Best Practices for the testing of SOA-based systems – with examples of Oracle SOA Suite 11g DOAG conference 2009 Guido Schmutz, Technology Manager / Partner Trivadis AG 18.11.2009, Nürnberg

Introduction
Guido Schmutz
Working for Trivadis for more than 12 years
Oracle Ace Director for Fusion Middleware and SOA
Co-Author of different books
Consultant, Trainer Software Architect for Java, Oracle, SOA and EDA
Member of Trivadis Architecture Board
Trivadis Technology Manager
More than 20 years of software development experience
Contact: guido.schmutz@trivadis.com
Best Practices for the testing of SOA-based systems

About Trivadis
Swiss IT consulting company
13 locations in Switzerland, Germany and Austria
~ 540 employees
Key figures 2008
Services for more than 650 clients in over 1‘600 projects
Over 150 service level agreements
More than 5‘000 training participants
Research and development budget: CHF 6.0 Mio. / EUR 3.6 Mio.

Agenda
Introduction
Scenario with SOA Suite 11g as an example
Unit Testing of SOA Suite 11g components
Integration Testing of SOA Suite 11g composites
Summary
Best Practices for the testing of SOA-based systems Data are always part of the game.

Testing of SOA solutions
For testing N-tier solutions some common best practices have been established
Unit and Integration Tests
Test Driven Development / Test-First Approach
Mock Objects
A lot of these approaches can be used/adapted for testing SOA solutions as well
Testing a SOA solution is as important
Often enterprise wide systems (backbone of an enterpirse)
Many different users
Each single error can have a huge impact
Even if in a SOA a lot of existing functionality is used, it’s not enough to just test these
SOA adds some additional logic via Router, Filter, Orchestration, which has to be tested as well

Challenges for testing a SOA solution
SOA environments are inherently heterogeneous
SOA solutions typically integrate a set of packaged or custom applications
It may not be possible to re-create a dedicated testing environment for all the systems involved
Tests are usually carried out in a synchronous way, SOA often works asynchronously!
Business processes often depend on timed events
Minimal unit of test in a SOA tends to be larger and more data driven than in traditional applications
Testing tools for SOA solutions are not yet readily

Automatic Testing
Relies on automatic, programmatic execution of the different test scenarios
The results can be verified against expected results
Efficient development and execution of test cases can only be achieved with the help of Testing Frameworks
A Testing Framework provides some common, reusable components, which supports the creation and execution of test cases as well as the verification of test results.

Functionalities of a Test Framework
Generator
Produces the test data and with it calls the components under test
Verifier/Asserter
Compares the actual test results with the expected results
It’s important that a Verifier/Asserter makes an accurate, binary decision whether a test was successful or not
Mock/Stub
Testing component that simulates part of the system that is not under test

Unit / Component Testing
Focuses on a specific component in the system
Outside dependencies must be isolated as much as possible to assure that the component can be tested in isolation
Easier to achieve with low-level component, which have none or almost no dependencies
Integration issues between components may not be discovered
Ensures that when integration begins we can have confidence in the functionality of each component being integrated

Integration Testing
Focuses on the interaction between multiple components
Focuses on the lower layers first
Because they have the least external dependencies
If an integration test fails in the upper layers, its unlikely that the reason is a faulty lower layer component since these components have already been tested
Also referred to as Bottom-Up Testing

Agenda
Introduction
Summary

Sample scenario Request Generate ID Read customer info Validate credit card Internally Externally Best Practices for the testing of SOA-based systems

Implementation with SOA Suite 11g
SCA composite once for the process with the connection to the customer system and once for the credit card validation
First SCA composite is called from the second
Credit card validation implemented as Mediator service
Decides which credit card institute to be called
Business Process implemented through BPEL component

Agenda
Introduction
Summary

Unit testing of a Mediator 11g component
In order to be able to test a Mediator component isolated (as a unit) there must be a way to simulate the two service references (Visa and Amexco)
This way it can be tested, that the Routing and Transformation logic in the Mediator works correctly
This can be achieved with the SOA Suite Unit Testing Framework
Services can be simulated
Results can be verified

Unit testing of a Mediator 11g component
Oracle SOA Suite 11g provides a testing framework with the following features
Definition of tests, assertions and emulations via JDeveloper
Starting Tests from the EM console or via the command line using ANT
Test Reports via EM console or via JUnit report
A test case contains
Initiation
Defines the services and operations, which will be called with test data
Emulation
Defined the message or error, which will be returned from a reference or a component
Assertion
Compares the message or part of the message against expected data

Initial message, will be sent to the generator component ( Generator ) Given answer for the Visa service, without calling the real service ( Mock ) Answer will be tested against the expected message ( Verifier ) Best Practices for the testing of SOA-based systems

Unit testing of a 11g BPEL component
CustomerMediator will be called, but the database access (via DB-Adapter) will only be simulated
Answer of CreditCardService will only be simulated
Allocation of the booking ID will only be simulated
Fixed and deterministic values are always returned
Important to be able to test the answer with an Asserter (Verifier) against an expected message

Deployment of test cases
Test cases will be deployed with the normal deployment of an SCA composite
Unit tests can be executed via Enterprise Manager (EM) console

Agenda
Introduction
Summary

Integration Testing of SOA solutions
After the isolated testing of each single component, we can be sure, that these work correctly by itself
Now we also want to test them integrated
Each single components are deployed together against the testing environment and connected with the corresponding test versions of the external services
What should we do, if there is no test version available of a given service?
What should we do, if the service is not available at all?

Integration Testing of SOA solutions
How can the behavior of an external service can be influenced?
So that all the different possibilities can be tested
To be able to test the behavior of a SOA solution in an error case, the error situation has to actually happen
How does somebody bring an (external) service to produce an error at the right moment?
The soluiton is again a Mock Service, which takes over the place of the external services

But how to I get these Mock Services?
How should we implement Mock Services?
The previously shown Unit Testing Framework of SOA Suite 11g is not available in the integration environment
Should we start implementing the Mock Services as own web services with the language of our choice, in such a was, that they can achieve the requirements mentioned before?
One advantage of SOA is the standardized description of the interfaces through the WSDL
There are more and more utilities/tools, which uses such a WSDL as the starting point to simplify some of the tasks within a SOA solution

soapUI
Utility for the testing of a SOA
Available in a free version
Supports the Testing of SOAP as well as REST webservices
Covers these functionalities:
Inspection and call of web services
Functional testing of web services
Load testing of web services
Creation of Webservice-Dummies (Mock Services)
http://www.soapui.org/ Best Practices for the testing of SOA-based systems

Mock Service for the Visa Service Best Practices for the testing of SOA-based systems

Testing a Webservice with soapUI Best Practices for the testing of SOA-based systems

Agenda
Introduction
Summary

Summary
Best Practices for testing conventional applications are valid for SOA solutions as well
Unit Testing of SCA components is well supported via the SOA Suite 11g testing framework
Not complete yet, but already quite usable
Integration Testing can be implemented with soapUI, a well-known utility available in a free version
calling a SOA Suite Services
Creating a Mock Service for an external service
soapUI is much more powerful than shown here
All the Tests shown can be automated

Thank you! DOAG conference 2009 Guido Schmutz, Technology Manager / Partner Trivadis AG 18.11.2009, Nürnberg
