Scalability and Reliability in the Cloud Scalability and Reliability in the Cloud Presentation Transcript

  • About This Session Target audience is backend application developers deploying infrastructure into a cloud environment Will cover concepts for scalability and reliability with the goal of helping application developers understand some key considerations when designing and building the backend.
  • Design Time Decisions When first building your application backend, consider a few important questions  How fast should the application be recovered if a failure occurs?  What kind of down time is acceptable?  Is the application maintaining stateful data?  What kind of information needs to be shared across multiple instances?
  • Scalability
  • What is Scalability? Scalability is a term used to describe how the application will handle increased loads of traffic volume
  • Scalability – Factors to Consider Horizontal vs. Vertical Stateless vs. Stateful Understanding Limitations Connection Management Segmentation of traffic Segmentation of responsibility (distributed arch) Clustering Messaging
  • What Type of Scalability?Vertical vs. HorizontalVertical Horizontal Scaling up a single  Scaling out across node multiple nodes  Physical limitations –  Ability to distribute instances are very powerful but still have traffic over a number finite limits of nodes  Resources such as  Allows for more number of sockets flexibility over time can only go so high
  • Will the App Maintain State?Stateless Applications Application does not persist information about transactions Request Respons e Each transaction is independent and Application atomic
  • Will the App Maintain State?Stateful Applications Application needs to maintain data about transactions in First Subseque progress Request nt Request Requires storage D Application B Persistence may also be required depending the
  • Understanding Limitations Thorough testing is key to understanding bottlenecks Test real-world scenarios included latency Push the system to the max to understand how it
  • Connection ManagementMobile Device Connections Mobile devices don’t always behave like you expect  Connectivity is often very dynamic  Devices move from 4G/3G/2G/no G/Wifi  Not all TCP events will get reported and sockets can remain open If not handled correctly, these factors can be time bomb no matter how vertically you scale a component
  • Segmenting Traffic Once the application is able to be scaled out, traffic can be segmented in different ways  Location (i.e. east coast vs. west coast)  Pre-assigned criteria - User ID, IP, or other dynamic criteria  Load Balanced
  • Segmenting Responsibility Segmenting responsibility allows for a distributed architecture  Each component can be scaled independently  Allows for more flexibility in scaling  Adds more complexity and potential messaging overhead
  • Clustering Clustering is the concept of having a group of nodes working App App App App Nod Nod Nod Nod together to provide the e e e e same capability  Nodes typically co- Share located d  Common data shared Data as needed across the cluster  Communication may be needed between nodes
  • Messaging Once a clustered  Types of Messaging and/or distributed  JMS architecture is used  Open Source MQ messaging will be packages needed between  Custom Designed various components  Use of APIs and/or nodes
  • Example of Scaled Architecture Load Load Load Load Balancer Balancer Balancer Balancer Web Compone Compone Web Compone Compone Web Server Compone nt 1 Compone nt 2 Web Server Compone nt 1 Compone nt 2 Server nt 1 nt 2 Server nt 1 nt 2 Database Database Site 1 Site 2
  • Reliability/Availability
  • What is Reliability/Availability? Availability is typically measured by the amount of downtime your application has in a given year  Unplanned downtime and planned downtime are both considered Reliability is described by the likelihood of failure based on actual measurements We’ll focus more on Availability
  • Reliability/AvailabilityFactors to Consider Cost vs. Need Problem detection Automation for recovery Active/standby, active/active, hot standby vs. cold standby Local and Geo-redundancy Multi-zone, multi-cloud Test Until You Break the System
  • Reliability RequirementsCost Considerations Need Number of instances  User Experience Bandwidth  Customer requirements requirements between sites  Negative Publicity Complexity of software Monitoring
  • Problem Detection Effective monitoring of the application is key to minimizing downtime  Event reporting in the software  External monitoring – test for successful behavior  Auto detection and alerting to minimize cost of operations personnel
  • Automation for Recovery How quickly a failed component recovers increases reliability  Automatic detection and automatic recovery  Automated installation key for minimizing setup time during recovery
  • Availability Models N = number of nodes required for normal N N processing N+1 = one additional node to provide N N +1 redundancy in case of failure N+K = K nodes provide N N K K additional redundancy
  • Redundancy Models Active/Cold Standby Cold  backup site is booted Active Standb up when needed y Active/Hot Standby Active  Backup site is running Active Standb and ready to takeover y Active/Active  Both sites active and Active Active processing traffic
  • Local and Geo-Redundancy Local  Geo-Graphic  Backup instances  Backup instances are available within are available in the same location another geo-graphic location  Use of availability  Typically in a zones within a separate region to region very similar account for events such as natural disasters
  • Availability to the Max Multi-Zone/Multi-  Multi-Cloud Region  Ifyour application  Multi-zone typically requires the provide instances running in different maximum possible physical locations, but availability in same region  Run in different  Multi-region provides cloud providers in different geographic regions of availability different regions
  • Test Until You Break the System Push the system to the max and observe the breaking points Fix the problem, repeat The best way to find problems to prevent unplanned downtime is to thoroughly test with a mindset to break
  • Q&A
  • THANK YOU!Greg
