HES2011 - joernchen - Ruby on Rails from a Code Auditor Perspective

Ruby on Rails from a code auditors perspective 0x0b4dc0de the RoR way 9th April 2011 Hackito Ergo Sum

Meta / Disclaimer● Its an attempt to share my experience in reading Ruby on Rails code with the aim to find nice¹ bugs● You can expect some code and practical examples from ● Redmine – Open Source project management software ● CCCMS – http://ccc.de● Im not a coder ● Rather, I enjoy reading other peoples code – So dont expect a RoR development tutorial ¹) as in: security

RoR – WTF?● Ruby on Rails ● Blah² from the website: – “Ruby on Rails © is an open-source web framework thats optimized for programmer happiness and sustainable productivity. It lets you write beautiful code by favoring convention over configuration.” ● Current version: 3.0.5 ● Model-View-Controller based webapp framework written in Ruby

MVC● Model-View-Controller: a software architecture pattern isolating different domains of the software into three parts ● Model: handling data of the application as well as state changes ● View: user interface elements ● Controller: I/O, application logic calling methods of the model and view

RoR – Controller● Located in $railsapp/app/controllersclass PostsController < ActionController::Base[…]1 def show 2 @post = Post.find(params[:id]) 3 respond_to do |format| 4 format.html # show.html.erb 5 format.xml { render :xml => @post } 6 end 7 end […]

RoR – Model● Located in $railsapp/app/models 1 class User < ActiveRecord::Base 2 has_many :posts 3 verifies_presence_of :name 4 verifies_uniqueness_of :name 5 end

RoR – View● Located in $railsapp/app/views● Typically written in ERB ● Mixture of HTML and Ruby01 <% if @posts.blank? %>02 <p>There are no posts yet.</p>03 <% else %>04 <ul id="posts">05 <% @posts.each do |c| %>06 <li><%= link_to c.title, {:action => show, :id => c.id} =%></li>07 <% end %>08 </ul>09 <% end %>10 <p><%= link_to "Add new Post", {:action => new }%></p>

Looks shiny, huh?

Reading the code and (ab)using the webapp

RoR – Reading the Code● Ruby tends to be easy to read, so does RoR● There are at least three layers (MVC) ● All layers have to be covered when reading the source code (for finding bugs) ● Additionally, theres libs, helpers, etc. ● There might be checks somewhere you dont expect ● There might be bugs somewhere you dont expect

RoR – Database● Database is configured in ● $railsapp/config/database.yml● Migrations are used to describe the database tables (in Ruby) ● These are then deployed on the database using rake

RoR – Migrations● Example taken from Redmine ● db/migrate/001_setup.rb create_table "users", :force => true do |t| t.column "login", :string, :limit => 30, :default => "", :null => false t.column "hashed_password", :string, :limit => 40, :default => "", :null => false t.column "firstname", :string, :limit => 30, :default => "", :null => false t.column "lastname", :string, :limit => 30, :default => "", :null => false t.column "mail", :string, :limit => 60, :default => "", :null => false t.column "mail_notification", :boolean, :default => true, :null => false t.column "admin", :boolean, :default => false, :null => false […]

RoR - Filters● Filter example taken from Redmine ● app/controllers/issues_controller.rb 1 class UsersController < ApplicationController 2 layout admin 3 4 before_filter :require_admin, :except => :show

RoR – Filters● So mainly, there are ● before_filter ● after_filter ● skip_before_filter ● skip_after_filter ● around_filter

RoR – User Input● Look for params[:something] in the controller ● Take a look at the model/migration/DB to know which fields you might potentially influence ● Post it like: something=foo ● params[:something][:bar] is posted like something[bar]=foo

RoR – User Input● RoR also takes automagically user input as ● XML – Post with Content-Type text/xml: <user> <firstname>chunky</firstname> </user> ● JSON – Post with Content-Type application/json: { User:{ lastname:bacon } }

Good old friends

The Usual Web Application Suspects● SQL Injection● XSS● CSRF

SQL Injection the RoR way● Rarely found ● Per se, RoR hides away plain SQL – User.where(:first_name => “Chunky”, :last_name => “Bacon”)● Look for the typical concatenation patterns 1 def sqlinjectme 2 User.find(:all, :conditions => "id = #{params[:id]}") 3 end● Unfortunately stacked queries do not work

