The Art of Infrastructure Elasticity              April 28th, 2012    Cloud Developer Conference 2012 , Bangalore         ...
Agenda• Problem• Challenges• Requirements• Solution Architecture• Q&A                          2
What is the problem scenario ?                                 3
Big Sales Promotion every quarter by         the Enterprise                                       4
• Massive online Concurrent Visitors• Limited processing capacity of the Booking Engine                (~3k requests/sec) ...
• Unhappy Visitors• More Booking opportunity lost                                  6
Solution (Step 1):• Create a Queuing App before the Booking engine• Efficiently Queue the concurrent visitors             ...
Solution (Step 2) :Moderate and move the visitors waiting in Queuingapp to Booking engine                                 ...
What are the Challenges ?                            9
Concurrency• HTTP/AJAX/REST requests • Total : 500+ Million requests in 6 hours • Average :23k+ requests/sec • Peak : 80K+...
Queue efficiency• Allot unique Queue Numbers for visitors• Queue Number allotment on Fair Basis (As  much possible)• Reduc...
Load Volatility                                         Peak utilization duringCompute                                    ...
IP Whitelisting Public Cloud                                                      3rd Party                               ...
Variety of OS / Software’s• RedHat OS for Load Balancer , NoSQL and  Queue Layer• Apache Tomcat Java web/App Layer• CentOS...
What are the requirements from          enterprise ?                                 15
Requirements• Elastic Infrastructure • Create the Infrastructure 2 hrs before the   promo • Tear down infrastructure 2 hrs...
Solution Architecture                        17
Solution ArchitectureOption 1: Single Queue ( Initial thought)                    Queuing                   Application   ...
Solution ArchitectureOption 2: Parallel Queue ( Recommended)                                 BookingConcurrent       Queui...
Request types• Customer Visit is a HTTP request to the  Queuing Application• Current Visitor Queue position is a AJAX  cal...
Solution Step 1 : The Cloud ?• Amazon Web Services• We had 4+ years Architecture experience in AWS• It satisfied many cust...
Solution Step 2 : R53/NW                                Amazon Virtual Private CloudUsers         Amazon         Route 53 ...
Solution Step 3 : Load Balancing                                                         Amazon Virtual Private CloudUsers...
Solution Step 3: Load Balancing• HAProxy vs Amazon ELB• Custom programs to Auto Scale HAProxy• HAProxy Elastic -> Attach /...
Solution Step 4 : Web/App Servers                                                         Amazon Virtual Private CloudUser...
Solution Step 4: Web/App Servers• 3 Web/App instances under every HAProxy• C1.Xlarge Instance Type for Web/App Instances• ...
Solution Step 5 : Queue Servers                                               Amazon Virtual Private Cloud                ...
Solution Step 5: Queue Servers• RabbitMQ vs Amazon SQS• FIFO/Concurrency/No Duplicate messages• 1 RabbitMQ instance for qu...
Solution Step 6 : Processors/Redis                 Amazon                                  Single Sector View     Componen...
Solution Step 6: Redis• Redis vs Amazon DynamoDB• Redis : NoSQL KV Data store• Visitors are shown their Current Queue  pos...
Solution Step 6: Processors• BG Processors : Java Programs to  • RabbitMq -> Redis : Allot Queue numbers to visitor    req...
Overall Solution ArchitectureSector is not an AWSterm , it is 8KMiles termfor Logical EC2 instance             Amazongroup...
Scalability                                   AZ-1                Amazon Virtual Private Cloud                            ...
Scalability• New sectors containing LB, Web, Queue ,  NoSQL , BG stack will be created  automatically depending upon the l...
High Availability @ Instance level                                   AZ-1                Amazon Virtual Private Cloud     ...
High Availability @ Instance• HA built @ Web/App , Redis and BG  processor instances• Any Failure / Non responsive EC2 ins...
High Availability @ Sector level                                   AZ-1                Amazon Virtual Private Cloud       ...
High Availability @ Sector level• Any Failure / Non responsive instances inside  Sectors will be automatically  detected/r...
High Availability @ AZ Level                                   AZ-1                Amazon Virtual Private Cloud           ...
High Availability @ AZ level• If entire AZ-2 fails then load will be balanced  to instances in AZ-1• Automated programs wi...
Log Analytics                                       HDFS Cluster            1               2                  3   EC2    ...
Monitoring• Nagios + Puppet (combined) for Auto  scaled monitoring infra and deployment• CloudWatch Custom metrics / Tomca...
Backup• No backups -> only Syncs to S3• Golden AMI’s snapshot to S3• Periodic Sync of data between EC2 and S3• Periodic lo...
Infrastructure• Amazon Route53• Amazon VPC – Public , Private subnet• 150+ EC2 instances , 2 AZ’s , 1 Region• 70+ Elastic ...
Infrastructure Elasticity• Entire Infra created 2 hrs before promo• Tear down infra 2 hrs after promo• ~30 Mins to launch ...
Infrastructure Cost• ~10K USD per promo• Not inclusive of Data charges• Unthinkable Savings• Visitor experience was good• ...
If you need help in architecting Highly Elasticsolutions on AWS?
Leave it to the experts , we willhandle thisCloud Architecture ConsultingCloud Application DevelopmentCloud Migration & Im...
Q&AHarish11g.aws@gmail.comhttp://in.linkedin.com/in/harishganesanwww.twitter.com/harish11ghttp://harish11g.blogspot.comAma...
