowsFeature Server-Gui-Mgmt-Infra,Server-Gui-Shell–Restart –Source c:mountdirwindowswinsxsPOWERSHELLInstall-WindowsFeature Server-Gui-Mgmt-Infra,Server-Gui-Shell–Restart –Source wim:d:sourcesinstall.wim:4
