Yokai Versus the ElephantHadoop and the Fight Against Shape-Shifting Spam
VishwanathRamarao & Mark Risher
Yahoo! Mail

AGENDA
3
Shape-shifting spam
Antispam Origins
Hadoop Algorithms
Applications to Security
Resources for Implementers

6
http://f915fde2cf53df18.ligh
tto
pbody.com]*!}v}]along especially consecutive important dmvfu

8
1,300,925,111,156,286,160,896
(http://bit.ly/cpOyLi)

Typical attack/response profile
11
Rule change
(1/23@01:15)

MORE YOKAI - TARGETED ATTACKS
<style>mechanic CC0066 getimage 3A00 lectroniques repertoires spiel proscribing ammonoid 10110 radiobuttontelefoons Jermaine iesaporitoroshan 3026 janatatrennungpalillos toughest ncapitolecalzado 20200 Omnimedia collective saudadedizaines 205px hardener elongating InvasionofyourprivacyPersonnalftsbedingungenMontanerprozacSerpellfcardbvh capacitate 12502 courtship kiranjiutroligt transducer tyee Delhaize clueless toffee nnioZoapochino sterns 622 Verordnung carbons waterresistant assessing footerTextperrine url0 potatoes 999933 Rightmove positively thmb closer secures Amarillo suffer 314992 32599 8849 GJ initialling cockleshell JTA Justiaguardo jibes Chubb inflammatory iteration granfaldasseoir considerations 692px treasured Allotransplantationtwoyearsappx Bowers doorgeven 1487 bigpicture repeatedly Popp MPEG4 webbsidaliefdeVoeding Elena Kernighan sternway laggardly Zwischendurch commons equis sewing f17 apadrinasareiniqueslugoquotedblbayr 3500 CI addressee optativelygazzetta 616px mingus 23238 PhotoLink desuetude tofu keychains molding redevelopment stucco deltage astrology2 thumbscrews probablemente 700g rnsfuseactionrepristaires restraint manchettestrendlineseffectuedespatchMinskyestadual doses danbrown Muenster jind7n7 smashes gourmandesashantisentants rows kyk coated Incontournablescoincidenjspa stalker CDS contienen expletives s8 eof replenishing puyalluppratosondravalidarorientale sonnets steamer Niwangoacrocentric dozens elr tempting poing jails ingredi Sep3 misdirection vested tecniciconciertos dear martini 3D35 MBR DNAME 2650 violation Egyptiin NCR sposoriss hl 12450 connectors circumcision transform CFA employeur 153 comunicazioni miner 19905 citronella PlissierHellmich Randall CaradonnaspringaregistradahauptEntran 3060 Rochin capacitor sotol 3413 smirk interditeServicePoint capabilities bouncefeeLinkov 3Dg auntie OSP CaeciliaPlatzierung wrangler pisosbanlieueDaniellaenderleisraelprofessionnellessusto 39800 Espanaplena radian antic!...........................200KB……….
</style>
<center><a href="http://ivywhere.info/52210088504303.hrmj.1/285/1000/1006/1000/1237976a102c0176c7b3fb3164f83590.html">Please Click Here if You Can't See Images<br><imgsrc="http://ivywhere.info/images/usacpm1.jpg" border="0"></a><br><a href="http://ivywhere.info/52210088504303.hrmj.1/40106/1000/1000/1000/a.html"><imgsrc="http://ivywhere.info/images/usacpm2.jpg" border="0"></a><br><a href="http://ivywhere.info/gp.html"><imgsrc="http://ivywhere.info/images/please2.jpg" border="0"></a><br>
12
[400kb…]
<center><a href="http://corfair.info/52210088504303.hrmj.1/129286/1000/1006/1000/d1c7b1fa06980b08bf9b3a9c14844623.html">Please Click Here if You Can't See Images<br><imgsrc="http://corfair.info/images/ivblg1.jpg" border="0"></a><br><a href="http://corfair.info/52210088504303.hrmj.1/40126/1000/1000/1000/a.html"><imgsrc="http://corfair.info/images/ivblg2.jpg" border="0"></a><br><a href="http://corfair.info/gp.html"><imgsrc="http://corfair.info/images/please2.jpg" border="0"></a><br>

Why is the ANTISPAM PROBLEM hard
Scale of the problem; 25B Connections, 5B deliveries, 450M mailboxes
User feedback is often late, noisy and not always actionable
Large, diverse stream of legitimate traffic that looks like spam
Slow adoption of authentication technologies like DKIM and SPF
Spammers are clever; target and specialize attacks
Rapidly changing spam campaigns with a large bot controlled IP base; large variations even within a single campaign
A significant percentage of spam comes from large ESPs like Hotmail, Google and Yahoo
15

