FOSDEM'08: TOMOYO Linux for Secure Embedded FOSDEM'08: TOMOYO Linux for Secure Embedded Presentation Transcript

  • TOMOYO Linux for Secure Embedded Toshiharu Harada haradats@nttdata.co.jp NTT DATA CORPORATION February 24, 2008
  • TOMOYO Linux for Secure Embedded JFYI This slide has been under control of Subversion. The version you are viewing is $Id: tomoyo.tex 71 2008-03-07 10:06:22Z haradats $ The latest and a better version is http://sourceforge.jp/projects/tomoyo/document/fosdem2008.pdf. Visit the elinux Wiki for general information of TOMOYO Linux http://elinux.org/TomoyoLinux. 2008-2-24 FOSDEM’08 Embedded Track 1
  • TOMOYO Linux for Secure Embedded About This slide . . . was prepared for the presentation of TOMOYO Linux at the FOSDEM’08 Embedded Track. Toshiharu Harada <haradats@nttdata.co.jp> . . . is project manager of TOMOYO Linux and the author/speaker/contact person of the program. NTT DATA CORPORATION . . . is the largest SI company in Japan and has been supporting the project. http://www.nttdata.co.jp/en/index.html. 2008-2-24 FOSDEM’08 Embedded Track 2
  • TOMOYO Linux for Secure Embedded Executive Summary • TOMOYO Linux is designed and developed to be a practical security enhancements to Linux 2.4 and 2.6. • It can be used to analyze a system as well as protection. • Ubuntu based LiveCD (ISO image) is available. • There are two different versions: Version 1.x non LSM, full featured. Version 2.x LSM compliant, for mainline inclusion. • Gorgeous GUI should be available soon. 2008-2-24 FOSDEM’08 Embedded Track 3
  • TOMOYO Linux for Secure Embedded TOMOYO Linux Security Goal Quotes from the message posted to LKML (Linux Kernel Mailing List). The TOMOYO Linux’s security goal is to provide “MAC that covers practical requirements for most users and keeps usable for most administrators”. TOMOYO Linux is not a tool for security professional but for average users and administrators. Full message can be found at http://lwn.net/Articles/263179/. 2008-2-24 FOSDEM’08 Embedded Track 4
  • TOMOYO Linux for Secure Embedded What is TOMOYO Linux • TOMOYO Linux is a mandatory access control implementation to Linux 2.4 and 2.6 kernel. • TOMOYO Linux consists of set of kernel patch files and utilities. No userland modifications are needed for TOMOYO Linux. • Available packages include: RedHat Linux 9, Fedora Core 3-6, Fedora 7/8, CentOS 4.6/5.1, Debian Sarge/Etch/Lenny, OpenSUSE 10.1/10.2/10.3, Asianux 2.0/3.0, Ubuntu 6.06/6.10/7.04/7.10, Vine Linux 4.2, Gentoo 2007.0 and Turbolinux 10/11 Server. 2008-2-24 FOSDEM’08 Embedded Track 5
  • TOMOYO Linux for Secure Embedded Project Official Information • http://elinux.org/TomoyoLinux (English) • http://tomoyo.sourceforge.jp/ (English and Japanese) • http://tomoyo.sourceforge.jp/wiki-e/ (English) • http://sourceforge.jp/projects/tomoyo/ (English and Japanese) • http://tomoyo.sourceforge.jp/cgi-bin/lxr/source (the code) If you have not heard of TOMOYO Linux, elinux.org Wiki word is the best place to start. 2008-2-24 FOSDEM’08 Embedded Track 6
  • TOMOYO Linux for Secure Embedded “mandatory access control” • often called as ‘MAC’. • the opposite of ‘DAC’ (Discretionary Access Control), that was included in good and sweet old UNIX and early days Linux. • MAC was designed to compensate the shortages of DAC. MAC has been ported to most modern operating systems by now. SELinux is an implementation of the MAC to Linux. Please refer TCSEC and NSA SELinux web site for more information. 2008-2-24 FOSDEM’08 Embedded Track 7
  • TOMOYO Linux for Secure Embedded Why developing another MAC while SELinux is available? • The project members were not smart enough to use SELinux. :-) • Linux is open source. So, why not? :-) 2008-2-24 FOSDEM’08 Embedded Track 8
  • TOMOYO Linux for Secure Embedded How many MACs are there on this planet? • Already in-tree – SELinux • Just (2.6.25) in-tree – SMACK (Simplified Mandatory Access Control Kernel) • Want to be in-tree – AppArmor (formerly known as SubDomain) – TOMOYO Linux – LIDS (Linux Intrusion Detection System) 2008-2-24 FOSDEM’08 Embedded Track 9
