Meetup Performance
Greg Whalin, CTO Meetup (@gwhalin), Justin Cataldo, Lead UI Engineer (@jcataldo), Will Howard, Lead UI ...
Meetup

Platform for local groups

Mission is MEME (Meetup Everywhere About Most Everything)

~6.2m members
~70k Groups
~5...
General Architecture and Back-
      end Performance
     (just a tiny bit - this could and
     should be another present...
Data
MySQL (any RDBMs store) biggest pain
   replication
   use InnoDB!
   smart indexing (take advantage of clustered ind...
Storage


  Over half a million photos uploaded to Meetup every month

  Scaled and processed into 4 different sizes (plus...
Storage solutions
  Options for growth include NAS, SAN, or something else

  NAS and SAN are single point of failure and ...
MogileFS
 developed by Brand Fitzpatrick (i.e. Memcached)
 OSS distributed filesystem (built in Perl)
 any hard drive on n...
Much much much more going on

       but...
UI Performance
(much of our focus here)
Why does performance matter?
Why does performance matter?

             Slow site
Why does performance matter?

              Slow site

         Bad User Experience
Why does performance matter?

              Slow site

         Bad User Experience

           Drop in Member
           ...
Why focus on front end performance?

  Back end only accounts for 10-15% of the response time
  Less time and resources
  ...
Case Study: Event Details
Event Details:
 Load Time

  Load time = 6.321s




www.webpagetest.org
Event Details: Requests




        Lots of javascript being loaded
How do we improve
  performance?
3 Steps to improving performance

1. Externalize script
2. Move scripts to the bottom of the page
3. Reduce requests
3 Steps to improving performance

1. Externalize script
2. Move scripts to the bottom of the page
3. Reduce requests
Why externalize scripts

  Prevents blocking
     Inline scripts prevent asynchronous downloads
     Downloads must wait f...
Pull out inline script



<script type="text/javascript">




                                                >
if(typeof ...
3 Steps to improving performance

1. Externalize script
2. Move scripts to the bottom of the page
3. Reduce requests
Web:script
    Custom tag built in house
    Moves inline and external script to the bottom of the page
    Allows UI engi...
3 Steps to improving performance

1. Externalize script
2. Move scripts to the bottom of the page
3. Reduce requests
Reduce Requests

 Concatenate as much as possible
 Load only what we need upfront
Concatenation using Sprockets

 Sprockets (www.getsprockets.com)
 Created by 37Signals
 Ruby library that preprocesses and...
Concatenation using Sprockets (cont.)



EventDetails.js
CommentDeleteConfirm.js
BubbleTips.js
PlacesManager.js
MaxCharact...
Using Sprockets
/******* Sprockets Directives *******/

//= require <CommentDeleteConfirm>
//= require <DomDeco/BubbleTips...
Lazy Loading

 Defer loading of javascript files until they are needed
 Reduces the initial upfront requests
 Helps reduce...
Lazy Loading: How it works
Inserts scripts into the head dynamically
 var scriptNode = function(src) {
   return createDOM...
Did it make a difference?
Reduced requests




       Javascript requests cut by 50%
Event Details
Page Load After
Old Load Time = 6.321s
New Load time = 4.643s
Event Details
Page Load After
Old Load Time = 6.321s
New Load time = 4.643s




   Load time
  decreased by
      27%!
But that's not all
Execute early




       Execute when the dom is ready
Execute early: DOMReady
Libraries that have a DOM ready solution:
   jQuery
   YUI
   Prototype
   Pretty much every moder...
Execute early: DOMReady
And by rolled our own, I mean we're using the Dean
Edwards/Matthias Miller/John Resig implementati...
Execute early: Even earlier

Do you need to wait for the DOM to be ready?

If you aren't manipulating the DOM, there's no ...
Automated Image Optimization
Using smush.it
http://developer.yahoo.com/yslow/smushit/



Smusher Ruby gem
http://github.co...
Event Delegation

Run less JavaScript up front
Event Delegation

But first, a little bit about event bubbling...




  From: http://www.quirksmode.org/js/events_order.ht...
Event Delegation
Pros                             Cons
                                      Does not work well with neste...
Event Delegation: Meetup.Dispatcher
 <div id="C_page">
   ...

    <span class="meetup-topic"><a class="topic-id-7029 topi...
Event Delegation: Meetup.Dispatcher
Event Delegation: Meetup.Dispatcher
 <div id="C_page">
   ...

    <span class="meetup-topic"><a class="topic-id-7029 topi...
Speeding up DOM crawling with Sizzle



                         sizzlejs.com

  Internet Explorer 7

  MochiKit: 6623.94m...
Where do we go from here?

 More concatenation and lazy loading where it makes sense
 Defer image loading where it makes s...
Deployment and Serving
   As it pertains to css/html/js
Launches

Launch multiple times a day (sometimes)

Need launches to be quick / no downtime

Optimize static resources only...
Deployment of static content

Sprockets (reduce requests)

YUICompressor for js (local mod to speed up optimizing
multiple...
Link generation
   Custom JSTL page function
   http vs https
   domain sharding and cookie free domain
   content version...
Versioning static content
     MD5 checksum of contents of file
     Run w/ each launch
     Store versions in db tied to ...
Static content serving
    Served off CDN (reverse proxy)
    Anycast DNS for hostname resolution
    Origin servers runni...
Questions?
Also, we need help! Hiring for:

   Linux Systems Administrator
   Software Engineers
   UI Engineers
   QA Eng...