Generation 1: Manual management layer
Heuristics, blocks, blacklists
Provide attack mitigation and operational flexibility, highly explainable.
Not durable, expensive to keep pace with fast morphing spam
Ad hoc queries
Proprietary implementations, not very scalable, steep learning curve
Reactive and usually late
16

Generation 2: Machine Management Layer
Online reputation models
Simple, mostly scoring/counter/ratio based models
Highly scalable due the absence of any state/memory
Generalize too broadly, lack expressive power
Batch trained reputation models
Typically digested memory based hashing or machine learning models
Difficult to implement and due to the need for labeled examples scale well only moderately
Slow to update and learn, lack explainability, limited operational control
17

distributed computing paradigm
19
Map:Reduce + distributed storage:
Simplicity of online, stateless models
Expressiveness of offline analysis
Ease of management

the map:reduce paradigm
Input data format is application-specific, specified by the user
Output is a set of <key,value> pairs
User expresses algorithm using two functions
Map is applied on the input data and produces a list of intermediate <key,value> pairs
Reduce is applied to all intermediate pairs with the same key. It typically performs some kind of merging operation and produces zero or more output pairs
Finally, output pairs are sorted by their key value
20

the map:reduce paradigm
21
Mapper
<k1,v1>
Mapper
<k1,{v1,v3}>
<k2,v2>
Reducer
<k2,v2>
<k1,W1>
Mapper
<k1,v3>

A SIMPLE MAP:REDUCE EXAMPLE
$ bin/hadoopdfs -cat /usr/joe/wordcount/input/file01
Hello World Bye World
$ bin/hadoopdfs -cat /usr/joe/wordcount/input/file02
Hello Hadoop Goodbye Hadoop
// Split up input files (MAP), iterate over chunks, reassemble results (REDUCE)
$ bin/hadoop jar /usr/joe/wordcount.jarorg.myorg.WordCount /usr/joe/wordcount/input /usr/joe/wordcount/output
$ bin/hadoopdfs -cat /usr/joe/wordcount/output/part-00000
Bye 1
Goodbye 1
Hadoop 2
Hello 2
World 2
22

a simple map:reduce example (bit.ly/bdyi0l)
18. public void map(LongWritable key, Text value, OutputCollector<Text, IntWritable> output, Reporter reporter) throws IOException {
19. String line = value.toString();
20. StringTokenizertokenizer = new StringTokenizer(line);
21. while (tokenizer.hasMoreTokens()) {
22. word.set(tokenizer.nextToken());
23. output.collect(word, one);
24. }
25. }
23

a simple map:reduce example (bit.ly/bdyi0l)
28. public static class Reduce extends MapReduceBase implements Reducer<Text, IntWritable, Text, IntWritable> {
29. public void reduce(Text key, Iterator<IntWritable> values, OutputCollector<Text, IntWritable> output, Reporter reporter) throws IOException {
30. int sum = 0;
31. while (values.hasNext()) {
32. sum += values.next().get();
33. }
34. output.collect(key, new IntWritable(sum));
24

Applications
&
Outcomes
25

Lets REVIEW OUR DESIGN GOALs AGAIN
Classifiers are notorious for lack of explainability
Engineers and analysts needs to know what the classifier is missing
Engineers and analysts need to know about emerging threats
Analysts need “canned” reports along interesting dimensions
Machines need smart feature engineering
Develop a scalable system to provide deep insight into spammer campaigns
Double up as a platform for standard reporting
Also double up as a platform for adhoc analysis and data probing
Signal amplification and smart feature extraction platform
26

Our ANTISPAM ANALYTIC PLATFORM
Hadoop: Implements map reduce, written in Java but supports many other languages including Perl and C++ using the streaming interface
Feature engineering with small simple Perl programs for data extraction and transformation
SQL-like “Pig” programming language for data analysis and management
Mahout: data mining libraries that provide shrink- wrapped, scalable, sophisticated algorithms
Other proprietary algorithms and frameworks for specialized tasks
27

Various ASPECTS of A GRID DRIVEN SOLUTION
Standard reporting
Ad hoc querying
Campaign discovery from spam feedback using frequent item set mining
“Gaming” detection in notspam feedback using connected components
28

AD HOC queries for ANTISPAM research
Identify domains that had few spam votes in the previous time window but have a high number of spam votes today
All IPs in the last hour that sent a particular URL pattern…or that sent any unknown URL >500 times
Which domains/IPs suddenly increased their sending volume after a positive reputation change
Which FROM addresses exhibit low message size entropy
All messages that had nothing but a URL and the domain of the URL had low page rank
30