  • TOMOYO Linux for Secure Embedded • “Our Own Way” for some reasons – RSBAC – GRESECURITY • Where to find the players? – “Linux Weather Forecast” run by the Linux Foundation might help. http://www.linux-foundation.org/en/Linux_Weather_Forecast 2008-2-24 FOSDEM’08 Embedded Track 10
  • TOMOYO Linux for Secure Embedded How do they compare? I am trying to provide a fair and helpful chart. Comments and suggestions would be appreciated. http://tomoyo.sourceforge.jp/wiki-e/?WhatIs#comparison 2008-2-24 FOSDEM’08 Embedded Track 11
  • TOMOYO Linux for Secure Embedded TOMOYO Linux General Features 1. “Policy learning mode” revolutionary enlightens the loads of policy management tasks. 2. Policy definitions of TOMOYO Linux is exceptionally human readable and understandable. 3. TOMOYO Linux can live with any file system (built on top of the VFS layer). 4. Small footprint 2008-2-24 FOSDEM’08 Embedded Track 12
  • TOMOYO Linux for Secure Embedded Key Concepts • TOMOYO Linux limits the access by the behavior of the subject while SELinux limits the access by the attributes of the subject and object. • TOMOYO Linux kernel keeps track of the process invocation history (a.k.a. system call chains). Every process remembers its parent and ancestors. – This scheme quite well suits to the Linux’s fork/exec mechanism. Process invocation history information is copied when fork() and added the new process name when execve() issued. 2008-2-24 FOSDEM’08 Embedded Track 13
  • TOMOYO Linux for Secure Embedded Terminology • TOMOYO Linux Policy is composed of per DOMAIN access control definitions. • In TOMOYO Linux, DOMAINs are automatically defined and given names by the TOMOYO Linux kernel, no operations required for the administrators side. • Access control modes for each DOMAIN is specified by a number that ranges 0. . . 255. That number is called as PROFILE id. 2008-2-24 FOSDEM’08 Embedded Track 14
  • TOMOYO Linux for Secure Embedded • Administrators need to define the meaning of each PROFILE id in /etc/ccs/profile.conf. • Administrators define the entity of each PROFILE id by choosing the desired MAC functionality. 2008-2-24 FOSDEM’08 Embedded Track 15
  • TOMOYO Linux for Secure Embedded • While SELinux has system wide global modes called “enforcing” and “permissive”, TOMOYO Linux has per domain four MODEs to administrate MAC behavior. Mode unpermitted access Log domains 0 (Disabled) granted grows 1 (Learning) granted and learned logged grows 2 (Permissive) granted logged grows 3 (Enforcing) rejected logged unchanged • Learning mode is for designing a policy. • Permissive mode is for testing the policy. 2008-2-24 FOSDEM’08 Embedded Track 16
  • TOMOYO Linux for Secure Embedded Profile definitions Syntax [Profile id(0-255)]-[Directive]=[Mode] Example 1-COMMENT=----- Profile #1 Defs ----- 1-MAC_FOR_FILE=1 1-MAC_FOR_NETWORK=1 2-COMMENT=----- Profile #2 Defs ----- 2-MAC_FOR_FILE=2 2-MAC_FOR_NETWORK=2 2008-2-24 FOSDEM’08 Embedded Track 17
  • TOMOYO Linux for Secure Embedded Profile Sample Description The following example defines profile number 35, “file access is enforced (access will be restricted) and network and signal are learned (access will not be restricted)”. Example 35-MAC_FOR_FILE=3 35-MAC_FOR_NETWORK=1 35-MAC_FOR_SIGNAL=1 2008-2-24 FOSDEM’08 Embedded Track 18
  • TOMOYO Linux for Secure Embedded TOMOYO Linux supports MAC only for files? “Hell, No!”:-) TOMOYO Linux supports MAC for networking (MAC FOR NETWORK), signals (MAC FOR SIGNAL), capabilities (MAC FOR CAPABILITY) . . . and much much more. For the meanings of each directives, please RTFM. 2008-2-24 FOSDEM’08 Embedded Track 19
  • TOMOYO Linux for Secure Embedded “Domain” of TOMOYO Linux Domain name starts from the prefix string, “<kernel>”. Names of the programs (issued execve()) will be appended sequentially with a single space character as a separator. (quite simple, huh?) <kernel> /sbin/init <kernel> /sbin/init /boo /bar <kernel> /sbin/init /foo /bar /buz 2008-2-24 FOSDEM’08 Embedded Track 20
  • TOMOYO Linux for Secure Embedded TOMOYO Linux ACL Example Captured on Ubuntu 7.10 Desktop. <kernel> /sbin/init --x /bin/dash rw- /dev/console rw- /dev/null r-- /etc/event.d/control-alt-delete r-- /etc/event.d/logd ... 2008-2-24 FOSDEM’08 Embedded Track 21