XSS the RoR way● In order to find XSS bugs ● Look at the views – <%= @post.title %> vs. – <%= h @post.title %> ● Look at formatters ● Just try to find XSS scripted/manually

Redmine persistent XSS● Somewhat hard to spot ● Found it by chance ;)● Problem in the syntax highlighter: ● lib/redcloth3.rb

Redmine persistent XSS1 htmlesc( aftertag, :NoQuotes ) if aftertag && escape_aftertag && ! first.match(/<codes+class="(w+)">/)2 line = "<redpre##{ @pre_list.length }>"3 first.match(/<#{ OFFTAGS }([^>]*)>/)4 tag = $15 $2.to_s.match(/(class=S+)/i)6 tag << " #{$1}" if $17 @pre_list << "<#{ tag }>#{ aftertag }"

CSRF● There is some RoR magic to protect_from_forgery: 1 class FooController < ApplicationController 2 protect_from_forgery :except => :index

To be a bit more specific

Bugs the RoR way● Rails has a lot of fancy automagic ● … which might eventually blow up in your face ● “Most of you are familiar with the virtues of a programmer. There are three, of course: laziness, impatience, and hubris.” – Larry Wall

Automagic – Mass Assignments● When there is an assignment like ● user[name] = “Chunky Bacon”● This is typically saved with ● 1 user = @params[:user] ● 2 user.save

Automagic – Mass Assignments● When there is an assignment like ● user[name] = “Chunky Bacon”● This is typically saved with ● 1 user = @params[:user] ● 2 user.save● So what if you posted ● user[name]= “Chunky Bacon” ● user[admin]= true

Mass Assignment – CCC Website● CCCMS – “feature” allowing regular users promoting themselves to admin 1 def update 2 3 if @user.update_attributes(params[:user]) […]

Mass Assignment – CCC Website● CCCMS – patch preventing regular users promoting themselves to admin 1 def update 2 params[:user].delete(:admin) unless current_user.is_admin? 3 if @user.update_attributes(params[:user]) […]

Preventing Mass Assignments● To be fixed in the model● Example taken from Redmine: 1 class User < Principal […] 2 attr_protected :login, :admin, […]

Laziness – Infoleaks● All those fanciness of RoR doesnt help against lazy developers● If youre having a second controller accessing a model, you have to implement proper filters as well

Redmine – Journals Infoleak● Leaks info about issue descriptions, even if they are not visible to the current user● app/controllers/journals_controller.rb 1 class JournalsController < ApplicationController 2 before_filter :find_journal, :only => [:edit] 3 before_filter :find_issue, :only => [:new] 4 before_filter :find_optional_project, :only => [:index] 5 […]

Redmine – Journals Infoleak● Leaks info about issue descriptions, even if they are not visible to the current user● app/controllers/journals_controller.rb 1 class JournalsController < ApplicationController 2 before_filter :find_journal, :only => [:edit] 3 before_filter :find_issue, :only => [:new] 4 before_filter :find_optional_project, :only => [:index] 5 before_filter :authorize, :only => [:new, :edit] […]

Digging a bit deeper

Digging a bit deeper● There is more than just the MVC code ● $railsapp/lib/ ● $railsapp/vendor/plugins ● $railsapp/app/helpers● There is RoR code itself

Redmine – SCM Adapters● app/controllers/repositories_controller.rb 1 before_filter :find_repository, :except => :edit […] 2 def diff 3 if params[:format] == diff 4 @diff = @repository.diff(@path, @rev, @rev_to) […] 5 def find_repository […] 6 @rev = params[:rev].blank? ? @repository.default_branch : params[:rev].strip

Redmine – SCM Adapters● lib/redmine/scm/adapters/bazaar_adapter.rb 1 def diff(path, identifier_from, identifier_to=nil) 2 path ||= 3 if identifier_to 4 identifier_to = identifier_to.to_i 5 else 6 identifier_to = identifier_from.to_i 1 7 end 8 cmd = "#{BZR_BIN} diff r#{identifier_to}..#{identifier_from} #{target(path)}"

Redmine – Command Execution● http://redminehost/projects/ $project/repository/diff/?rev=`cmd`