AD HOC QUERIES - Anatomy of a PIG QUERY
--- This includes some basic string functions, including splitting a string on the '@' character
register /homes/jpujara/pig_scripts/string.jar;
define splitEmail string.Tokenize('2','@');
--- Load up some data - incoming messages at a date and time, and our trusted user database
MESSAGES = load '/projects/antispam/mta_feature_logs/$date*/*/*-$time*' using com.yahoo.ymail.pigfunctions.AsStorage('__record_key__,firstrcpt,mailfrom') as (mid:chararray,to:chararray,from:chararray);
USERS = load '/projects/antispam/TrustedUser.bz2' using com.yahoo.ymail.pigfunctions.AsStorage('user,t') as (user:chararray,trusted:int);
--- Split the e-mail addresses into user+domain and generate the appropriate user-id for yahoo users and partners
EXPLODED_MESSAGES = FOREACH MESSAGES GENERATE to,FLATTEN(splitEmail(to)) as (user,udomain),FLATTEN(splitEmail(from)) as (sender,sdomain);
YAHOO_MESSAGES = FOREACH EXPLODED_MESSAGES GENERATE (udomain MATCHES '.*yahoo.*' ? user : to ) as yuser,sdomain;
31
--- Combine the message and sender domains with the trusted user data and select only trusted messages
YAHOO_MESSAGES_TRUST = JOIN YAHOO_MESSAGES by yuser, USERS by user;
TRUSTED_MESSAGES = FILTER YAHOO_MESSAGES_TRUST by trusted > 0;
--- Group by domain, and generate a count, order by descending count
DOMAIN_GROUPS = GROUP TRUSTED_MESSAGES by sdomain;
DOMAIN_GROUPS_COUNT = FOREACH DOMAIN_GROUPS GENERATE group,COUNT(TRUSTED_MESSAGES) as count;
DOMAIN_GROUPS_ORDER = ORDER DOMAIN_GROUPS_COUNT by count DESC;
--- Output the results
STORE DOMAIN_GROUPS_ORDER into '$targetdir/topDomains';

CAMPAIGN Discovery in SPAM Feedback
Frequent Itemset Mining
Classical method
Research interesting relationships between variables in a large database
Primarily applied for market basket analysis
Many good implementations
APRIORI
Easy to implement
Parallelizes moderately well but bottlenecks for extremely large data sets
Not very efficient with the number scans
ECLAT
Parallelizes easily
Amenable to a good grid implementation
Fewer scans of the dataset
Parallel FP GROWTH
Designed explicitly for systems like hadoop
Implemented in Mahout 0.2
32

Frequent item set – example dataset
33

Frequent ITEMSET MINING
34
Slide Courtsey: dortmund.de

Frequent itemset MINING on ONE DAY’s SPAM REPORTS
9 2595 (IPTYPE:none,FROMUSER:sales,SUBJ:It's Important You Know,FROMDOM:dappercom.info,URL:dappercom.info,ip_D:66.206.14.77,)
9 2457 (IPTYPE:none,FROMUSER:sales,SUBJ:Save On Costly Repairs,FROMDOM:aftermoon.info,URL:aftermoon.info,ip_D:66.206.14.78,)
9 2447 (IPTYPE:none,FROMUSER:sales,SUBJ:Car-Dealers-Compete-On-New-Vehicles,FROMDOM:sherge.info,URL:sherge.info,ip_D:66.206.25.227,)
9 2432 (IPTYPE:none,FROMUSER:sales,SUBJ:January 18th: CreditReport Update,FROMDOM:zaninte.info,URL:zaninte.info,ip_D:66.206.25.227,)
9 2376 (IPTYPE:none,FROMUSER:health,SUBJ:Finally. Coverage for the whole family,FROMDOM:fiatchimera.com,URL:articulatedispirit.com,ip_D:216.218.201.149,)
9 2184 (IPTYPE:none,FROMUSER:health,SUBJ:Finally. Coverage for the whole family,FROMDOM:fiatchimera.com,URL:stratagemnepheligenous.com,ip_D:216.218.201.149,)
9 1990 (IPTYPE:none,FROMUSER:sales,SUBJ:Closeout 2008-2009-2010 New Cars,FROMDOM:sastlg.info,URL:sastlg.info,ip_D:66.206.25.227,)
9 1899 (IPTYPE:none,FROMUSER:sales,FROMDOM:brunhil.info,SUBJ:700-CreditScore-What-Is-Yours?,URL:brunhil.info,ip_D:66.206.25.227,)
9 1743 (IPTYPE:none,FROMUSER:sales,SUBJ:Now exercise can be fun,FROMDOM:accordpac.info,URL:accordpac.info,ip_D:66.206.14.78,)
9 1706 (IPTYPE:none,FROMUSER:sales,SUBJ:Closeout 2008-2009-2010 New Cars,FROMDOM:rionel.info,URL:rionel.info,ip_D:66.206.25.227,)
9 1693 (IPTYPE:none,FROMUSER:sales,SUBJ:January 18th: CreditReport Update,FROMDOM:astroom.info,URL:astroom.info,ip_D:66.206.25.227,)
9 1689 (IPTYPE:none,FROMUSER:sales,SUBJ:eBay: Work@Home w/Solid-Income-Strategies,FROMDOM:stamine.info,URL:stamine.info,ip_D:66.165.232.203,)
35
2432 (IPTYPE:none,FROMUSER:sales,SUBJ:January 18th: CreditReportUpdate,FROMDOM:zaninte.info,URL:zaninte.info, ip_D:66.206.25.227,)
2447 (IPTYPE:none,FROMUSER:sales,SUBJ:Car-Dealers-Compete-On-New-Vehicles,FROMDOM:sherge.info,URL:sherge.info,
ip_D:66.206.25.227,)