  • TOMOYO Linux for Secure Embedded Policy Configuration Files All policy configuration files are located at /etc/ccs in plain text format. Name File Domain Policy domain policy.conf System Policy system policy.conf Exception Policy exception policy.conf 2008-2-24 FOSDEM’08 Embedded Track 22
  • TOMOYO Linux for Secure Embedded Policy Editor (CUI) CUI program “editpolicy” is located at /usr/lib/ccs with other TOMOYO Linux tools. editpolicy has roles of: 1. To show the current (on memory) policy settings 2. To modify them. editpolicy understands and deals with the all three TOMOYO Linux policy configuration files. 2008-2-24 FOSDEM’08 Embedded Track 23
  • TOMOYO Linux for Secure Embedded Policy Editor (CUI) When invoked, domain policy screen will be displayed. Entering TAB key will change the screens. Screen Name Description Domain Policy Shows domain transition trees. The total number of existing domains will be displayed in the top of the screen. Move cursor control keys to choose a domain. System Policy Shows system global settings. Exception Policy Shows lists of MAC access control exceptions. 2008-2-24 FOSDEM’08 Embedded Track 24
  • TOMOYO Linux for Secure Embedded Other tools savepolicy Saves current policy settings under /etc/ccs. loadpolicy Loads policy settings to the kernel. 2008-2-24 FOSDEM’08 Embedded Track 25
  • TOMOYO Linux for Secure Embedded TOMOYO Linux LiveCD Definition TOMOYO Linux LiveCD = Ubuntu 7.10 Desktop + TOMOYO Linux kernel and tools For what? Casual, safe and free trial of TOMOYO Linux. Where can I get one? http://tomoyo.sourceforge.jp/wiki-e/?TomoyoLive 2008-2-24 FOSDEM’08 Embedded Track 26
  • TOMOYO Linux for Secure Embedded LiveCD Design Specification TOMOYO Linux LiveCD comes with predefined policy definition. domain policy.conf # cat /etc/ccs/domain_policy.conf <kernel> use_profile 1 # This means, “run the <kernel> domain with profile 1”. The definition of profile with id 1 can be found at profile.conf. Since the mode for file access (MAC FOR FILE) of profile 1 is not enforcing, domains are created as needed. 2008-2-24 FOSDEM’08 Embedded Track 27
  • TOMOYO Linux for Secure Embedded profile.conf # head /etc/ccs/profile.conf 1-MAC_FOR_FILE=1 1-MAC_FOR_NETWORK=1 1-MAC_FOR_SIGNAL=1 ... Profile 1 is defined to remember access for files, networks, signals. . . and keeps the results on memory. Thus, TOMOYO Linux LiveCD allows every access (as usual Ubuntu LiveCD) and keeps remembering them. The results depend on your environment. For instance, number of domains and each ACL for specific domains. 2008-2-24 FOSDEM’08 Embedded Track 28
  • TOMOYO Linux for Secure Embedded How to use a LiveCD 1. save and burn the ISO image. 2. set the disc to your PC. 3. BOOT IT! Or, you can define a virtual machine that reads the saved ISO image. 2008-2-24 FOSDEM’08 Embedded Track 29
  • TOMOYO Linux for Secure Embedded What can I do with TOMOYO Linux LiveCD? In addition to anything you can do with Ubuntu, • View how Ubuntu are running on your PC by browsing domain transitions and ACL information obtained from policy learning mode. • Select domains and change the behavior. For instance, selecting a shell domain and change it from policy learning mode to enforcing mode. • Exploring what will happen if you click GNOME menus. (Everything including GUI and X are monitored by TOMOYO Linux kernel) 2008-2-24 FOSDEM’08 Embedded Track 30
  • TOMOYO Linux for Secure Embedded • TOMOYO Linux LiveCD can be used to install to your PC. Here’s the instruction. 1. Boot from TOMOYO Linux LiveCD. 2. Find icon named ”Install”. 3. Click it, as usual. 4. Follow the instruction from the LiveCD. This is by far the easiest way to install TOMOYO Linux. 2008-2-24 FOSDEM’08 Embedded Track 31
  • TOMOYO Linux for Secure Embedded Policy Editor (GUI) Implemented as an Eclipse plugin. Runs on both Linux and Windows. Communicates using SSH. No server side modifications needed. Coming soon. 2008-2-24 FOSDEM’08 Embedded Track 32
  • TOMOYO Linux for Secure Embedded TOMOYO Linux for Secure Embedded 2008-2-24 FOSDEM’08 Embedded Track 33
  • TOMOYO Linux for Secure Embedded Reasons to use TOMOYO Linux with Embedded • For use with 2.4 kernel (LSM does not support 2.4) • File system independent • Userland modifications free • BusyBox support • Small footprint 2008-2-24 FOSDEM’08 Embedded Track 34