XXX¹● Open Source Rails app● Developed by xxx.com● Was suspicious to me due to heavily using send statements on user input● send(symbol, [args...]) ● Invokes the method identified by symbol, passing it any arguments specified. ● Allows private methods to be called ¹) sorry had to censor this

send, my new best friend● In XXXs controllers I didnt find anything directly exploitable :-(● But then a search helper lib got my attention:● some/lib/path/search.rb: 01 values.each do |condition, value| 02 mass_conditions[condition.to_sym] = value 03 value.delete_if { |v| ignore_value?(v) } if value.is_a?(Array) 04 next if ignore_value?(value) 05 @current_scope = @current_scope.send(condition, value)

send, my new best friend● How about: GET /triggerpath?search[instance_eval]= %60touch%20%2ftmp%2fcommand_exec%60 HTTP/1.1● Or just msfupdate in a couple of days ;-)

Rails itself● Of course, there is the RoR code itself● Didnt look into it deeply enough (yet)

Security Mechanisms – CSRF Tokens● Short recap: ● protect_from_forgery● But wait a minute ● Thumbs up to Felix Gröbert (Google Sec. Team) – CVE-2011-0447 – Fixed in Rails 3.0.4

Security Mechanisms – CSRF Tokens● actionpack/lib/action_controller/metal/request_forgery_protectio n.rb 1 def verified_request? 2 !protect_against_forgery? ||request.forgery_whitelisted? || 3 form_authenticity_token == params[request_forgery_protection_token] 4 end● actionpack/lib/action_dispatch/http/request.rb 5 def forgery_whitelisted? 6 get? || xhr? || content_mime_type.nil? || !content_mime_type.verify_request? 7 end

Security Mechanisms – CSRF Tokens● actionpack/lib/action_dispatch/http/mime_type.rb 1 def verify_request? 2 @@browser_generated_types.include?(to_sym) 3 end● With 4 @@browser_generated_types = Set.new [:html, :url_encoded_form,:multipart_form, :text]

RoR Generic CSRF Protection Bypass

RoR Generic CSRF Protection Bypass● Post to yoursite.com with flash¹● Let yoursite.com redirect via 307 to target.com● Supply application/json with proper json params● authenticity_token should also be present (arbitrary string)● Resend popup in Firefox ¹) Cross-domain POST header manipulation details: http://bit.ly/hc65g3

Session Cookies● Session cookie holds all session information ● Accessed like: session[:user_id] ● _twitter_sess=$base64blob$sha1hmac

Session Cookies● Can be loaded after base64 decoding with● Marshal.load token● => {:logged_in_after_phx_default=>false, :created_at=>1293669570258, :in_new_user_flow=>nil, :show_help_link=>nil, :user=>19395266, :password_token=>"censored", "show_discoverability_for_joernchen"=>nil, "flash"=>{}, :id=>"censored", :csrf_id=>"censored"}

Some Thoughts on Session Cookies● Looked at the RoR handling of Session Cookies → looked fine to me ● Maybe you find something I missed● But keep in mind: ● What has been HMACed cant be un-HMACed

What has been HMACed● A fictional example of some RoR controller: 01 def grant_token # called only once for a user 02 session[:token] = true 03 end 04 def invalidate # called in do_the_magic 05 session[:token] = false 06 end 07 def check # check if user has used token 08 if session[:token] == true 09 do_the_magic 10 else 11 do_not_do the magic 12 end 13 end

What has been HMACed● The before made example is vulnerable to simple replay attacks● Once you have a HMACed session cookie with special capabilities in a naïve implementation noone stops you from reusing that cookie.● Simple experiment: ● Go to twitter.com and login (without “Remember Me”). ● Save your _twitter_sess cookie ● Logout ● Restore the _twitter_sess cookie ● Be logged in again :-)

Kudos to Jean-Philippe Lang● Initial notification of ● Infoleak issue ● Persistent XSS ● Multiple CMD-Exec bugs ● ~ 2:00 PM● Respone “Ill fix it and let you know” ● ~ 6:00 PM● Response “Its fixed and there will be a new release tomorrow” ● ~ 8:00 PM● 2h for a complete fix.● So in case you use Redmine ● Update at least to version 1.0.5 =)

Thanks for Listening Any Questions?

Cheers● astera <3 ● all @● xilef ●● opti ● Recurity Labs ● Zynamics (RIP ;-))● til ● Das Labor● tina ● Timecoderz ● Dangerous Drums ● HES-Orga