Gaming DETECTION in NOTSPAM FEEDBACK
Spammers instrument accounts to vote “not spam” on emails that they send
Delays classification of spamming IP addresses
Throws off the classifiers if the feedback is not filtered well
Model the problem as a bipartite graph
Well known model for matching algorithms
Broadly applied in various fields like coding theory
A graph whose vertices are disjoint form disjoint sets U,V
There is an edge connecting every U to a vertex in V
36

Connected COMPONETS - EXPLAINED
Y1 = Yahoo user 1, Y2 = Yahoo user 2
IP1 = IP address of the host Y1 “voted” notspam from
37
y1
IP1
y1
SQUARING
weight = 2
y1
IP2
y1

Connected COMPONENTS for “GAMING” DETECTION
38
Set of IPs/YIDs used
exclusively for
voting notspam
Set of (likely new)
spamming IPs which
are “worth” voting for
y1
IP3
IP1
y2
IP4
IP2
y3
Set of
“voted on” IPs
Set of
“voted from” IPs
Set of Yahoo IDs
voting notspam

Connected Components - RESULTS
39
- Connnected components for IPsnotspam was voted from

Connected components - results
40
- Connnected components for IPsnotspam was voted on

CONCLUSIONS
We have had success leveraging parallel, stateful algorithms on grid systems to keep pace with polymorphic spam that evade traditional analysis and algorithms
Frequent Itemset Mining rapidly identifies cohesive campaigns in ISSPAM feedback
Connected Components amplifies weak signals in gamed NOTSPAM feedback and helps separate signal from noise in the feedback
Grid system based analysis platforms may be broadly applicable across the security domain
41

Apply Slide
Download Hadoop distribution
http://hadoop.apache.org
Try out Pig on standalone, single Linux box
Identify source data to aggregate
Start simple: IP patterns across web access logs
Begin with offline aggregation; yesterday’s attacks still interesting
Read Connected Components and Frequent Itemset Mining papers
Stop looking for a single, invariant “tell” – far too costly
Start thinking about co-occurrence of innocuous features
42

Resources for implementers
Hadoop setup, documentation and resources
http://hadoop.apache.org/
Pig documentation and resources
http://hadoop.apache.org/pig/
Mahout documentation and resources
http://lucene.apache.org/mahout/
Frequent itemset mining implementation repository
http://fimi.cs.helsinki.fi/src/
Connected components description
[link not yet live]
Ranger, Raghuraman, Penmetsa, Bradski, and Kozyrakis. Evaluating MapReduce for Multi-core and Multiprocessor Systems. In HPCA 2007
43

Connected COMPONENTS
45
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday
Reg IP
Cookie
Username
Birthday

http://developer.yahoo.net	602
http://www.readwriteweb.com	299
http://developer.yahoo.com	158
http://www.slideshare.net	156
http://readwriteweb.com.br	106
http://www.hadoopsphere.com	97
http://linkhay.com	35
http://webholic.com.br	34
http://feeds.feedburner.com	23
http://static.slidesharecdn.com	10
http://readwrite.com	9
https://developer.yahoo.com	3
https://readitlaterlist.com	1
http://www.hanrss.com	1
http://74.125.95.132	1
http://2868824907842590784_18d887540e821527539eb43f8f9aa97f67770712.blogspot.com	1
http://rss2.com	1
http://busk.com	1
http://webcache.googleusercontent.com	1
http://eberbach.pl	1
http://www.cnliam.com	1
http://www.abhinavnews.info	1

Yahoo! Mail antispam - Bay area Hadoop user group

by Hadoop User Group on Apr 21, 2010

Accessibility

Categories

Upload Details

Usage Rights

22 Embeds 1,542

Statistics

Yahoo! Mail antispam - Bay area Hadoop user group Presentation Transcript