  • TOMOYO Linux for Secure Embedded Digging issues from LKML 2008-2-24 FOSDEM’08 Embedded Track 35
  • TOMOYO Linux for Secure Embedded How about labels? Pros • Label is bound to inode that we can trust, so unaffected by renames. Cons • Needs extra resource and work for labels. • Inode can be changed by operations. • Label is defined according to pathnames. :) Label has clear advantages but does not solve every cases. 2008-2-24 FOSDEM’08 Embedded Track 36
  • TOMOYO Linux for Secure Embedded Label or Pathname? That’s ridiculous. What pathname means is a “name of the place”. Pathname is not bound to the attributes of the entity. • No one can live without pathnames. • Both Label and Pathname are incomplete and needs work. • People can easily argue. 2008-2-24 FOSDEM’08 Embedded Track 37
  • TOMOYO Linux for Secure Embedded LABEL vs. PATHNAME argument Most important difference is LABEL or PATHNAME. label Assign ‘labels’ to the objects and judge access control according the label information. xattr (extended attributes) are used to store label information. SELinux and SMACK belong this. pathname Don’t use labels and live with traditional pathnames. AppArmor and TOMOYO Linux belong this. 2008-2-24 FOSDEM’08 Embedded Track 38
  • TOMOYO Linux for Secure Embedded Issues with pathname Pros • Pathnames are handy for restricting behavior of the subject. Cons • Pathnames can be easily changed by operations (mount, chroot, /etc/../etc/shadow, ln. . . ). 2008-2-24 FOSDEM’08 Embedded Track 39
  • TOMOYO Linux for Secure Embedded Summary • TOMOYO Linux is a lightweight and usable MAC implementation to Linux. • Though it was designed for servers, it also suits embedded systems very well. • TOMOYO Linux is useful for analyzing your own Linux box, so it would help embedded developers. • We are having unclear difficulties in mainlining TOMOYO Linux. We promise to continue the work. • We will be happy if you use our work, if TOMOYO Linux helps you. We will be pleased to help you. 2008-2-24 FOSDEM’08 Embedded Track 40
  • TOMOYO Linux for Secure Embedded Project History March 2003 I met Tetsuo Handa and started working at a small building called Kayaba-cho Tower. Tetsuo has wrote the first version of TOMOYO Linux and is the chief architect of the project ever since. November 2005 Made the code open (GPL2) April 2007 First proposal posting to LKML. April 2007 Embedded Linux Conference 2007, ””TOMOYO Linux: A Lightweight and Manageable Security System for PC and Embedded Linux”. Thank Tim Bird for this cool title. 2008-2-24 FOSDEM’08 Embedded Track 41
  • TOMOYO Linux for Secure Embedded June 2007 Ottawa Linux Symposium 2007, “TOMOYO Linux BoF”. November 2007 PacSec 2007, “TOMOYO Linux: A Practical Method to Understand and Protect Your Own Linux Box”. December 2007 6th proposal posting to LKML. February 2008 FOSDEM’08 presentation, “TOMOYO Linux for Secure Embedded” (U R here) Every slides and papers are stored at http://sourceforge.jp/projects/tomoyo/docman/ (choose the category and the language). 2008-2-24 FOSDEM’08 Embedded Track 42
  • TOMOYO Linux for Secure Embedded Acknowledgments Special thanks goes to. . . • Linus Torvalds for creating this wonderful world of Linux. • Donald E. Knuth for bringing the world TEX and letting us to know the joy of writing. • Bill Joy for creating “the editor”, “vi”. It’s part of myself. • Staff of SourceForge.jp (http://sourceforge.jp/) for their continuous supports and hosting. • NTT DATA CORPORATION for supporting the project. 2008-2-24 FOSDEM’08 Embedded Track 43
  • TOMOYO Linux for Secure Embedded • Jack Bauer and the staff of Twenty Four series. They taught me what the brave is. • My family for their patience and forgiveness. Also, my dog, Wish for taking me to a walk everyday and not biting me so often as before. 2008-2-24 FOSDEM’08 Embedded Track 44
  • TOMOYO Linux for Secure Embedded Thanks! We will see you at ELC2008 and OLS2008. Toshiharu Harada <haradats@nttdata.co.jp> Tetsuo Handa <penguin-kernel@i-love.sakura.ne.jp> Kentaro Takeda <takedakn@nttdata.co.jp> 2008-2-24 FOSDEM’08 Embedded Track 45
  • TOMOYO Linux for Secure Embedded 2008-2-24 FOSDEM’08 Embedded Track 46
